LCD screen display
VOLTAGE RAMP ERR.
INVERTER BLOCKED
OUTPUT DC VOLTAGE
INVERTER BLOCKED
INVERTER BLOCKED
BLK.UPS -> BLK.INV
INVERTER DESATS.
INVERTER BLOCKED
INTERN.EXE. ERROR
INVERTER BLOCKED
DSP INTERN. ERROR
INVERTER BLOCKED
UPS BLOCKED
BLK.REC -> BLK.UPS
INTERN.INI. ERROR
UPS BLOCKED (DSP)
INTERN.EXE. ERROR
UPS BLOCKED (DSP)
UPS BLOCKED
BLK.INV -> BLK.UPS
INTERN.COM. ERROR
UPS BLOCKED (DSP)
PARAL. SYS. DISC.
UPS BLOCKED
UPS OVERTEMPERAT.
UPS BLOCKED
RECTIFIER OVERLO.
UPS BLOCKED
INVERTER DESATS.
UPS BLOCKED
DSP INTERN. ERROR
UPS BLOCKED
PFC & INV BLOCK.
UPS BLOCKED
Table .4 Alarm list displayed in the LCD panel.
Screen 4.1: This alarm indicates that the rectifier is overloaded. The rectifier overload appears when the input
current of any phase is greater than the following ratio:
Where:
- Iin-ovl is Overload Input Current (A)
- Pout is Rated Output Apparent Power (VA)
- Vout_p-n is Rated Output Voltage phase-to-neutral (V)
Screen 4.2: This alarm indicates that the inverter is overloaded. The inverter overload appears when the
output current of any phase is greater than the rated output current.
Where:
- Iout is rated Output Current (A)
- Pout is Rated Output Apparent Power (VA)
- Vout_p-n is Rated Output Voltage phase-to-neutral (V) or when the total output active
power is greater than the following formula:
INFOSEC UPS SYSTEM - 4, rue de la Rigotière - 44700 Orvault - FRANCE - www.infosec-ups.com
36
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 03 11 AA AA 201 18
Alarms Ref.
4.48
4.49
4.50
INVERTER
BLOCKS
4.51
4.52
4.53
4.54
4.55
4.56
4.57
4.58
UPS BLOCKS 4.59
4.60
4.61
4.62
4.63
4.64
Iin-ovl = 0,326 x Pout / Vout_p-n
Iout-ovl = Pout / (Vout_p-n * 3)
