Advantech TPC-1570H User Manual

Touch panel computer with high luminance 15" xga tft lcd
Hide thumbs
Table of Contents

Advertisement

Quick Links

TPC-1570H
Touch Panel Computer with High
Luminance 15" XGA TFT LCD

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPC-1570H and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech TPC-1570H

Summary of Contents for Advantech TPC-1570H

  • Page 1: User Manual

    TPC-1570H Touch Panel Computer with High Luminance 15" XGA TFT LCD User Manual...
  • Page 2 No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reli- able.
  • Page 3 Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or...

  • Page 4: Declaration Of Conformity

    This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
  • Page 5 Safety Instructions Read these safety instructions carefully. Keep this User's Manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for clean- ing. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
  • Page 6 The sound pressure level at the operator's position according to IEC 704- 1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. TPC-1570H User Manual...

  • Page 7: Table Of Contents

    Advantech COM Driver Installation ....... 22 Watchdog Timer (WDT) Driver Installation ....32 4.3.1 Installing the TPC-1570 Watchdog Timer Driver ..33 4.3.2 How to Use the TPC-1570H Watchdog Timer .... 38 Dual Display Setting ............41 Table of Contents...
  • Page 8 Figure E.8:Fastening the HDD cover ......77 Figure E.9:Chamfer ............. 78 Figure E.10:Chamfer & Rubber ........78 Figure E.11:Sliding the HDD Into Position ....79 Figure E.12:Completed HDD Installation ....79 Figure E.13:Mounting the Rubber Cushions ....80 TPC-1570H User Manual viii...
  • Page 9 Figure E.14:Fastening the HDD Module ..... 80 Figure E.15:Reinstalling the Rear Cover ..... 81 Appendix F Touchscreen Installation & Configuration. 84 Driver Installation ............84 Figure F.1:Setup.exe ............ 84 Figure F.2:Install - Wizard .......... 84 Figure F.3:Install – License Agreement ...... 85 Figure F.4:Install –...
  • Page 10 TPC-1570H User Manual...
  • Page 11 General Information Sections include: • Introduction • Specifications...

  • Page 12: Chapter 1 General Information

    South Bridge: Intel 855GME/ 852GM GMCH/ICH4 chipset VGA: Intel 855GME for TPC-1570H-P2AE, C1AE series; Intel 852GM for TPC-1570H-B1AE series; Support 16 MB frame buffer with system memory; Simultaneously support of CRT and LVDS flat panel display. Ethernet: Intel 82562EZ and Intel 82551QM Ethernet controller; IEEE 802.3u protocol compatible...

  • Page 13: I/O Ports

    1.2.2 I/O Ports 1 parallel port: supports EPP/ ECP/SPP modes 3 serial ports: RS-232 (COM1, COM3) and RS-232/422/485 (COM4, default is RS-485) 2 RJ-45 Ethernet port: TPC-1570H-P2AE/C1AE: LAN 1 (10/100BaseT) LAN2 (10/100/1000BaseT) TPC-1570H-B1AE: LAN 1 (10/100BaseT); LAN2 (10/100BaseT) 1 PS/2 port: 6-pin mini-DIN ports for keyboard and mouse 2 USB ports: compliant with USB 2.0...

  • Page 14: Lcd Specifications

    50,000 hours Backlight Life Time Note There might be several bright or dark pixels on the LCD. This comes from the production of the LCD. Such phenomenon is claimed to be normal accord- ing to the LCD manufacturers. TPC-1570H User Manual...

  • Page 15: Touchscreen Specifications

    1.4 Touchscreen Specifications Resistive Touchscreen Type Tempered Glass Base Glass Construction 1024 x 1024 Resolution 75% typical Light Transmission RS232 Interface Controller 3.3 to 5V Power Rating 1 million touches Durability 1.5 Power Input voltage: 18 ~ 32 Vdc (the fuse will be open circuit as input level exceeds 33Vdc) Typical: 24V@2.4 (57W) 1.6 I/O Port Arrangement...

  • Page 16: Panel Mounting

    1. There is a piece of adhesive waterproof gasket on the Mg-AL front bezel. Make sure the waterproof gasket is in position before installing the TPC-1570H to the panel opening. 2. Install the TPC-1570H to the panel opening. 3. Find out the eight clampers and eight long screws in the accessory pack.

