Creda SPA 200c Installation And User Manual

HOW TO USE YOUR SPA200C SHOWER (SUMMARY)
1. Ensure the electricity and water are turned on to the unit.
2. Press the start / stop button "B".
This will turn the shower on, the water will flow and the
neon indicator light will illuminate. It is recommended that
you do not wholly enter the water flow during this period.
3. Knob "A" controls the power selection.
Select "High", "Medium (Med)" or "Cold"
The "small bar" indicates knob setting.
4. If the water is not at your desired showering
temperature, turn knob "C" a small amount until
you reach the desired showering temperature.
Turn clockwise for cooler or Turn anti-clockwise for warmer.
5. When you have finished showering, press the start / stop button "B" again.
The water will stop flowing and the neon indicator will go out.
10.5kW Models Only-Water will continue to flow for approximately 7 seconds before switching off.
6. Switch off the electricity supply at the ceiling switch or local isolator.
Notes
Wait 20 seconds for the temperature to stabilise after each adjustment.
The neon indicator light illuminates when the heaters are on and, if the shower has
been recently used, it may take up to 20 seconds to come on.
During this time the water may go from very hot to cold before stabilising.
The position of knob "C" will be approximately the same each time the shower is
used, varying only with incoming water temperature or pressure changes
(e.g. you will only need to change from summer to winter).
During normal operation, if an overheated water temperature is sensed then the
heater will switch off and the neon indicator light will go out.
Water will continue to flow and cool down before the heater switches back on again.
IMPORTANT WARNINGS!
DO NOT SWITCH THE APPLIANCE ON IF YOU SUSPECT IT OF BEING FROZEN.
WAIT UNTIL YOU ARE SURE IT HAS THAWED OUT.
DO NOT OPERATE THE APPLIANCE IF WATER DISCHARGES FROM THE PRESSURE RELIEF
VALVE. MAINTENANCE IS REQUIRED BEFORE THE APPLIANCE CAN BE SAFELY USED.
THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS (INCLUDING CHILDREN AND
THE INFIRM) WITH REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES,
OR LACK OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY HAVE BEEN GIVEN
SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE
BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY
DO NOT PLAY WITH THE APPLIANCE.
We offer a technical advisory service on the telephone to installers and
other customers with problems in the field. RING 0844 372 7766 (UK ONLY)
(A3) Leaflet No. 567-2151-61b
16
CREDA SPA200C RANGE
ELECTRIC SHOWER
Installation and User Guide
IMPORTANT:
This booklet should be left with the user
after installation and demonstration
