HCE1400A, HCE1400W 50Hz Icemakers
Order parts online
www.follettice.com
Following installation, please forward this manual
to the appropriate operations person.
801 Church Lane • Easton, PA 18040, USA
Toll free (800) 523-9361 • (610) 252-7301
Fax (610) 250-0696 • www.follettice.com
Operation and Service Manual
After Serial Number C20000
00171611R00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCE1400A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Follett HCE1400A

Summary of Contents for Follett HCE1400A

  • Page 1 HCE1400A, HCE1400W 50Hz Icemakers Order parts online Operation and Service Manual www.follettice.com After Serial Number C20000 Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Toll free (800) 523-9361 • (610) 252-7301 Fax (610) 250-0696 •...
  • Page 2 Follett Corporation Equipment Return Policy Follett equipment may be returned for credit under the following conditions: The equipment is new and unused. A return authorization number has been issued by customer service within 30 days after shipment. Follett receives the equipment at the factory in Easton, PA within 30 days after issuance of the return authorization number. The equipment must be returned in Follett packaging.

  • Page 3: Table Of Contents

    Table of contents Welcome to Follett Corporation Specifi cations Operation Cleaning Weekly exterior care Monthly condenser cleaning Semi-annual evaporator cleaning Service Icemaker operation Water system Electrical system Normal control board operation Test points Time delay and self fl ushing jumpers Error faults Hard error Soft errors...

  • Page 4: Welcome To Follett Corporation

    Welcome to Follett Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and outstanding after-the-sale support. To ensure that this equipment delivers the same degree of service, we ask that you review the installation manual (provided as a separate document) before beginning to install the unit. Our instructions are designed to help you achieve a trouble-free installation.

  • Page 5: Specifi Cations

    Specifi cations Electrical Each icemaker requires its own separate circuit with electrical disconnect within 10 ft (6m). Equipment ground required. Standard electrical – 220-240/50/1 Maximum icemaker fuse – 20 amps Amperage – 16 amps Maximum power – 5280 watts Climatic class – N 6 ft (2m) cord provided on icemaker CAUTION •...
  • Page 6 Dimensions and clearances Entire front of icemaker must be clear of obstructions/connections to allow removal. 1" (26mm) clearance above icemaker for service. 1" (26mm) minimum clearance on sides. The intake and exhaust air grilles must provide at least 170 sq in (1098 sq cm) of open area. Air-cooled model HCC1400A icemakers –...

  • Page 7: Operation

    Operation Cleaning and preventive maintenance (all models) Note: Do not use bleach to sanitize or clean the icemaker. Preventive maintenance Periodic cleaning of Follett’s icemaker system is required to ensure peak performance and delivery of clean, sanitary ice. The recommended cleaning procedures that follow should be performed at least as frequently as recommended, and more often if environmental conditions dictate.
  • Page 8 Fig. 2 2. Mix 1 gallon (3.8L) 120˚F (49˚C) water and 7 ounces (198g) (one 7 ounce packet of Follett SafeCLEAN ice machine cleaner, part# 00132001). Locate cleaning cup. Fill until HI WATER light HI WATER comes on (Fig. 2). Note: Do not use bleach to sanitize or clean the icemaker.
  • Page 9 Fig. 5 5. Mix 1 gallon 120˚F (49˚C) water and 1.6 ounces (48ml) NU-CALGON IMS-II SANITIZER. Fill until HI WATER light comes on (Fig. 5). Note: Do not use bleach to sanitize or clean the icemaker. HI WATER Fig. 6 6.
  • Page 10 Fig. 8 8. Disconnect coupling as shown (Fig. 8). Fig. 9 9. Using disposable food service grade gloves, insert dry Sani-Sponge (kit part# 00132068). ™ Next, insert Sani-Sponge soaked in Nu-Calgon IMS-II sanitizer solution. Push both Sani-Sponges down ice transport tube with supplied pusher tube (Fig.
  • Page 11 Fig. 11 11. Reconnect coupling. Press power switch ON. Ice pushes Sani-Sponges through tube (Fig. 11). Fig. 12 12. Place a sanitary (2 gallon or larger) container in bin or dispenser to collect Sani-Sponges and ice for 10 minutes. Collect 5.5 lbs of ice from unit. Discard ice and Sani-Sponges (Fig.

  • Page 12: Service

    Service Icemaker operation (all models) Follett’s icemaker consists of fi ve distinct functional systems covered in detail as follows: • Water system • Electrical control system • Mechanical assembly • Refrigeration system • Bin full The Horizon icemaker overview The Follett Horizon icemaker uses a horizontal, cylindrical evaporator to freeze water on its inner surface. The refrigeration cycle is continuous;...