  • Page 17: Exploded Diagram

    1.8 Exploded Diagram Figure 1.3: Exploded Diagram 1.9 Dimensions and cutout Weight: 5 Kg (without HDD) Dimensions: 383 x 307 x 64.5 mm (WxHxD) Cutout: 374.5 x 298.5 mm (suggested) Chapter 1...

  • Page 18: Figure 1.4:Dimensions

    Figure 1.4: Dimensions TPC-1570H User Manual...
  • Page 19 System Setup...

  • Page 20: Figure 2.1:Unpack The Package

    Chapter 2 System Setup This chapter provides a brief explanation for operating the TPC-1570H. It is easy to make the TPC-1570H start working with the below step-by- step. Step 1: Unpack the TPC-1570H package. Please check the packing list at the beginning of this manual.

  • Page 21: Figure 2.2:Install Compactflash Memory Card

    Figure 2.2: Install CompactFlash memory card Warning It is suggested to turn OFF system power as plug in or pull out the memory card, though the Compact- Flash memory is supposed to be hot swappable. Step 3: Connect the power connector to the 24VDC power lines. The power lines can either be of some power adapter or in-house power source.

  • Page 22: Figure 2.3:Power Connector

    Step 5: Push the power button to power on the system as the figure 2.4. Step 6: Calibrate the touchscreen. Please go to “Start” ”Programs” ”PenMount DMC9000 Utilities”->”Control Panel” as the figure 2.5. Then, click the tab “Calibrate” to calibrate by selecting the standard calibration or advanced calibration. TPC-1570H User Manual...

  • Page 23: Figure 2.5:Touchscreen Calibration - 1

    If your operating system is Windows CE, the details of the procedure are described in following section. Figure 2.5: Touchscreen Calibration - 1 Figure 2.6: Touchscreen Calibration - 2 Chapter 2...
  • Page 24 TPC-1570H User Manual...
  • Page 25 System Engine...

  • Page 26: Chapter 3 System Engine

    Serial port:COM1 RS232 COM3 COM3 Serial port:COM3 RS232 COM4 COM4 Serial port:COM4 RS232/422/485 COM4 MODE1 Setting COM4 RS232/422/485 mode COM4 MODE2 Setting COM4 RS422 Master or Slave mode CLEAR CMOS CLEAR CMOS POWER SWITCH System Power Switch TPC-1570H User Manual...

  • Page 27: Figure 3.1:Main Board Connector -1

    Figure 3.1: Main Board Connector -1 Figure 3.2: Main Board Connector -2 Chapter 3...
  • Page 28 TPC-1570H User Manual...
  • Page 29 Software Configuration Sections include: • Utilities & Drivers • Advantech COM Driver Installation • Watchdog Timer Driver Installation • Dual Display Setting...

  • Page 30: Chapter 4 Software Configuration

    Chapter 4 Software Configuration A support CD-ROM for TPC-1570H is available and along with the prod- uct. There are related utilities and drivers for TPC-1570H included. Please install the Chipset INF driver, VGA graphics driver, LAN driver, audio driver, Advantech.com driver, Touchscreen driver and Watchdog Timer (WDT) driver sequentially.

  • Page 31: Audio Driver

    • Microsoft Windows 98 SE • Microsoft Windows 2000 • Microsoft Windows XP 4.1.5 Advantech COM Driver Path: \ Advantech com \ Available for the OS’s below: • Microsoft Windows 98 SE • Microsoft Windows 2000 • Microsoft Windows XP 4.1.6 Touchscreen Driver...

