Summary of Contents for Advantech TPC 51T-E Series
- Page 1 User Manual TPC-XX51T-EXXX TPC-XX51H-EXXX TPC-1751T-JXXX Industrial Touch Panel Computers with ® Intel Atom™ Processors...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 4 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
- Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 6 Caution! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dis- pose of used batteries according to the manufacturer's instructions. Attention! Danger d'explosion si la pile est remplacée de façon incor- recte.
-
Page 7: Table Of Contents
Chapter General Information ......1 Introduction ....................2 Specifications .................... 2 1.2.1 System Kernel................2 1.2.2 I/O Ports..................2 1.2.3 O/S support................... 2 1.2.4 Safety and Environment..............3 LCD Specifications..................3 Touchscreen Specifications ..............4 Power ......................4 I/O Port Arrangement ................4 Figure 1.1 I/O Port Arrangement .......... - Page 8 Intel® Trusted Execution Engine Driver Installation........ 46 Windows 7 USB 3.0 Driver Installation ........... 50 Advantech EC Driver Installation ............53 Advantech EC Brightness Control Tool Installation ........ 55 Advantech EC Watchdog Timer Driver Installation......... 57 Advantech LMsensor Driver Installation ..........61...
-
Page 9: Chapter 1 General Information
Chapter General Information... -
Page 10: Introduction
Introduction The TPC-XX51T/H Touch Panel Computer is a state-of-the-art Human Machine Inter- face featuring displays ranging from 5.7” to 17” and Intel Atom™ E3827 1.75 GHz / Intel® Celeron J1900 2 GHz Quad-core Processor. The key features are as follows: ... -
Page 11: Safety And Environment
1.2.4 Safety and Environment Safety FCC Class A CE certificated The front bezel is compliant with IP66 for true flat models and IP65 for the TPCs with the traditional front bezel Environment Operating Temperature: – -20 ~ 60°C (-4 ~ 140°F) TPC-1751T-J: 0~55°C ... -
Page 12: Touchscreen Specifications
Touchscreen Specifications Touch Type: 5- wire Resistive Base Glass Construction: Tempered glass Resolution: (follows the resolution of the system) Light Transmission: 80% ± 3% (Measured by BYK-Gardner) Controller: USB Interface Lifespan: 1 million touches at single point Note! Touchscreen ITO maybe crash duo to heavy usage. -
Page 13: Dimensions And Cutout
Dimensions and Cutout TPC-1751T Series Weight: 4 kg Dimensions (W x H x D): 410.4 x 343.4 x 61.9 mm (16.16" x 13.52" x 2.44") Cutout: 401.3 x 334.8 mm (15.80" x 13.18") TPC-1751H Series Weight: 4 kg Dimensions (W x H x D): 413.7 x 347.2 x 63.8 (16.28"... - Page 14 272.9/ 272.5 343.4/ 347.2 333.4/ 333.3 Figure 1.2 TPC-1751T/1751H Dimensions TPC-XX51T/H-E Series User Manual...
- Page 15 Figure 1.3 TPC-1551T Dimensions TPC-XX51T/H-E Series User Manual...
- Page 16 Figure 1.4 TPC-1251T Dimensions TPC-XX51T/H-E Series User Manual...
- Page 17 Figure 1.5 TPC-651T Dimensions TPC-XX51T/H-E Series User Manual...
- Page 18 Figure 1.6 TPC-651H Dimensions TPC-XX51T/H-E Series User Manual...
-
Page 19: Chapter 2 System Setup
Chapter System Setup... -
Page 20: Transport And Unpacking
Transport and Unpacking When accepting a delivery, please check the packaging for visible transport damage and check the delivery for completeness by comparing it with your order. If you notice any shipping damage or inconsistencies between the contents and your order, please inform the responsible delivery service immediately. -
Page 21: System Setup
System Setup You can easily get TPC started by following the below steps. Unpack the TPC package. Check the packing list at the beginning of this manual to make sure all items have been included. Figure 2.1 Unpack the Package TPC-XX51T/H-E Series User Manual... - Page 22 ® Install a CFast card containing the operating system. Figure 2.2 Install CFast Memory Card (The Mylar in the accessory box can be attached to the CFast card for easy extraction) Warning! It is suggested turning OFF the system power to plug in or pull out the memory card, even though the CompactFlash memory is hot swappa- ble.
-
Page 23: Installing The Drivers
Note! The drivers and utilities used for the panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest information regarding drivers and utilities. -
Page 24: Panel Mounting
Panel Mounting Position the TPC against the panel. Insert the clamps into the side of the TPC. Secure the clamp to the panel using the included screws. TPC-XX51T/H-E Series User Manual... -
Page 25: Cabinet Installation And Earth Grounding Setup
(5.6"/6.5" only) Smaller screws are included with the TPC-651T/TPC-651H, use these to avoid blocking CFast slot or I/O ports. Cabinet Installation and Earth Grounding setup Follow the following steps to setup TPC system, and please pay attention that Ground pin of TPC system should be connected to earth ground. Under this circum- stance, TPC system could have the best performance such as EMI immunity, ESD immunity, Surge immunity and also system isolation. - Page 26 System wiring. Step A: Connect the cabinet to earth ground. Step B: Ensure that all cabinet has been grounded together. Step C: Connect the ground of the power supply to the cabinet. Step D: Connect the ground pin of TPC system to the cabinet. Step E: Connect the I/O to the controller if needed.
