Creda JETSPA CONTEMPORARY Installation And User Manual

HOW TO USE YOUR JETSPA SHOWER (SUMMARY)
1. Ensure the electricity and water are turned on to the unit.
2. Your shower can be turned on by pressing either
Button "A", Button "B" or Button "C"
Button "A" (III) - Starts shower on "High" power.
Button "B" (II) - Starts shower on "Medium" power.
Button "C" (I) - Starts shower on "Cold".
Press Button "A", "B" or "C".
Water will flow and the LED indicator above your choice
will illuminate. It is recommended that you do not wholly
enter the water flow during this period.
3. If the water is not at your desired showering temperature,
turn knob "E" a small amount until you
reach the desired showering temperature.
Turn clockwise for cooler or Turn anti-clockwise for warmer.
4. When you have finished showering, press Button "D" ( ) only, the LED light above will flash.
Water will continue to flow for up to 7 seconds before switching off.
5. Switch off the electricity supply at the ceiling switch or local isolator.
Notes
Wait 20 seconds for the temperature to stabilise after each adjustment.
The LED indicator light illuminates when the heaters are on and, if the shower has
been recently used, can take up to 20 seconds to come on.
During this time the water may go from very hot to cold before stabilising.
The position of knob "E" will be approximately the same each time the shower is
used, varying only with incoming water temperature or pressure changes
(e.g. you will only need to change from summer to winter).
During normal operation, if an overheated water temperature is sensed then the
heater will switch off and the LED indicator light will go out.
Water will continue to flow and cool down before the heater switches back on again.
IMPORTANT WARNINGS!
DO NOT SWITCH THE APPLIANCE ON IF YOU SUSPECT IT OF BEING FROZEN.
WAIT UNTIL YOU ARE SURE IT HAS THAWED OUT.
DO NOT OPERATE THE APPLIANCE IF WATER DISCHARGES FROM THE PRESSURE RELIEF
VALVE. MAINTENANCE IS REQUIRED BEFORE THE APPLIANCE CAN BE SAFELY USED.
THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS (INCLUDING CHILDREN AND
THE INFIRM) WITH REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES,
OR LACK OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY HAVE BEEN GIVEN
SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE
BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY
DO NOT PLAY WITH THE APPLIANCE.
We offer a technical advisory service on the telephone to installers and
other customers with problems in the field. RING 0870 9000 430 (UK ONLY)
(A3) Leaflet No. 567-2189-01 Revision A
12
JETSPA CONTEMPORARY
ELECTRIC SHOWER
Installation and User Guide
IMPORTANT:
This booklet should be left with the user
after installation and demonstration
