- Page 1 CREDA 570 Pumped Electric Shower Installation and User Guide IMPORTANT: This booklet should be left with the user after installation and demonstration WARNING: Under no circumstances should this unit be connected to the mains cold water supply...
-
Page 2: Table Of Contents
How to install your Creda Shower ........ -
Page 3: How To Install Your Creda Shower
HOW TO INSTALL YOUR CREDA SHOWER WARNING: ALL WIRING AND INSTALLATION MUST BE SUPERVISED BY A SUITABLY QUALIFIED PERSON. WARNING: DO NOT INSTALL THIS SHOWER WHERE IT MAY BE SUBJECTED TO FREEZING CONDITIONS We recommend that the installation is done in the following sequence. - Page 4 7. If you have not yet done so, remove the front cover assembly by undoing the retaining screws at the top and bottom of the unit and lifting the cover off. Your shower is provided with 3 fixing positions in the backplate (see Diagram 3). The top-fixing hole is a “key-hole”...
- Page 5 7. The shower is designed to have an open outlet and should only be used with “Creda” recommended fittings. Do not connect the handset until after the shower front cover and corner section are fitted. WARNING: DO NOT FIT A TAP ON THE SHOWER OUTLET.
-
Page 6: How To Maintain Your Creda Shower
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH THE APPLIANCE. HOW TO MAINTAIN YOUR CREDA SHOWER It is recommended that the shower unit and hose etc. be cleaned using a soft cloth and that the use of abrasive or solvent based cleaning fluid be avoided, especially on any plated finishes. -
Page 7: How To Use Your Creda Shower (Detailed)
HOW TO USE YOUR CREDA SHOWER 1. Ensure the electricity and water are turned on to the unit. 2. Your shower has 2 control knobs (see Diagram 5). Knob “A” controls the 2 power settings. The most popular is “high” indicated by “... -
Page 8: What To Do If Things Go Wrong (1) Self Help
WHAT TO DO IF THINGS GO WRONG (1) SELF HELP If the shower is not working satisfactorily, make the following checks before calling out the installer. Any one of these adjustments could restore the performance. The shower cycles The shower temperature is set too hot causing the thermal cut-out (safety from HOT to COLD device) to operate. -
Page 9: What To Do If Things Go Wrong (2) Professional Service
Blockage on outlet e.g. blocked shower handset. relief valve Replace the pressure relief disc (not covered by guarantee). CREDA AFTER SALES SERVICE We offer a technical advisory service on the telephone to installers and other customers with problems in the field. -
Page 10: How Your Creda Shower Works
HOW YOUR CREDA SHOWER WORKS 1. Water is heated instantaneously as it flows over the heating elements in the copper cylinder. 2. Your shower incorporates a pump which boosts the incoming water pressure to a level more suitable for showering. -
Page 11: Filters And Assembly Of Accessories
FILTERS Inlet Assembly Showing Filter Position Removing the Filter from the Filtered Isolation Valve (Turn Water Off First) ASSEMBLY OF ACCESSORIES... -
Page 12: Guarantee And Contact Details
APPLIED ENERGY PRODUCTS LIMITED, MORLEY WAY, PETERBOROUGH, PE2 9JJ TEL: +44 (0) 1733 456789 FAX: +44 (0) 1733 310606 Website: www.creda-showers.co.uk We offer a technical advisory service on the telephone: Ring: 0870 9000 430 (UK Only) / Ring: +385 1 842 8222 (ROI Only)
