ShakeNBake

Effect Mode parameter DMX value = 61
This option randomly vibrates the image. You can control the horizontal and vertical frequency.
Modifier 1: Adjusts random horizontal "shake" from the shortest refresh rate at a value = 0 to
to a maximum at a DMX value of 255 (100%).
Modifier 2: Adjusts random vertical "shake" from the shortest refresh rate at a value = 0 to a
maximum at a DMX value of 255 (100%).
Modifier 3: Adjusts how much the image is allowed to move from a minimum at a DMX value
of 0 to a maximum at a DMX value of 255 (100%).
Tip: To get the maximum effect, set a high value for Modifier 3 and low values for Modifiers 1
and 2.
NOTE: This option is also available as a Visual Mode adjusted with 2 Modifier
parameters, (see

Sinewave, Circular

Sinewave, Circular w/X-axis Wobbulation

Effect Mode parameter DMX value = 64

Sinewave, Circular w/Y-axis Wobbulation

Effect Mode parameter DMX value = 65

Sinewave, Circular w/Z-axis Wobbulation

Effect Mode parameter DMX value = 66
These options create a circular sinewave pattern and then vary the boundaries of the underlying
object along the designated axis without affecting the media file that is applied as a texture.
Modifier 1: Adjusts the size (amplitude) of the wobble from 0 = no adjustment to 255 (100%)
= maximum size.
Modifier 2: Adjusts the rate (frequency) of the wobble from 0 = no adjustment to 255 (100%)
= maximum rate
Modifier 3: Adjusts the offset (phase) of the wobble from 0 = no adjustment to 255 (100%) =
maximum offset
DL.2 Digital Light User Manual
ShakeNBake
on page 99).
CHAPTER 13
Effect Mode Options Descriptions
Object Effect Global Effect
Object Effect Global Effect
169
