Appendix A
Navigation links are shown on the left side of the browser screen. Navigable links include:
System Information
Configuration
Site Survey
Link Control
Help
The lower left portion of the screen shows the unit's current opmode, connection, channel, and antenna status.
The main body of the System Information displays most of the key parameters. To alter these parameters use the
Configuration page.
Description of System Information entries. To view this information within the radio, click the Help link.
Model:
Unit Type:
Hardware Version:
Firmware Version:
System Up Time:
MAC:
IP, Subnet Mask, Gateway:
Opmode:
Default Opmode:
Peer ID:
Status:
RSSI:
Tx MIR:
Channel:
Tx Power:
Channel Table:
Area Code:
Trango Broadband Wireless — Atlas4900 User Manual Rev. 1.3
Model number.
Atlas unit type either MU (master) or RU (remote).
Hardware version is factory-set and can not be changed by user.
Current firmware version loaded in the radio.
Time since radio was last rebooted or powered.
MAC address of the radio.
IP, subnet mask, and gateway of radio
Current operation of the radio.\"On\" indicates transmitting. \"Off\" indicates
not transmitting.
Opmode which radio enters after reboot or power cycle.
User entered MAC address of the peer unit. In the MU, Peer ID is the MAC
address of the RU. In the RU, Peer ID is the MAC address of the MU.
Status of Remote Unit. Connected (wireless link established) or disconnected
(wireless link not established).
Relative Signal Strength Indicator. Displays signal strength received from the
Remote Unit. 'n/a' indicates Remote Unit is not connected.
Transmit Maximum Information Rate to the peer unit.
RF Channel
Transmit power
Set of channels based on the Country Code setting.
Country information elements. It consists of the country code and a set of
channels with maximum power.
HTTP Interface
