Overview

The Kramer VP-727A is a high performance 8x2 audio switcher for
unbalanced stereo audio signals. It switches any input to either the preview or
program output. The VP-727A is an audio companion switcher for the
VP-727xl Universal Presentation Matrix Switcher / Scaler and the VP-727
Universal Presentation Matrix Switcher / Scaler, and operates in conjunction
with them and the VP-727T Presentation Switcher Control Panel.
The VP-727A features:
Eight unbalanced stereo audio inputs on RCA connectors
Three program outputs: unbalanced stereo audio, balanced stereo audio and
S/PDIF
One unbalanced stereo audio preview output
A selectable headphone connector for preview or program audio outputs
A front panel lockout
A TAKE button for executing preview to program switching (with
transition effects)
An audio-follow-video button when operating in conjunction with the
VP-727xl or the VP-727
Fade to mute audio switching
Separate mute buttons for the preview and program channels
Bass, treble and balance audio controls
Audio delay for each input channel
You can control the VP-727A via the front panel buttons and/or RS-232.
Achieving the best performance means:
Connecting only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables)
Avoiding interference from neighboring electrical appliances, making sure
not to block the ventilation holes, and positioning your VP-727A away
from moisture, excessive sunlight and dust
4

Your VP-727A Audio Switcher

Figure 1 and Table 1 define the front panel of the VP-727A:
