Contact and Commissioning Details
Installer Contact Name and Address :
GUARANTEE
Terms and Conditions for UK (outside UK contact your local distributor)
We, Applied Energy Products Limited, guarantee this product for domestic use only, for the period of 24
*
months
from the date of purchase.
*
Months 13 to 24 of your free guarantee are conditional on the registration of your product at the time of purchase.
Product registration helps us to identify when products are installed, and in what location, in order to facilitate a more
efficient response to your requests.
If the shower is not working properly when it is first used, please contact your installer. They will check that
the system set up is correct and that the shower has been satisfactorily commissioned.
During the period of guarantee, in the unlikely event of a product break -down due to faulty workmanship or
material defects the product should be returned to Applied Energy Products Ltd for repair on condition that:-
a) The appliance has been correctly installed in accordance with our instructions and is being used on the
supply circuit or voltage printed on the rating plate.
b) The appliance has been used in accordance with these instructions and has not been tampered with or
otherwise been subject to misuse, neglect or accident.
c) The appliance has not been taken apart, modified or repaired ex cept by a person authorised by us.
d) Evidence of the date of purchase in the form of an invoice or receipt will be required in order to qualify for
an in-guarantee repair.
e) Repair under guarantee has no effect on the expiry date. The guarantee on any exchanged parts or product
ends when the original guarantee period ends.
EXCLUSIONS
This guarantee DOES NOT cover damage or defects arising from poor or incorrect installation, improper use or lack of
maintenance, including build up of limescale. Checking and cleaning of the inlet filters is not covered by this guarantee. It is
the responsibility of the installer to check that the installation parameters meet the requirements of the product, and any
relevant regulations.
We make no guarantees as to repair times.
The guarantee applies to a repair or replacement (at our discretion) of the product subject to the conditions above, and
DOES NOT cover compensation for the loss of the product or consequential loss of any kind including the removal,
refitting and transportation of the product under any within guarantee repair.
This guarantee applies to the base unit and remote control only and not to other parts of the installation or product such as:
Pressure relief devices, sprayheads, hoses, accessories, isolating switches , batteries, electrical cable and/or circuit
breakers.
This guarantee does not affect your statutory rights.
Applied Energy Products Ltd. Morley Way, Peterborough. PE2 9JJ.
(A3) 567 2194 40A
Model N° :
Serial N° :
Date Installed :
Telephone 01733 456789
Fax 01733 310606
www.applied-energy.com
_20_
Installation and User Guide
Please leave this guide with the end user (for future reference)
Thermostatic Digital
Mixer Shower
Electronic Remote Control Mixer Shower
This Handbook is for the Installer and User
You must read these instructions prior to installing and
commissioning the mixer shower
Note to Installer :
For the benefit of the customer please complete :
Your contact details and commissioning information on Page 20.
_1_
Models
Pumped
Non pumped

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pumped and is the answer not in the manual?

Questions and answers

Summary of Contents for Creda Pumped

  • Page 1 Checking and cleaning of the inlet filters is not covered by this guarantee. It is Non pumped the responsibility of the installer to check that the installation parameters meet the requirements of the product, and any relevant regulations.
  • Page 2: Table Of Contents

    Cleaning the remote control and descaling the shower handset b) Cleaning the base unit inlet filters How the shower works Description - Switch on and running - Pumped and Non pumped Troubleshooting a) Self Help (Consumer and Installer) b) Professional Help (Qualified Installer) Spares and After Sales service Contact &...
  • Page 3: Introduction

    • Remove and clean filter (See Plumbing (Non pumped model only) Page 15) • The non pumped shower unit is designed to mix cold and hot water from an unvented supply and • Base unit makes a whizzing • Air lock in pipes •...
  • Page 4: B) Product Description

    5. Potentiometer position sensor 12. Programmable buttons • The base unit is supplied with cold water and hot water. (Gravity fed on Pumped model, Unvented 6. Mixing chamber and valve 13. Warmer and cooler buttons on Non Pumped model).
  • Page 5: B) Locating The Base Unit

    DO NOT install the base unit in the bathroom or shower cubicle area. The shower is a remote controlled mixer shower incorporating a booster pump. (On the non pumped DO NOT install the base unit upside down (i.e. secured to a ceiling) model the booster pump is replaced by a motorised flow regulator valve).
  • Page 6: Typical Layouts - Gravity Feed - Unvented

    • Replace and reassembly the cold and hot water connections. • Turn water and electrical supplies back on again. High pressure – Unvented mains fed storage (Non Pumped Model only) • Pressure reducing valves are required if the pressure is above 5 bar.
  • Page 7: Combi Boiler - Shower Cubicle

    Remove battery cover and insert 2 x AAA batteries. (Observe polarity). High pressure – Unvented thermal store (Non Pumped Model only) • Pressure reducing valves are required if the pressure is above 5 bar. • This plumbing scheme requires that the...
  • Page 8: D) Electrical Connections

    • A means for disconnection in all poles must be incorporated in the fixed wiring in accordance Note : A button must be programmed before it will function. with the wiring rules. d) Overtemperature protection Schematic of Pumped base unit The shower has an over temperature protection built in. (Pumped Model) •...
  • Page 9: Remote Control Batteries

    • Before the unit can function correctly the air must be bled from the base unit and associated pipes Temp Temp Press the Temperature buttons to adjust the temperature. • To bleed the air from the Pumped base unit : Decrease Increase - Make sure the cold and hot delivery pipes are primed prior to connection. (See above) - Make sure the power to the base unit has been on for LESS than 5 minutes.
  • Page 10: Synchronising The Remote Control To The Base Unit

    OFF = Temperature adjustment is restricted between 1 (approx 34°C) and 5 (approx 40°C) Notes : a) Pressing the two Program buttons is used to bleed the air from a Pumped unit. On a Non DIP 3 : Stop the water flow being adjusted to maximum setting Pumped unit these two buttons will have no effect.
