OPERATION EXAMPLE (Continue)
D D Mch Select
(0017 Default)
This command is available from both the transceiv-
er and phone line. This explanation shows the step
by step operation from the transceiver or operation
from the phone line when entering the password and
command continuously (one after the other).
This command cannot be performed while repeater
is transmitting, therefore you must stop the repeater
operation before selecting a different memory chan-
nel.
[From the transceiver]
q Enter the programmed password from the trans-
ceiver.
Code: ∗ 0001#
• Verify the repeater replies "System Password OK
ACK (1111)."
• If the repeater replies "NG ACK (4040)," make sure
the password, header tone and de-limiter tone are
correct, and try again.
w Enter the "Repeat Stop" command within 10 sec.
Code: ∗ 0004#
• Verify the repeater replies "OK ACK (3333)."
• If the 10 sec. input standby time runs out, enter the
password and command continuously (Code:
∗ 0001#0004#
).
e Enter the "Mch Select" command followed by sub
code within 10 sec.
Code: ∗ 0017#07#
(when your intended channel is 07)
• Verify the repeater replies "OK ACK (3333)."
• If the 10 sec. input standby time runs out, enter the
password and command continuously (Code:
∗ 0001#0017#07#
).
• The repeater changes to the memory channel 7.
r Enter the "Repeat Start" command within 10 sec.
Code: ∗ 0003#
• Verify the repeater replies "OK ACK (3333)."
• If the 10 sec. input standby time runs out, enter the
password and command continuously (Code:
∗ 0001#0003#
).
REMOTE CONTROL OPERATION
[From the Phone line]
q Dial the phone number of the phone line that the
repeater is connected to.
w When the connection has been confirmed, enter
the following DTMF code.
Code: ∗ 0001#0004#
• Verify the repeater replies "OK ACK (3333)."
• If the repeater replies "NG ACK (4040)," make sure
the password, header tone, de-limiter tone and
Repeat Stop code are correct, and try again.
e Enter the "Mch Select" command followed by sub
code within 10 sec.
Code: ∗ 0017#07#
(when your intended channel is 07)
• Verify the repeater replies "OK ACK (3333)."
• If the 10 sec. input standby time runs out, enter the
password and command continuously (Code:
∗ 0001#0017#07#
).
• The repeater changes to the memory channel 7.
r Enter the "Repeat Start" command within 10 sec.
Code: ∗ 0003#
• Verify the repeater replies "OK ACK (3333)."
• If the 10 sec. input standby time runs out, enter the
password and command continuously (Code:
∗ 0001#0003#
).
t Hang up the phone, the repeater automatically
disconnects the phone.
