INFOSEC M4T User Manual page 35

LCD screen display
RECTIFIER
OVERLOAD
INVERTER
OVERLOAD
MAINS FAILURE
LOW BATTERY LEVEL
INVERTER VOLTAGE
OUTSIDE MARGINS
DC VOLT. DETECTED
AT THE OUTPUT
DC VOLT. DETECTED
AT THE OUTPUT
MAINS FAILURE
BATTERY DISCHARGIG
HIGH TEMPERATURE
REDUCE OUTPUT LOAD
BATT. SWITCH OPEN
SWITCH IT ON
BYPASS FAILURE
NOT SYNCHRONISED INV
UPS ON BYPASS
INITIALISE THE UPS
SOME UNIT BLOCKED
DUE TO MAINT. BYPASS
CAN BUS 1
COMMUNICATION FAIL.
CAN BUS 2
COMMUNICATION FAIL.
END OF BATTERY
LIFE ALARM
BATT. TEMPERATURE
TOO HIGH
BATTERY TEST
NOT SUCCEEDED
BAT.DISCONNECTION
SHUTDOWN & RESTART
MAINS PHASE ROT.
UPS START INH.
BYPASS PHASE ROT.
UPS START INH.
INP. VOLTA. WRONG
RECTIFIER STOP
RECTIFIER DESATS.
RECTIFIER STOP
DSP INTERN. ERROR
RECTIFIER STOP
INPUT PHASE ROT.
RECTIFIER STOP
INFOSEC UPS SYSTEM - 4, rue de la Rigotière - 44700 Orvault - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 03 11 AA AA 201 18
Alarms Ref.
RECTIFIER 4.1
4.2
4.3
INVERTER 4.4
4.5
4.6
4.7
4.8
4.9
4.10
4.11
4.12
4.13
UPS
4.14
4.15
4.16
4.17
4.18
4.19
4.20
4.21
4.22
RECTIFIER
STOPS
4.23
4.24
LCD screen display
INVERTER DESATS.
INVERTER STOP
INVERTER OVERLOAD
INVERTER STOP
SHUTDOWN COMMAND
INVERTER STOP
MAINTENANCE BYP.
INVERTER STOP
PARAL. SYS. DISC.
INVERTER STOP
HIGH OVERLOAD
INVERTER STOP
OVERTEMPERATURE
INVERTER STOP
RECTIFIER OVERLO.
INVERTER STOP
DSP INTERN. ERROR
INVERTER STOP
OUT SHORT-CIRCUIT
INVERTER STOP
BYPASS PHASE ROT.
INVERTER STOP
DSP INTERN. ERROR
UPS STOP
LOW BATTERY
UPS STOP
EMERGE. POWER OFF
NO OUTPUT VOLTAGE
OUT SHORT-CIRCUIT
NO OUTPUT VOLTAGE
DSP INTERN. ERROR
UPS BLOCK ALL
DC BUS VOLT WRONG
RECTIFIER BLOCKED
RECTIFIER BLOCKED
BLK.UPS -> BLK.REC
RECTIFIER DESATS.
RECTIFIER BLOCKED
VOLTAGE RAMP ERR.
RECTIFIER BLOCKED
INTERN.EXE. ERROR
RECTIFIER BLOCKED
DSP INTERN. ERROR
RECTIFIER BLOCKED
CONTACTOR T. FAIL
RECTIFIER BLOCKED
Alarms Ref.
4.25
4.26
4.27
4.28
4.29
INVERTER
STOPS 4.30
4.31
4.32
4.33
4.34
4.35
4.36
UPS STOPS
4.37
4.38
BYP STOPS
4.39
4.40
4.41
4.42
4.43
