HP TouchSmart tx2 Maintenance And Service Manual page 14

Item
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
*To see wireless regulatory notices, refer to the section of the Regulatory, Safety, and Environmental Notices that applies to
your country or region. These notices are located in Help and Support.
6 Chapter 2 External component identification
Component
Battery light
Power light
Internal display switch
Wireless antennae (select models only)*
Internal microphones (2)
Display release latch
Integrated camera (select models only)
Fingerprint reader (select models only)
Mobility Center button
MediaSmart button
Rotate button
Consumer infrared lens
Function
●
On: A battery is charging.
●
Blinking: A battery that is the only available
power source has reached a low battery level.
When the battery reaches a critical battery level,
the battery light begins blinking rapidly.
●
Off: If the computer is plugged into an external
power source, the light is turned off when all
batteries in the computer are fully charged. If the
computer is not plugged into an external power
source, the light stays off until the battery
reaches a low battery level.
●
On: The computer is on.
●
Blinking: The computer is in the Sleep state.
●
Off: The computer is off or in Hibernation.
Turns off the display and initiates Sleep if the display
is closed while the power is on.
Send and receive wireless signals to communicate
with WLANs.
NOTE: The antennae are not visible from the outside
of the computer. For optimal transmission, keep the
areas immediately around the antennae free from
obstructions.
Record sound.
Opens the computer.
Records video and captures still photographs.
Allows a fingerprint logon to Windows® instead of a
password logon.
Opens Mobility Center.
Launches the MediaSmart program when the
computer is on.
Rotates the screen image clockwise into 4
orientations: landscape primary, landscape secondary,
portrait primary, and portrait secondary.
Receives a signal from the HP Remote Control.
