12. If required, disconnect the RS-232 rear panel port on the VP-727A unit
from the Null-modem adapter.
13. Slide the underside PROGRAM switch to the right (see section 4.1).
14. Connect the power to the VP-727A.
Upon initialization, the new VP-727A software version shows in the
STATUS 7-segment Display.
8

Technical Specifications

Table 3 includes the technical specifications:
Table 3: Technical Specifications
INPUTS:
OUTPUTS:
MAX. OUTPUT LEVEL:
BANDWIDTH (-3dB):
S/N RATIO:
CROSSTALK @1kHz
(all hostile):
CONTROLS:
COUPLING:
AUDIO THD + NOISE:
AUDIO 2nd HARMONIC:
POWER SOURCE:
DIMENSIONS:
WEIGHT:
ACCESSORIES:
1 Specifications are subject to change without notice
2 Check for the latest version on our Web site at http://www.kramerelectronics.com
Technical Specifications
8 unbalanced stereo on RCA connectors
1 Program and 1 Preview stereo unbalanced outputs on RCA connectors
1 Program balanced output on a 5-pin terminal block connector
1 Headphone output on a 6.5mm jack
1 Program S/PDIF output on an RCA connector
>4.5Vpp
>22kHz
>85dB
Program: <-88dB
Preview: <-92dB
Balanced: <-88dB
Phones (Preview): <-82dB
Phones (Program): <-80dB
Preview level: <-72dB to 62dB in and out
Program level: <-73dB to 45dB in and out
Program bass: 0dB to 27dB @100kHz
Program treble: 0dB to 11dB @10kHz
Program balance: -18dB to 0dB
Program balanced (+/-) level: <-80db to 47dB
Phones level (preview and program level): <-80dB to 57dB
AC, input and output
Program: 0.02%; Preview: 0.002%;
Program phones: 0.034%; Preview phones: 0.018%
Preview phones: 0.03%; Program phones: 0.04%; Program: 0.03%; Preview:
0.04%; Program balanced: 0.04%
100-240 VAC, 50/60 Hz; 10VA
19-inch (W), 7-inch (D) 1U (H) rack-mountable
2.7kg (6lbs.) approx.
Power cord, Null modem adapter, Windows®-based Kramer control
2
software
1
of the VP-727A Audio Switcher