  • Page 32: Advantech Com Driver Installation

    4.2 Advantech COM Driver Installation A com port named COM3 or COM4 on TPC-1570 is Advantech Special com port. Please follow the steps below to install the driver. Step 1: Insert the companion CD-ROM into your CD-ROM drive. Open the directory: \ advantech com\...
  • Page 33 Step 2: Use Windows Explorer (or Windows Run command) to execute PCI_ICOM.EXE from the companion CD-ROM. Step 3: Click Next to continue installation. Chapter 4...
  • Page 34 Step 4: Click Next to continue installation. TPC-1570H User Manual...
  • Page 35 Step 5: Click uninstall icon to remove ?PCI Serial Port Chapter 4...
  • Page 36 Step 6: Click the scan for hardware changes icon to remove ?PCI Serial Port TPC-1570H User Manual...
  • Page 37 Chapter 4...
  • Page 38 Step 7: Found New Hardware and Click Next to continue installation. Step 8: Click Finish the Advantech PCI Serial Port to continue. TPC-1570H User Manual...
  • Page 39 Step 9: Then, found New Hardware and Click Next to continue. Step 10: Click Finish the Advantech PCI-1602 Serial SlaveBridge to continue installation. Chapter 4...
  • Page 40 Step 11: Found New Hardware and Click Next to continue installation. TPC-1570H User Manual...
  • Page 41 Step 12: Click Finish the Advantech PCI Serial Port to continue. Chapter 4...

  • Page 42: Watchdog Timer (Wdt) Driver Installation

    4.3 Watchdog Timer (WDT) Driver Installation In order to ensure reliable and fail-safe performance, TPC-1570H has a built-in Watchdog Timer to handle unexpected system failures. TPC- 1570H provides the drivers and a utility to activate and configure the timer for Windows2000/XP operating systems. The following is a brief introduction, using Windows2000 as an example, for the installation and configuration procedures.

  • Page 43: Installing The Tpc-1570 Watchdog Timer Driver

    4.3.1 Installing the TPC-1570 Watchdog Timer Driver Step 1: Insert the companion CD-ROM into your CD-ROM drive. Open the directory: \WDT\8362x\W2K_XP. Step 2: Use Windows Explorer (or Windows Run command) to execute SETUP.EXE from the companion CD-ROM. Chapter 4...
  • Page 44 Step 3: Click Next to proceed. TPC-1570H User Manual...
  • Page 45 Step 4: Click Next to confirm the customer information. Step 5: Select Advantech [W83627HF] Watchdog Timer and click Next. Chapter 4...
  • Page 46 Step 6: Click Next to confirm selecting the Typical setup type. Step 7: Click Next to proceed. TPC-1570H User Manual...
  • Page 47 Step 8: Click Finish to complete the procedure. Step 9: Click OK to restart the system and activate the Watchdog Timer. Chapter 4...

  • Page 48: How To Use The Tpc-1570H Watchdog Timer

    4.3.2 How to Use the TPC-1570H Watchdog Timer Step 1: Open the Control Panel and click Watchdog Service Configuration. Step 2: Click the Start Service button. TPC-1570H User Manual...
  • Page 49 Step 3: Click Setting to select the setting page. Step 4: Select the Timer Span that meets your application requirement. Chapter 4...
  • Page 50 Step 6: Check the Start watchdog service on boot to enable the Watchdog timer to start automatically after the system boots every time. Step 7: Click OK, then the configuration procedure is finished. Note Use Advantech WDT Driver.WDT was enable,and WDT LED was 1Hz glisten. TPC-1570H User Manual...

  • Page 51: Dual Display Setting

    4.4 Dual Display Setting If you use CRT monitor, you must Connections to CRT port in during system boot up. During system boot up, the system will set CRT parame- ter. If you have multiple devices, you can set them. Step 1: Click Intel graphic icon from the toolbars Step 2: Select Graphics Options ->...
  • Page 52 TPC-1570H User Manual...
  • Page 53 Windows XP Embedded Sections include: • EWF • HORM • Advantech Utilities...

  • Page 54: Chapter 5 Windows Xp Embedded

    Chapter 5 Windows XP Embedded TPC-1570H is in support of embedded windows platform. This section is to state the important features, EWF and HORN, provided in windows XP embedded. 5.1 EWF EWF stands for Enhanced Write Filter. It provides an upper filter in the storage device driver stack that redirects disk write operations to volatile (RAM) or non-volatile (disk) storage.

  • Page 55: Advantech Utilities

    In other words, the hibernation file is 512MB that is the same as memory size used on TPC-1570H-A1 or TPC-1570H-B1. 5.3 Advantech Utilities TPC-1570H provides the useful utilities for users to configure the HORM and EWF. 5.3.1 Version Information Start menu->...

