INFOSEC M4T User Manual page 32

Press key (ESC) on any screen of any submenu, to return to main screen (Screen 0.0),
Screen 2.1: Input voltages phase to phase (units 0.1V).
Screen 2.2: Three phase input voltages phases to neutral (units 0.1V).
Screen 2.3: Input current for each phase in three phase equipments (units 0.1A).
Screen 2.4: Three phase output voltages phases to neutral (units 0.1V).
Screen 2.5: Output current for each phase in three phase equipments (units 0.1A).
Screen 2.6: Three phase inverter output voltages phases to neutral (units 0.1V).
Screen 2.7: Inverter output current for each phase in three phase equipments (units 0.1A).
Screen 2.8: Three phase bypass voltages phases to neutral (units 0.1V).
Screen 2.9: Bypass current for each phase in three phase equipment (units 0.1A).
Screen 2.10: DC bus voltages positive and negative (units 0.1V).
Screen 2.11: Battery voltages positive and negative (units 0.1V).
Screen 2.12: Charge battery currents positive and negative (units 0.1A).
Screen 2.13: Discharge battery currents positive and negative (units 0.A).
Screen 2.14: Input apparent power of L1 (units 0.1kVA).
Screen 2.15: Input apparent power of L2 (units 0.1kVA).
Screen 2.16: Input apparent power of L3 (units 0.1kVA).
Screen 2.17: Input active power of L1 (units 0.1kW).
Screen 2.18: Input active power of L2 (units 0.1kW).
Screen 2.19: Input active power of L3 (units 0.1kW).
Screen 2.20: Total input apparent power and active power (units 0.1kVA & 0,1kW).
Screen 2.21: Input power factor for each phase in three phase equipment (units 0.01).
Screen 2.22: Apparent output power L1 (units 0.1kVA).
Screen 2.23: Apparent output power L2 (units 0.1kVA).
Screen 2.24: Apparent output power L3 (units 0.1kVA).
Screen 2.25: Active output power L1 (units 0.1kW).
Screen 2.26: Active output power L2 (units 0.1kW).
Screen 2.27: Active output power L3 (units 0.1kW).
Screen 2.28: Total apparent and active powers (units 0.1kVA and 0,1kW).
Screen 2.29: Output power factor of each phase for three phase equipments (units 0.01).
Screen 2.30: Output load of three phases (units 0.1%).
Screen 2.31: Total input load and total output load (units 0.1%).
Screen 2.32: Input, bypass and output frequencies (units 0.1Hz).
Screen 2.33: Rectifier, inverter and battery temperatures (units 1ºC).
Screen 2.34: Estimated backup time (units 1 minute).
