Features
Horizon Elite
1010 series ‑ up to 1061 lb (482 kg) in 24 hours
1410 series ‑ up to 1466 lb (665 kg) in 24 hours
‑ automatically transport ice through a tube with
RIDE technology from up to 75' (22.8 m) away
®
‑ chewable, compressed nugget ice is preferred
over cubes
1
‑ Chewblet ice dispenses reliably from ice and
beverage dispensers
‑ available with approximately 1.00" (2.54 cm) long
standard Chewblet ice or optional 3/8" (0.95 cm)
long Micro Chewblet
™
‑ quiet production without noisy harvest cycles
Revolutionary, scale inhibiting design
‑ produces ice that has 15% the TDS of the incoming
water for optimum dispensing and long life in drinks
‑ quarantines and regularly expels scale producing
dissolved solids to dramatically reduce scale buildup
‑ increases time between descaling and reduces or
eliminates the need for expensive scale treatment
‑ saves 35% water compared to comparable cubers
‑ meets 2018 Department of Energy regulations
Durable, attractive ice machine
‑ regular bearing inspection or replacement is
not required
‑ upgraded, easy‑to‑read LED operating status and
diagnostic display
Designed with sanitation in mind
‑ Agion silver‑based antimicrobial product protection
®
of key ice and water contact components2
‑ floatless, sealed design inhibits formation of biofilms
‑ semi‑automatic cleaning and sanitizing system
Warranty
‑ 3 years parts and labor, 5 years compressor parts
Certifications
1 Independent third party studies. Contact Follett for details.
2 Disclaimer: Antimicrobial protection is limited to the treated components and does not treat water or ice.
Job
Item
ice
self-contained 1010, 1410 series Chewblet® ice machine
Short form specification:
Ice machine to be a Follett
______________ [Insert size/series, condenser type and installation/mounting,
from model number guide] capable of producing compressed nugget ice using
an efficient, sanitary horizontal evaporator/auger system and delivering ice by
a flexible wire reinforced transport tube to
dispenser, ice and beverage dispenser, drop‑in dispenser or Ice Manager
diverter valve system, slide‑out compressor/condenser/evaporator with utility
docking station, front‑mounted unit status display, evaporator water inlet at
harvest end with automatic flush while producing ice, and semi‑automatic
cleaning and sanitizing system, plus all the features listed below and mounting/
performance‑enhancing accessories checked.
Model configurations
Install/
For use with mount
1
top
mount
ice storage bin
RIDE
Follett Vision
™
undercounter
RIDE
ice & beverage
dispenser
Cornelius PR150
undercounter ice & RIDE
beverage dispenser
2
top
mount
countertop
ice & beverage
dispenser
(by others)
RIDE
drop-in dispenser
RIDE
(by others)
Ice Manager diverter
RIDE
valve system
Ordered separately.
1
Not compatible with Micro Chewblet ice.
2
Requires top kit (see page 4 for item number).
3
For Micro Chewblet ice, replace second character (C) with an M e.g. HMC1010ABT.
4
801 Church Lane | Easton, PA 18040, USA
1.800.523.9361 | 1.610.252.7301 | follettice.com
Horizon Elite
Horizon Elite ice machine model
®
ice storage bin, ice and water
Item number
Condenser V/Hz/Ph 1010 series
208-230/60/1 HCC1010ABT HCC1410ABT
air
230/50/1 HCE1010ABT HCE1410ABT
208-230/60/1 HCC1010WBT HCC1410WBT
water
230/50/1 HCE1010WBT HCE1410WBT
208-230/60/1 HCC1010ABS HCC1410ABS
air
230/50/1 HCE1010ABS HCE1410ABS
208-230/60/1 HCC1010WBS HCC1410WBS
water
230/50/1 HCE1010WBS HCE1410WBS
208-230/60/1 HCC1010AVS HCC1410AVS
air
230/50/1 HCE1010AVS HCE1410AVS
208-230/60/1 HCC1010WVS HCC1410WVS
water
230/50/1 HCE1010WVS HCE1410WVS
air 208-230/60/1 HCC1010APS HCC1410APS
water 208-230/60/1 HCC1010WPS HCC1410WPS
208-230/60/1 HCC1010AHT HCC1410AHT
air
230/50/1 HCE1010AHT HCE1410AHT
3
208-230/60/1 HCC1010WHT HCC1410WHT
water
230/50/1 HCE1010WHT HCE1410WHT
208-230/60/1 HCC1010AHS HCC1410AHS
air
230/50/1 HCE1010AHS HCE1410AHS
208-230/60/1 HCC1010WHS HCC1410WHS
water
230/50/1 HCE1010WHS HCE1410WHS
208-230/60/1 HCC1010AJS
air
230/50/1 HCE1010AJS
208-230/60/1 HCC1010WJS HCC1410WJS
water
230/50/1 HCE1010WJS HCE1410WJS
air 208-230/60/1 HCC1010AMS HCC1410AMS
water 220/60/1 HCC1010WMS HCC1410WMS
™
™
Item number
4 4
1410 series
HCC1410AJS
HCE1410AJS