  • Page 56: Horm

    5.3.3 HORM This is to create HORM environment. Please go to Start Menu-> All Pro- grams-> Advantech. This utility firstly dismounts all local physical vol- umes that are not protected by EWF. It requires users to input the volume list.
  • Page 57 Serial Port Settings...

  • Page 58: Appendix A Serial Port Settings

    NRTS NCTS A.2 COM4 Setting The serial port COM4 on the TPC-1570H is adjustable. It can be set to RS-232, RS-422 or RS-485. This port is designed with auto data flow control capability. In other word, the TPC-1570H can automatically detect the data flow direction at this port when the two wired RS-485 communication is activated.
  • Page 59 Note: The black square is dip direction. COM4 Mode S1 and S2 setting RS-232 Mode RS-485 Mode RS-422 Master Mode RS-422 Slave Mode Appendix A...
  • Page 60 RS-232 RS-422 RS-485 NDCD NDTR NDSR NRTS NCTS TPC-1570H User Manual...
  • Page 61 Watchdog Timer on WinCE 5.0...

  • Page 62: Appendix B Watchdog Timer On Wince

    Appendix B Watchdog Timer on WinCE There is a built-in Watchdog timer on Windows CE 5.0 for TPC-1570H. You can access it through WIN32 API. TPC-1570H provides a WDT driver to allow users to enable/disable the Watchdog timer. The driver name is “WDT1:”.
  • Page 63 control codes can then be advertised, and an application can use these control codes with DeviceIoControl to perform driverspecific functions. lpInBuffer [in] Long pointer to a buffer that contains the data required to perform the operation. This parameter can be NULL if the dwIoControlCode parame- ter specifies an operation that does not require input data.

  • Page 64: How To Use The Control Code

    WDT driver, your application must trigger the Watchdog once during the Watchdog timer period. If your application has not triggered at the specified period, the device will reboot automatically. lpInBuffer: unused. nInBufferSize: unused. lpOutBuffer: unused. nOutBufferSize: unused. TPC-1570H User Manual...
  • Page 65 IOCTL_WDT_GETTIMEOUT: Gets the Watchdog time setting. lpInBuffer: unused. nInBufferSize: unused. lpOutBuffer: The DWORD pointer to your Watchdog time setting. The Watchdog time setting is just a number. 0 means 2 seconds, 1 means 5 seconds, 2 means 10 seconds, 3 means 15 seconds, 4 means 30 seconds, 5 means 45 seconds and 6 means 60 seconds.

  • Page 66: Examples

    // assign the WDT driver name wsprintf(szClassName, TEXT("WDT1:")); // Open the WDT driver m_hWDT = CreateFile(szClassName, GENERIC_READ GENERIC_WRITE, 0, NULL, OPEN_EXISTING, FILE_ATTRIBUTE_NORMAL, NULL); if ( m_hWDT == INVALID_HANDLE_VALUE ) { DebugMsg(CString("WDT driver fail")); return; DWORD dwTemp; DWORD nIndex=2; TPC-1570H User Manual...
  • Page 67 // Set the Watchdog Timer as 10 seconds. Number 2 means 10 seconds. DeviceIoControl(m_hWDT, IOCTL_WDT_SET_TIMEOUT, &nIndex, sizeof(nIndex), NULL, 0, &dwTemp, NULL); // Enable the Watchdog timer DeviceIoControl(m_hWDT, IOCTL_WDT_ENABLE, NULL, 0, NULL, 0, &dwTemp, NULL); While (1) { // do your job here. Sleep(8000);...
  • Page 68 TPC-1570H User Manual...
  • Page 69 Watchdog Timer Programming...

  • Page 70: Appendix C Watchdog Timer Programming

    Appendix C Watchdog Timer Programming C.1 Overview The TPC-1570H cards’ watchdog timer can be used to monitor system software operation and take corrective action if the software fails to func- tion after the programmed period. This section describes the operation of the watchdog timer, and how to program it.

