Page 1: Installation Guide
AT-MC13 AT-MC14 Ethernet Media Converters Installation Guide PN 613-50291-00 Rev A... - Page 2 Allied Telesyn, Inc. reserves the right to make changes in specifications and other information contained in this document without prior written notice. The information provided herein is subject to change without notice. In no event shall Allied Telesyn, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesyn, Inc.
-
Page 3: Electrical Safety And Emission Compliance Statement
Electrical Safety and Emission Compliance Statement Standards: This product meets the following standards. U.S. Federal Communications Commission Declaration Of Conformity Manufacture Name: Allied Telesyn, Inc. Manufacture Address: 960 Stewart Drive, Suite B Sunnyvale, CA 94085 USA Manufacture Telephone: 408-730-0950 Declares that the product:... - Page 4 Warning: In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. RFI Emission EN55022 Class B Immunity EN55024 Warning: This product requires shielded cables to comply with emission and immunity standards.
-
Page 5: Table Of Contents
Welcome to Allied Telesyn ........ - Page 6 Chapter 3 Troubleshooting ..........15 Appendix A Technical Specifications .
-
Page 7: Welcome To Allied Telesyn
Welcome to Allied Telesyn This guide contains instructions on how to install the AT-MC13 and AT-MC14 Ethernet Media Converters. Where to Find Web-based Guides The Allied Telesyn web site at www.alliedtelesyn.com offers you an easy way to access the most recent documentation, software, and technical information for all of our products. -
Page 8: Contacting Allied Telesyn Technical Support
You can use the Knowledge Base to submit questions to our technical support staff and review answers to previously asked questions. Telephone Support For Technical Support by phone, contact Allied Telesyn at one of the following locations: Americas Germany... -
Page 9: E-Mail Support
Returning Products Products for return or repair must first be assigned a Return Materials Authorization (RMA) number. A product sent to Allied Telesyn without a RMA number will be returned to the sender at the sender’s expense. To obtain an RMA number, contact Allied Telesyn’s Technical Support at one... -
Page 10: For Sales Or Corporate Information
Welcome to Allied Telesyn For Sales or Corporate Information You can contact Allied Telesyn for sales or corporate information at the location below: Allied Telesyn, Inc. 19800 North Creek Parkway, Suite 200 Bothell, WA 98011 Tel: 1 (425) 487-8880 Fax: 1 (425) 489-9191... -
Page 11: Overview
2 kilometers (1.2 miles). These media converters operate at 10 Mbps and feature half- or full-duplex operation. The AT-MC13 and AT-MC14 media converters can be used on a desktop or in an AT-MCR12 chassis. These media converters are easy to install and do not require software configuration or management. -
Page 12: Key Features
Table 1 lists the maximum operating distances for the AT-MC13 and AT-MC14 media converters. Table 1 Maximum Operating Distances 10Base-F 10Base-T Model Maximum Operating Maximum Operating Connector Connector Distance Distance AT-MC13 2 km (1.2 mi) RJ-45 100 m (328 ft) AT-MC14 2 km (1.2 mi) -
Page 13: Fiber Optic Port
This port has a maximum operating distance of 2 kilometers (1.2 miles) using 62.5/125 micron multimode fiber optic cable. Status LEDs Table 2 lists the status LEDs for the AT-MC13 and AT-MC14 media converters. Table 2 Status LEDs for the Media Converters... -
Page 14: Nml/Lnk Tst Button
NML/LNK TST Button The NML/LNK TST (Normal MissingLink/Link Test) button allows you to perform a link test on the ports on the media converter. This button also allows you to activate the MissingLink feature on the unit. The MissingLink and Link Test features are describe below. -
Page 15: Auto-Negotiation
The best network performance is achieved when an end-node can operate in full-duplex mode. The AT-MC13 and AT-MC14 media converters can operate in either half- or full-duplex mode. However, it is important to note that the end-nodes connected to these media converters must operate in the same duplex mode to avoid a duplex mode mismatch which can result in poor network performance. -
Page 16: External Ac/Dc Power Adapter
The power adapter is not used if you install the media converter in an AT-MCR12 chassis. Network Topologies The AT-MC13 and AT-MC14 media converters can be used in two different topologies: standalone and back-to-back. Both types of topologies are described below. -
Page 17: Back-To-Back Topology