  • Page 13: Water System

    Water system The water level in the evaporator is controlled by a feed solenoid and level detecting sensors. Referencing the diagram below, water sensing rods extend down into the reservoir at the end of the evaporator assembly. The system works via electrical conductivity as follows: One of the longest probes is a common.

  • Page 14: Electrical System

    Electrical system Normal control board operation The PC board indicator lights provide all the information necessary to determine the machine's status. Green indicator lights generally represent “go” or normal operation; Yellow indicators represent normal off conditions; Red indicators generally represent alarm conditions, some of which will lock the machine off. A green light labeled POWER indicates power to the machine.

  • Page 15: Test Points

    Test points: The Horizon PC board incorporates on-board test points that can be used to determine various electrical outputs. The test point holes allow a standard probe to be inserted for quick voltage measurement. For 208-230 systems, use TP-4 (L2) as the common for testing outputs for solenoids, motors, etc. Error faults: The Horizon PC board monitors various operating parameters including high pressure, auger gearmotor amperage limits, clogged drain, and high and low water alarm conditions.

  • Page 16: Wiring Diagram

    Wiring diagram SNUBBER POWER AUGER REFRIG DELAY TIME CLEANING PURGE SERVICE AMPS PRESS BOARD CONTROL PRESS CLOG DRAIN WATER WATER...

  • Page 17: Compressor Data

    Compressor data Compressor current draw Air-cooled Ambient air temp. 60˚F/16˚C 70˚F/21˚C 80˚F/27˚C 90˚F/32˚C 100˚F/38˚C 6.9A 6.9A 7.0A 7.3A 7.9A Water-cooled Condenser water temp 50˚F/10˚C 60˚F/16˚C 70˚F/21˚C 80˚F/27˚C 90˚F/32˚C 7.4A 7.4A 7.4A 7.5A 7.5A Locked rotor amps 96.8 Gearmotor data Brother Gearmotor current 2.8A (nominal) Locked rotor amps...

  • Page 18: Mechanical System

    Mechanical system Fig. 13 Evaporator disassembly Press PURGE button to purge evaporator, and then turn power OFF. 2. Unscrew and remove stream divider as shown. Fig. 14 3. Unplug and remove gearmotor as shown. 4. Remove all traces of anti-seize compound from the auger shaft.
  • Page 19 Fig. 16 8. Loosen nut on V-band clamp and remove. 9. Remove V-band clamp from front of evaporator. 10. Remove main housing as shown. Fig. 17 11. Remove and discard mating ring and seal. 12. Carefully remove auger.

  • Page 20: Evaporator Reassembly

    Fig. 18 Evaporator reassembly Remove and inspect O ring seal. Discard if damaged in any way. 2. Clean O ring groove. Lubricate O ring and reinstall. Fig. 19 3. Press new mating ring into main housing as shown. 4. Lube the shaft with liquid soap in the area shown Cardboard and slip on seal and spring.
  • Page 21 Fig. 21 6. Orient auger shaft with keyway in the Note: Shuttle housing upward position. removed for clarity Force main housing into position against evaporator and place 1/4" (7mm) diameter Phillips screwdriver into hole in the auger shaft. 8. Replace V-band clamp as shown. 9.
  • Page 22 Fig. 24 17. Insert a bolt into the auger shaft and fi nger tighten. 18. Using a wrench, rotate the shaft clockwise to align the keyways in the gear housing and the shaft so as to accept the key. 19. Insert the key into the keyway. Fig.

  • Page 23: Refrigeration System

    Refrigeration system Refrigerant pressure data Air temperature Air-cooled condensers 60˚F/16˚C 70˚F/21˚C 80˚F/27˚C 90˚F/32˚C 100˚F/38˚C Pressure 208/26psi 238/28psi 270/30psi 306/33psi 346/36psi discharge/suction 1435/180kPa 1641/194kPa 1862/207kPa 2110/228kPa 2386/249kPa 14.35/1.80bar 16.41/19.4bar 18.62/2.07bar 21.10/2.28bar 23.86/2.49bar Water temperature Water-cooled condensers 60˚F/16˚C 70˚F/21˚C 80˚F/27˚C 90˚F/32˚C 100˚F/38˚C Pressure 282/31psi 282/31psi...