  • Page 71: Watchdog Timer Programming

    C.2 Watchdog Timer Programming The I/O port address of the watchdog timer is 2E(hex) and 2F(hex), 2E (hex) is the address port. 2F(hex) is the data port. You must first assign the address of register by writing address value into address port 2E(hex), then write/read data to/from the assigned register through data port 2F (hex).

  • Page 72: Table C.1:Watchdog Timer Registers

    0. [default=0] Bit 4: Read status of watchdog timer, 1 means timer is "time out". AA (hex) ----- Write this address to I/O port 2E (hex) to lock the watchdog timer.2 TPC-1570H Series User Manual...

  • Page 73: Example Programs

    C.3 Example Programs 1. Enable watchdog timer and set 10 sec. as timeout interval ;----------------------------------------------------------- Mov dx,2eh ; Unlock W83627HF Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ;...
  • Page 74 Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Set minute as counting unit Mov al,0f5h TPC-1570H Series User Manual...
  • Page 75 Out dx,al Inc dx In al,dx Or al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 5 minutes and start counting Mov al,0f6h Out dx,al Inc dx Mov al,5 Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al 3.
  • Page 76 4. Enable watchdog timer to be reset by keyboard ;----------------------------------------------------------- Mov dx,2eh ; unlock W83627H Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- TPC-1570H Series User Manual...
  • Page 77 Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable watchdog timer to be strobed reset by keyboard Mov al,0f7h Out dx,al Inc dx In al,dx Or al,40h Out dx,al ;-----------------------------------------------------------...
  • Page 78 Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register Inc dx In al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al TPC-1570H Series User Manual...

  • Page 79: Accessory Kit

    Accessory Kit Assembly This appendix shows how to connect to a CD-ROM via the CompactFlash slot.:...

  • Page 80: Appendix D Accessory Kit Assembly

    Please follow this assembly procedure to use the CompactFlash slot to connect with a CD-ROM drive. Connect the IDE cable to the adapter board. Figure D.1: Adapter Board and IDE Cable Figure D.2: Connecting Adapter Board & IDE Cable TPC-1570H User Manual...

  • Page 81: Figure D.3:Compactflash Slot

    Note Pin 1 is marked red Insert the adapter board into the CompactFlash slot. Figure D.3: CompactFlash Slot Figure D.4: Insert the Adapter Board into the CF slot Figure D.5: Inserted Adapter Board Appendix D...

  • Page 82: Figure D.6:Connect The Cd-Rom Via The Ide Cable

    Note Please make sure Windows 2000 Service Pack 4 is installed before you install the USB 2.0 driver on Windows 2000. Service Pack 1 must be installed on Windows XP before you install the USB 2.0 driver. TPC-1570H User Manual...
  • Page 83 HDD Kit Assembly...

  • Page 84: Appendix E Hdd Kit Assembly

    Please follow the assembly procedure to install the HDD into the system. Remove the rear cover. Figure E.1: Removing the Rear Cover De-assemble the HDD kit from the system. Please remove the two screws and take the transparent rubber cushion off.. Figure E.2: Removing the Top Screws TPC-1570H User Manual...

  • Page 85: Figure E.3:Removing The Hdd Kit

    Figure E.3: Removing the HDD kit Pull out the HDD kit from the system Figure E.4: Pulling out the HDD bracket Appendix E...

  • Page 86: Figure E.5:The Hdd Bracket

    Figure E.5: The HDD Bracket Put the HDD into the HDD holder. Figure E.6: Installing the HDDr TPC-1570H User Manual...

  • Page 87: Figure E.7:Linking The Hdd With The Connector

    Link the HDD with the HDD cable connector and fasten the HDD module with the screws. Figure E.7: Linking the HDD with the Connector Fasten the HDD cover with screws Figure E.8: Fastening the HDD cover Appendix E...

  • Page 88: Figure E.9:Chamfer

    Place the HDD kit into the system: Align to the HDD chamfer as shown the below in red circle and then slide the HDD module into the system sideways. Figure E.9: Chamfer Figure E.10: Chamfer & Rubber TPC-1570H User Manual...

  • Page 89: Figure E.11:Sliding The Hdd Into Position

    Figure E.11: Sliding the HDD Into Position Figure E.12: Completed HDD Installation Appendix E...