AT-MC13 and AT-MC14 Installation Guide Back-to-Back Topology In some network configurations you may want to interconnect two media converters in what is referred to as a back-to-back topology. In this topology, the media converters not only extend the distance of your network but also convert the fiber optic cable from twisted pair to fiber optic and back again. -
Page 19: Installing The Media Converter
Chapter 2 Installing the Media Converter This chapter explains how to install an AT-MC13 and AT-MC14 media converter on a desktop. To install the media converter in an AT-MCR12 chassis, refer to the AT-MCR12 Installation Guide. This guide can be downloaded from our web site at www.alliedtelesyn.com. -
Page 20: Reviewing Safety Precautions
Table 4 Fiber Optic Port Specifications (Full-duplex) Maximum Maximum Operating Model Connector Cable Allowable Loss Distance Budget AT-MC13 62.5/125 micron 2 km (1.2 mi) 20 dB at 850 nm multimode AT-MC14 62.5/125 micron 2 km (1.2 mi) 20 dB at 850 nm multimode 1. - Page 21 AT-MC13 and AT-MC14 Installation Guide Caution Power to the hub must be sourced only from the adapter. Warning This is a “CLASS 1 LED PRODUCT” Warning Lightning Danger: Do not work on equipment or cables during periods of lightening activity.
-
Page 22: Installing The Media Converter
Installing the Media Converter To install an AT-MC13 and AT-MC14 media converter, perform the following procedure: Remove all equipment from the package and store the packaging material in a safe place. Note Do not remove the dust cover from the fiber optic port until you are ready to connect the fiber optic cable. -
Page 23: Warranty Registration
AT-MC13 and AT-MC14 Installation Guide Plug the AC/DC power adapter into an appropriate AC power outlet and insert the power plug into the DC receptacle located on the back of the unit. This step does not apply if you installed the unit in an AT-MCR12 chassis. -
Page 25: Troubleshooting
Chapter 3 Troubleshooting Follow the guidelines below to test and troubleshoot the installation in the event a problem occurs. If the PWR LED is OFF, do the following: If the unit is installed on a desktop, check to be sure that the power adapter is securely connected to a power outlet and that the power adapter cable is securely connected to the back of the media converter. - Page 26 If the LNK LED for the fiber optic port is OFF, do the following: Verify that the end-node connected to the port is ON and is operating properly. Check that the fiber optic cable is securely connected to the fiber optic port on the media converter and on the end-node.
- Page 27 If you are still experiencing problems after troubleshooting the installation, contact Allied Telesyn Technical Support for assistance. Refer to “Contacting Allied Telesyn Technical Support” on page viii or visit our web site at www.alliedtelesyn.com for support information.
-
Page 29: Technical Specifications
Appendix A Technical Specifications Physical Dimensions (W x D x H): 10.5 cm x 9.5 cm x 2.5 cm (4.1 in x 3.7 in x 1.0 in) Weight: 294 g (10.4 oz) Temperature Maximum Operating: 0° C to 40° C (32° F to 104° F) Maximum Storage: -25°... -
Page 30: Fiber Optic Port Specifications
Fiber Optic Port Specifications Table 6 through Table 9 lists the specifications for the 10Base-F fiber optic port. Table 6 Fiber Optic Transmitter Launch Power (dBm) Fiber Fiber Optical Model Optic Type Frequency Diameter Maximum Average Minimum All Models 62.5/125 850 nm -12.0 -15.0... -
Page 31: Pinout Assignments
AT-MC13 and AT-MC14 Installation Guide Table 9 Fiber Optic Loss Specification (Benchmarks) Worst Case Fiber Fiber Optic Optical Typical Loss Loss Bandwidth Type Diameter Frequency Factor Factor 62.5/125 microns 850 nm 3.00 dB/km 3.75 dB/km 200 1. MMF = Multimode Fiber. -
Page 33: Translated Safety And Emission Information
Appendix B Translated Safety and Emission Information Important: This appendix contains multiple-language translations for the safety statements in this guide. Wichtig: Dieser Anhang enthält Übersetzungen der in diesem Handbuch enthaltenen Sicherheitshinweise in mehreren Sprachen. Vigtigt: Dette tillæg indeholder oversættelser i flere sprog af sikkerhedsadvarslerne i denne håndbog. - Page 34 Translated Safety and Emission Information This product meets the following standards. Standards: U.S. Federal Communications Commission Declaration Of Conformity Manufacture Name: Allied Telesyn, Inc. Manufacture Address: 960 Stewart Drive, Suite B Sunnyvale, CA 94085 USA Manufacture Telephone: 408-730-0950 Declares that the product:...
