Depending on how your Cisco Unified IP Phone is
Step 1
powered with one or two Expansion Modules, perform
one of the following actions to connect the power
supply:
• Your Cisco Unified IP Phone is powered over the
Ethernet with one Expansion Module:
• If your Cisco Unified IP Phone is powered over the
Ethernet with two Expansion Modules:
• If your Cisco Unified IP Phone is powered with a
power supply unit with one Expansion Module:
• If your Cisco Unified IP Phone is powered with a
power supply unit with two Expansion Modules:
Reconnect the Cisco Unified IP Phone handset and
Step 2
network connection.
Connect the power supply unit to the AC
adapter port on the Expansion Module and
plug the other end into a standard electrical
power outlet in the wall.
Connect the power supply unit to the AC
adapter port on the Expansion Module closest
to the Cisco Unified IP Phone and plug the
other end into a standard electrical power
outlet in the wall.
Reconnect the original Cisco Unified IP Phone
power supply unit to the AC adapter port on
the Cisco IP Phone and plug the other end into
a standard electrical power outlet in the wall.
Connect a second power supply unit to the AC
adapter port on the Expansion Module closest
to the Cisco Unified IP Phone and plug the
other end into a standard electrical power
outlet in the wall.
13
