- Page 1 ROFESSIONAL COIL SPRING COMPRESSOR MODEL NO: CHT747 PART NO: 1801747 OPERATION & MAINTENANCE INSTRUCTIONS LS0813...
-
Page 2: Whats Supplied
This guarantee does not effect your statutory rights. WHATS SUPPLIED Contact your Clarke dealer if any items are missing or damaged. • Compressor Column (with hand • 3 pairs of Yokes (Gold, Black and... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS WARNING: ENSURE HEALTH & SAFETY, LOCAL AUTHORITY, AND GENERAL WORKSHOP PRACTICE REGULATIONS ARE ADHERED TO WHEN USING THIS EQUIPMENT. WARNING: WEAR APPROVED SAFETY EYE PROTECTION (STANDARD SPECTACLES ARE NOT ADEQUATE). WARNING: DO NOT COMPRESS THE SPRING TO AN EXTENT WHERE THE COIL WINDINGS OR JAWS TOUCH. - Page 4 INSTRUCTIONS FOR USE 1. The basic setup is as shown on the right. • Each yoke has safety lips to prevent slippage and is angled to fit the pitch of the spring to achieve maximum surface contact between the yokes and the spring, 2.
- Page 5 CONICAL/WIDE BODIED SPRINGS 4. For conical springs, the centre axis of the spring should always stay parallel to the compressor column. • You may need to use different sized yokes for the top and bottom of the spring. 5. If necessary, use the extension block(s) as shown to keep the spring and compressor body parallel.
-
Page 6: To Compress A Spring Removed From A Vehicle
• Before each use check the compressor to ensure it is not damaged or worn. • If suspect, do not use the unit, but contact your local Clarke Dealer who will be able to advise you regarding repair and spare parts. -
Page 7: Also Available From Your Clarke Dealer
ALSO AVAILABLE FROM YOUR CLARKE DEALER CHT695 OIL FILTER CAP WRENCH SET CHT701 12 PIECE OIL DRAIN PLUG KEY SET • Can withstand up to 85lb ft torque • 3/8" square drive carbon steel tommy bar • Oxide finish for rust protection •...