- Page 35 AT-MC13 and AT-MC14 Installation Guide RFI Emission EN55022 Class B Immunity EN55024 Warning: This product requires shielded cables to comply with emission and immunity standards. If it is used with unshielded cables, the user may be required to take measures to correct the interference problem at their own expense.
- Page 36 Translated Safety and Emission Information Normen: Dieses Produkt erfüllt die Anforderungen der nachfolgenden Normen. Hochfrequenzstörung EN55022 Klasse B Störsicherheit EN55024 Für dieses Produkt sind abgeschirmte Kabel erforderlich, damit Achtung: den Richtlinien für Emission und Interferenzschutz entsprochen wird. Falls das Produkt mit nicht abgeschirmten Kabeln verwendet wird, können weitergehende Maßnahmen für die Korrektur von Interferenzproblemen auf Kosten des Benutzers notwendig werden.
- Page 37 AT-MC13 and AT-MC14 Installation Guide Elektrisk sikkerhed TUV-EN60950, UL60950 (UL/cUL) Sikkerhed Strømforsyningen til apparatet må udelukkende tages fra tilpasningstransformatoren. Europe - EC Brug kun TÜV godkendt vekselstrømstransformator på 12 Vdc, 500 mA. Laser/LED EN60825 Dette er et “PRODUKT UNDER KLASSE 1 LED”...
- Page 38 Translated Safety and Emission Information Waarschuwing: Het toestel wordt uitgeschakeld door de stroomkabel te ontkoppelen. Om het toestel stroomloos te maken: de stroomkabel ontkoppelen. Gevaar Voor Blikseminslag Gevaar: NIET aan toestellen of KABELS WERKEN bij BLIKSEM. Ventilatiegaten niet blokkeren. Sluit geen telefoonlijn aan op de signaalverbinding. Bedrijfstemperatuur: De omgevingstemperatuur voor dit produkt mag niet meer bedragen dan 40 graden Celsius.
- Page 39 AT-MC13 and AT-MC14 Installation Guide Ne pas connecter une ligne téléphonique au connecteur de signaux. Température De Fonctionnement: Ce matériel est capable de tolérer une température ambiante maximum de 40 degrés Celsius. Pour Tous Pays: Installer le matériel conformément aux normes électriques nationales et locales.
- Page 40 Translated Safety and Emission Information Standard: Questo prodotto è conforme ai seguenti standard. Emissione RFI (interferenza di radiofrequenza) EN55022 Classe B Immunità EN55024 questo prodotto, se utilizzato con cavi schermati, è conforme Avvertenza: alle norme sulle emissioni e sull’immunità. In caso di uso senza cavi schermati, l’utente può...
- Page 41 AT-MC13 and AT-MC14 Installation Guide Advarsel: Dette produktet må brukes med vernede kabler for å tilfredsstille emisjons- og fritakelsesstandarder. Dersom produktet brukes med uvernede kabler, må brukeren muligens rette forstyrrelsesproblemene for egen regning. Elektrisk sikkerhet TUV-EN60950, UL60950 (UL/cUL) Sikkerhet All strømtilførsel må komme fra adapteren.
- Page 42 Translated Safety and Emission Information Europe - EC Use um adaptador de corrente alternada com saída DC de 12 Vdc, 500 mA em conformidade com as especificações da TÜV. Laser/LED EN60825 Este é um “PRODUTO CLASSE 1 LED” Cuidado: O cabo de alimentação é utilizado como um dispositivo de desconexão.
- Page 43 AT-MC13 and AT-MC14 Installation Guide Peligro De Rayos Peligro: NO REALICE NINGUN TIPO DE TRABAJO O CONEXION en los equipos o en LOS CABLES durante TORMENTAS ELECTRICAS. No bloquee las aberturas para ventilacion. No conectar ninguna línea telefónica al conector de señales.