  • Page 90: Figure E.13:Mounting The Rubber Cushions

    Mount the two rubber cushions on the HDD kit and fasten the HDD kit with the system by screws Figure E.13: Mounting the Rubber Cushions Figure E.14: Fastening the HDD Module TPC-1570H User Manual...

  • Page 91: Figure E.15:Reinstalling The Rear Cover

    Place the rear cover back into position. Figure E.15: Reinstalling the Rear Cover Note: SATA HDDs only support data transfer rates of SATA 1 (1.5Gbits/sec), if your HDD is SATA 2 (3.0Gbits/sec) please adjust the jumper to 1.5Gbits/sec Appendix E...
  • Page 92 TPC-1570H User Manual...
  • Page 93 Touchscreen Installation & Configuration This appedix demonstrates how to install the PenMount 9000 touchscreen and set the configuration on TPC- 1260H. This section uses Windows XP as an example.

  • Page 94: F.1 Driver Installation

    Configuration F.1 Driver Installation Please insert the x86 TPC series support CD and go to the Windows 2000-XP driver folder (TPC-1570H\Driver\Touch Screen\Driver\Win- dows 2000-XP Driver V4.01). Click setup.exe Figure F.1: Setup.exe The screen displays the installation wizard for the PenMount software.

  • Page 95: Figure F.3:Install – License Agreement

    Figure F.3: Install – License Agreement Figure F.4: Install – Completed Appendix F...

  • Page 96: F.2 Uninstall The Driver

    F.2 Uninstall the Driver Please go to Settings and then select Control Panel. Please click Add/ Remove Programs. Figure F.5: Uninstall -1 Select PenMount DMC9000 and DMC9100. Click Remove button. Figure F.6: Uninstall -2 TPC-1570H User Manual...

  • Page 97: Figure F.7:Uninstall -3

    Mount Control Panel. It contains six functions: Calibrate, Draw, Multiple Monitors, Option, and About. Multiple Monitors is for multiple displays only; however TPC-1570H only provides one touchscreen display. This function is not workable on TPC-1570H. About is to show the driver ver- sion. Calibrate Two ways to calibrate the touch screen include “Standard Calibration”...

  • Page 98: Figure F.8:Standard Calibration -1

    Figure F.8: Standard Calibration -1 Figure F.9: Standard Calibration -2 TPC-1570H User Manual...

  • Page 99: Figure F.10:Standard Calibration -3

    Figure F.10: Standard Calibration -3 Note Touch the red squares in sequence. The cali- bration is completed after the fifth touch red point is calibrated. Press “ESC” to skip. Advanced Calibration is for the aged touchscreens by using 4, 9, 16 or 25 points to calibrate touch panel.

  • Page 100: Figure F.11:Advanced Calibration -1

    Figure F.11: Advanced Calibration -1 Figure F.12: Advanced Calibration -2 TPC-1570H User Manual...

  • Page 101: Figure F.13:Plot Calibration Data

    Figure F.13: Plot Calibration Data Note Plot Calibration Data enabled provides the blue lines to show linearity before calibration and black lines to show linearity after calibration when you finished the advanced calibration. Draw This is to test the touch screen operation. Its display shows touch loca- tion.

  • Page 102: Figure F.14:Draw

    Figure F.14: Draw Click “menu” and then click “clear screen” to clear the drawing. Figure F.15: Clear Screen TPC-1570H User Manual...

  • Page 103: Figure F.16:Option

    Option This option is to set the operation mode and beep sounds if the beep sound is enabled. The operation mode, stream mode and point mode, is to enable/ disable the mouse’s ability to drag on-screen icons. Stream mode let the mouse functions as normal and dragging on-screen. Point mode is only let the mouse a click function.
  • Page 104 TPC-1570H User Manual...
  • Page 105 Fuse Specifications...

  • Page 106: G.1 Fuse Specifications

    Step 2: Replace the damaged fuse with a new one Step 3: Place the fuse cover back in position Figure G.1: Fuse Replacement Warning Do NOT replace the fuse unless it is damaged. Do NOT replace the fuse with a different rating. TPC-1570H User Manual...
