1-4 COMMAND DESCRIPTIONS

• System Control Exit
Turns OFF "System Control standby mode" and
returns to normal operating mode. Will also "Hang
up" the phone line during Phone Patch operation.
• Repeat Start
This command enables repeater operation. This
command is not available during Phone Patch
operation.
• Repeat Stop
This command inhibits repeater operation immedi-
ately even while transmitting. May be cancelled by
entering "Repeat Start" command or power the
repeater OFF/ON. This command is not available
during Phone Patch operation.
• TX Start
This command initiates repeater transmit mode for
Phone Patch operation. This command is available
only when the signal is entered via the connected
telephone line.
• TX Stop
This command stops the repeater from transmitting
during Phone Patch operation. This command is
available only when the signal is entered via the
connected telephone line.
• RF Power (Low)
Switches TX power to "Low." This command is not
available during Phone Patch operation.
• RF Power (High)
Switches TX power to "High." This command is not
available for the channel which low power is pro-
grammed by cloning or during Phone Patch opera-
tion.
• RX Unit OFF
Turn OFF the RX unit (front end). This command is
not available from a transceiver or during Phone
Patch operation.
• RX Unit ON
Turn ON the RX unit (front end). This command is
not available from a transceiver or during Phone
Patch operation.
REMOTE CONTROL OPERATION
• TX/RX Unit OFF
Turn OFF the TX/RX units. This command is not
available from a transceiver or during Phone Patch
operation.
• TX/RX Unit ON
Turn ON the TX/RX units. This command is not
available from a transceiver or during Phone Patch
operation.
• Master Enable
Activates the master repeater when connected to a
back up repeater. This command is not available
during Phone Patch operation.
• Slave Enable
Activates the back up repeater when connected to
a master repeater. This command is not available
during Phone Patch operation.
• TEL Dial
Activates the phone line and dials the telephone
number entered as sub code (max. 24 digits).
Command will not activate when the first digit
entered is the same as programmed in "Call
Prohibition." The repeater transmits "NG ACK" sig-
nal. This command is only available from a trans-
ceiver.
• TEL Autodial
Activates the phone line and dials the pre-pro-
grammed autodial channel (2 digits) as sub code.
This command is only available from a transceiver.
• Memory CH Select
Selects the memory channel with sub code (2 dig-
its Memory channel number). This command is not
available during Phone Patch operation.
• CPU All Reset
Resets the repeater's CPU. This command is not
available from a transceiver or during Phone Patch
operation.