  • Page 24: Refrigerant Charge Size

    Recharging icemaker to other than factory specifi cations will void the warranty. R404A icemaker charge specifi cations Model Charge Refrigerant type HCE1400A (air-cooled) 34oz (652g) R404A HCE1400W (water-cooled) 21oz (426g) R404A Refrigerant replacement requirements 1.

  • Page 25: "Bin Full" Detection System

    “Bin full” detection system The Follett Horizon icemaker incorporates a unique “bin full” detection system that consists of the shuttle and actuator. The shuttle incorporates a fl ag and sensor. Referencing the fi gure below, the normal running position of the fl ag is down, out of the sensor. When the bin fi lls to the top and ice can no longer move through the tube, the machine will force the shuttle fl ag up into the sensor, shutting the machine off.

  • Page 26: Troubleshooting

    Troubleshooting Please see “Service” section for a description of each function. Ice machine disposition Possible causes Corrective actions Legend: ON or OFF FLASHING Ice machine is in running 1. Defective compressor. 1. Replace compressor. 2. Defective start relay. condition but not making ice. 2.
  • Page 27 Ice machine disposition Possible causes Corrective actions Legend: ON or OFF FLASHING Ice machine is not making ice. 1. Drain hose kinked or plugged 1. Remove kink or blockage from Drain clog. causing water to back up. drain hose. 2. Improper fl oor drain routing/pitch 2.

  • Page 28: Replacement Parts

    Replacement parts Order parts online www.follettice.com Evaporator assembly...
  • Page 29 Order parts online www.follettice.com Reference # Description Part # Tube, ice transport, molded 00130666 Shuttle assembly (includes 00115600 & 00130666) 00130815 Switch, optical 00130849 Compression nozzle 00115774 Elbow, water 00134502 Gasket, shuttle 00115600 Stream divider 00142521 Auger bolt 00116988 Washer 00161513 Retainer, auger bolt 00161356...
  • Page 30 Air-cooled assembly Order parts online www.follettice.com...
  • Page 31 Order parts online www.follettice.com Reference # Description Part # Condenser (includes 00130922) 00137588 Shroud, condenser 00137596 Fan motor assembly 00121566 Electrical box support 00156035 Cut-out, high pressure safety 00117077 Insulation, bulb, TXV 00106534 Drier 00134593 Valve, expansion, thermal (includes 502830 and 00106534) 00136317 Insulation, TXV 502830...
  • Page 32 Water-cooled assembly Order parts online www.follettice.com...
  • Page 33 Order parts online www.follettice.com Reference # Description Part # Electrical box support 00156035 Elbow, water 00129486 Valve, water regulating 00131052 Union, water 202148 Cut-out, high pressure safety 00117077 Insulation, bulb, TXV 00106534 Drier 00134593 Valve, expansion, thermal (includes 502830 and 00106534) 00130997 Insulation, TXV 502830...
  • Page 34 Electrical box Order parts online www.follettice.com...
  • Page 35 Order parts online www.follettice.com Reference # Description Part # Cover, electrical box, air/water-cooled 00130872 Board, control circuit, 240V (includes 00130906) 00132902 Stand off’s (set of 6) 00130906 Capacitor, compressor run 00133512 Clamp, run capacitor 00133603 Relay, compressor starting (includes wire harness) 00161810 Contactor 00117010...
  • Page 36 Integration kit – top-mount and Satellite-fi ll Order parts online www.follettice.com Top mount configuration Satellite-fill configuration...
  • Page 37 Order parts online www.follettice.com Reference # Description Part # Shuttle actuator 00171322 Clamp 500377 Actuator elbow (includes 00167122 and 209100) 00171264 Screws 209100 Gasket 00167122 Actuator body 00171272 Gasket, coupling 00126532 Ring, locking (includes 00126532) 00171371 Ice transport tube, 10' (3m) 00171280 Ice transport tube, 20' (6m) 00171298...
  • Page 38 Skins assembly Order parts online www.follettice.com Stock Module Identification Plate Stock Module Identification Plate 208264 208264 Module No. Module No. Product Product Service No. Service No.
  • Page 39 Order parts online www.follettice.com Reference # Description Part # Grille, intake 00122846 Front cover, air- & water-cooled (includes 00122846) 00137612 Tubing, water, 1/4" OD 502079 Tubing, drain 00144923 Fitting, drain 00109728 Fitting, water inlet 502924 Elbow, water inlet 502925 Coupling (includes 00144675) 00171207 O ring 00144675...
  • Page 40 801 Church Lane • Easton, PA 18040, USA 00171611R00 Toll free (800) 523-9361 • (610) 252-7301 05/07 Fax (610) 250-0696 • www.follettice.com...
