Page 1: Instruction Manual
Gas Hob C 761 G Model: Instruction Manual... -
Page 2: Table Of Contents
Thank you for buying your new CAPLE Gas Hob. To ensure that you get the best results from your new CAPLE Gas Hob, we strongly suggest that you read this instruction manual thoroughly before use. This manual contains installation advice, usage instructions and a cleaning guide, as well as other important facts about your CAPLE Gas Hob. -
Page 3: Installation Requirements
Installation Requirements DOUBLE POLE SWITCHED WARNING! FUSED SPUR OUTLET ELECTRICITY CAN BE EXTREMELY DANGEROUS. THIS APPLIANCE MUST BE EARTH- Electrical Installation FUSE This appliance must be connected by a qualified electrician using fixed wiring via a double pole isolating switch (fig. 1). As the colours of the wires in the mains USE A 3 AMP FUSE lead for the appliance, may not corre-... -
Page 4: Gas Installation
Gas Installation Gas installation Any C.O.R.G.I registered fitter requiring help must provide name, address and This appliance should be fitted by a registration number. Information supplied C.O.R.G.I. registered fitter. will be validated before help is provided. The installation must comply with Gas Safety (installation and use) Regulations This appliance is predisposed and 1994. -
Page 5: Installation
Installation The hob must be installed by a qualified technician and in compliance with local safety standard. Take care not to lose or mishandle cabinet only any parts when unpacking the (without cooker hood) appliance. Positioning the appliance The hob must be installed a minimum of 50 mm from the back wall and 150 mm from any vertical surface either side of the hob. -
Page 6: Assemble The Three Piece Burners. Take Care To Properly Locate The Assembled Burner On The Burner Base (Fig
Installation 1. The hob requires a space in the kitchen work surface as shown in fig 3. Fig. 3 NOTE: A partition between the base of the hob and the cupboard below should be fitted 100 mm below the worktop if the cupboard is to be used for storage. Never place perishable foods in the cupboard below the hob. - Page 7 Adhesive side Fig. 4 Fig. 5 Fig. 6...
-
Page 8: How To Use Your Gas Hob
How to use your gas hob Fig. 7 COOKING HOB CONTROLS DESCRIPTION 1. Auxiliary burner (A) - 1,00 kW 10. Electric lighter button 2. Rapid burner (R1) - 3,05 kW 3. Semirapid burner (SR) - 1,60 kW 11. Burner control knob 1 (A) 4. -
Page 9: Lighting The Burners
Use of the burners The arrival of the gas at the burner is controlled by a knob (fig. 8) which operates the safety closing tap. When the mark on the knob coincides with the symbols on the panel at the side, we will have: - symbol tap off (burner off) -
Page 10: Cleaning And Maintenance
How to use your gas hob Cooking hints The burners are different sizes, and can be used in different ways; the largest for boiling, to seal meat or foods that are cooked quickly and the smallest for stews and sauces. Always ensure that you use the correct size of saucepan. -
Page 11: Stainless Steel
2. The controls are switched on. 3. Both the fuse and the mains fuse are intact. 4. The gas supply is connected to the appliance. If you are in any doubt about carrying out these checks, call the CAPLE Helpline on 0870 241 1142. -
Page 12: Your Guarantee
YOUR GUARANTEE CAPLE guarantees all parts of this product for one year from the date of pur- chase. During that time, should it become necessary CAPLE engineers will replace or repair all defective parts free of charge, except for parts subject to fair wear and tear, such as lightbulbs.
