Start the Installation

To start the installation:
1. Turn off power to the computer and to the monitor.
2. Open the computer to gain access to the PCI expansion slots.
3. If your computer has an installed graphics accelerator, remove it.
If your computer has a graphics accelerator integrated onto the
system board, disable it.
4. Select the PCI expansion slots into which you will install the
boards. Select one open PCI slot for one Graphics Accelerator, or
two open PCI slots for two Graphics Accelerators (to provide
dual-screen capability).
5. Remove the slot covers from the selected PCI slots. Retain the
screws from the slot covers; you will use them to secure the boards
to the computer's chassis.

Install the Boards

To install a Graphics Accelerator board:
1. Align the board with the PCI expansion slot, making sure the
gold-fingered connectors on the board's edge are aligned properly
with the slot connector.
2. Push the board into the slot firmly and evenly until it is fully
seated in the slot connector.
3. Visually inspect the connection. If it does not appear to be
correct, remove and re-install the board.
4. Use the screws you removed previously to secure the board to the
computer's chassis.

Finish the Installation

To finish the installation:
1. Close the computer.
2. Connect the computer monitor's video cable to the blue video
output port on the Graphics Accelerator. Refer to the following
figure.
