- Page 1 CREDA SPA300C ELECTRIC SHOWER Installation and User Guide IMPORTANT: This booklet should be left with the user after installation and demonstration...
-
Page 2: Table Of Contents
Assembly of Accessories ....Creda After Sales Service ... . . How to maintain your SPA300C Shower.. -
Page 3: How To Install Your Spa300C Shower
HOW TO INSTALL YOUR SPA300C SHOWER WARNING: ALL WIRING AND INSTALLATION MUST BE SUPERVISED BY A SUITABLY QUALIFIED PERSON. WARNING: DO NOT INSTALL THIS SHOWER WHERE IT MAY BE SUBJECTED TO FREEZING CONDITIONS We recommend that the installation is done in the following sequence. - Page 4 Blockage in the water ways (particularly the handset and solenoid valve) will prevent the heater working properly. Note: You may be charged for a service call if it is due to incorrect installation. 7. The shower is designed to have an open outlet and should only be used with “Creda” recommended fittings.
-
Page 5: Cold Water Inlet Pipe Configuration
COLD WATER INLET PIPE CONFIGURATION Please note that standard compression fittings are shown. Push-Fit connections or a combination of the two are also suitable. To aid installation, you may find it convenient to move the flexible pressure relief valve outlet assembly by removing the two securing screws. - Page 6 c) ELECTRICAL WARNING: THIS SHOWER MUST BE EARTHED. The electrical installation must be in accordance with the current BS.7671 (IEE Wiring Regulations) and “Part P” of the Building Regulations and/or local regulations. 1. The shower unit is designed for a single phase AC electrical supply. Please check the rating plate on the unit to see what details apply to your shower.
-
Page 7: Assembly Of Accessories
NOTE: The adjustable slider grips the conical nut on the shower hose (g) HOW TO MAINTAIN YOUR SPA300C SHOWER It is recommended that the shower unit and hose etc. be cleaned using a soft cloth and that the use of abrasive or solvent based cleaning fluid be avoided, especially on any plated finishes. -
Page 8: How To Use Your Spa300C Shower (Detailed)
HOW TO USE YOUR SPA300C SHOWER (DETAILED) 1. Ensure the electricity and water are turned on to the unit. 2. Your shower can be turned on by pressing either Button “A”, Button “B” or Button “C” (see Diagram 5). Button “A” (III) - Starts shower on “High” power. -
Page 9: What To Do If Things Go Wrong
WHAT TO DO IF THINGS GO WRONG (1) SELF HELP If the shower is not working satisfactorily, make the following checks before calling out the installer. Any one of these adjustments could restore the performance. The shower cycles Temperature is set too hot causing the thermal cut-out (safety device) to operate. from HOT to COLD Turn knob “E”... -
Page 10: How Your Spa300C Shower Works
HOW YOUR SPA300C SHOWER WORKS 1. Water is heated instantaneously as it flows over the heating elements in the copper cylinder (Diagram 6). 2. The heaters are only switched on when sufficient water is flowing. This is done automatically with a switch which works on water pressure and is indicated by the LED indicator illuminating. -
Page 11: Creda After Sales Service
CREDA AFTER SALES SERVICE We offer a technical advisory service on the telephone to installers and other customers with problems in the field. RING 0870 9000 430 (UK ONLY) Remember to quote the exact type of shower, as written on the shower front and on is leaflet. -
Page 12: How To Use Your Spa300C Shower
HOW TO USE YOUR SPA300C SHOWER (SUMMARY) 1. Ensure the electricity and water are turned on to the unit. 2. Your shower can be turned on by pressing either Button “A”, Button “B” or Button “C” Button “A” (III) - Starts shower on “High” power.