-
Page 27: Power/Digital Ground And Earth Ground
Power/Digital Ground and Earth Ground The purpose is to block all the external interference on the chassis, and prevent any possibility of bad grounding design to cause electric shock of people. This is so called level 1 isolation which consumer PC do not implement this kind of design. ... - Page 28 TPC-XX51T/H-E Series User Manual...
-
Page 29: Chapter 3 Features In Windows Embedded
Chapter Features in Windows Embedded... -
Page 30: Features In Windows Embedded
Applying changes to an image applies all changes made to the operat- ing system during a specific period of time. Advantech provide utility to operate EWF. Refer below steps if you want to enable. Click Start Menu->All Programs->Advantech->AdvWF and click EWF Utility... - Page 31 Click EWF tab, and click “Enable” button After the system is rebooted automatically, EWF enable TPC-XX51T/H-E Series User Manual...
-
Page 32: File-Based Write Filter (Fbwf)
Writes to folders with write- through exceptions will be persisted when the device restarts. Advantech provide utility to operate FBWF. Refer below steps if you want to enable Click Start Menu->All Programs->Advantech->AdvWF and click FBWF Utility Move volume you want to protect from “Available Volume”... -
Page 33: Horm
Run OSLock, and then system reboot automatically. Open those software that customers want to directly use after system resume from hibernation. Hibernate via Advantech HORM utility: Click Start Menu->All Programs->Advantech->AdvWF Select “Enable Hibernation” in “Power Options”. Open AdvWF and enable EWF After the system is rebooted automatically, open AdvWF and click EWF Utility. - Page 34 TPC-XX51T/H-E Series User Manual...
-
Page 35: Appendix A Serial Port Settings
Appendix Serial Port Settings... -
Page 36: Jumper, Dip Switch And Connector Location
Jumper, Dip switch and Connector location A.1.1 A.1.2 Bottom TPC-XX51T/H-E Series User Manual... -
Page 37: Jumper Setting And Description
Jumper setting and Description A.2.1 CMOS Clear Function (CN1) CMOS Clear Function Description This jumper is used to select CMOS Clear Enable/Disable Default (1-2) (2-3) Enable (Clear CMOS) (1-2) Disable (1-2) Disable (2-3) Enable (Clear CMOS) Switch Setting COM2 RS232/422/485 mode setting (SW2) COM2 RS232/422/485 mode setting Description This switch is used to select COM2 RS232/422/485 mode setting... -
Page 38: Termination Resistor Select (Sw3)
Bit 1,2,3,4,5,8,9 OFF RS485 Mode Bit 6,7,10 ON A.3.1 Termination Resistor Select (SW3) Termination Resistor Select This switch is used to select Termination Resistor (120 ohm) for long Description distance transmission or device matching. Default Bit1 & Bit2 (DATA+ & RX-) DATA+ Pin 1 Pin 2... -
Page 39: Sata Power Connector (Cn13)
A.4.2 SATA Power connector (CN13) 1655000453 WAFER BOX 2.0mm 5P 180D(M) DIP WO/Pb JIH VEI Signal Description +V3.3SATA SATA power output 3.3V/1A +V5SATA SATA power output 5V/1A +V12SATA SATA power output 12V/0.5A A.4.3 Mini PCIE slot (MINIPCIE) 1654002538 MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68N7H Supports PCI1.1, PCI1.2 Power Definition Signal Description... -
Page 40: Cfast Slot (Cn14)
A.4.4 CFast slot (CN14) 1653004849 CFast 24P 1.27mm 90D(M) SMD N7G24-A0B2RA-10-0HT- The host is connected to the CFast Card using a 7+17 pin connector Segment CFast Name Description SATA SGND Ground for signal integrity SATA Signal Pair A : TX+/- (Transmit) SATA SATA... -
Page 41: Lan Rj45 Connector (Cn7,Cn8)
A.4.6 LAN RJ45 connector (CN7,CN8) 1652002996 PHONE JACK RJ45 14P 90D(M) DIP RTA-195AAK1A RJ45 Pin Signal Description In BASE-T: Media Dependent Interface[0]: 1000BASE-T: In MDI configuration, MDI[0]+/- corre- MDI0+ sponds to BI_DA+/- and in MDI-X configuration MDI[0]+/- corresponds to BI_DB+/-. ... -
Page 42: Usb Connector (Cn10)
A.4.7 USB connector (CN10) 1654010199 USB Conn. 2.0+3.0 13P 90D(F) DIP UEA1112C-UHS6-4 Signal Description 1, 10 USB VBUS USB Power output ,USB2.0 5V/0.5A and USB3.0 5V/0.9A 2, 11 USB_P- USB2.0 date - 3, 12 USB_P+ USB2.0 date + 4,13 Ground for Power return SSRX- USB3.0 RX - SSRX+... -
Page 43: Com2 Rs232/422/485 Connector (Cn16)
A.4.9 COM2 RS232/422/485 connector (CN16) 1654000056 D-SUB Conn. 9P 90D(M) DIP 070241MR009S200ZU RS232 RS422 RS485 TPC-XX51T/H-E Series User Manual... - Page 44 TPC-XX51T/H-E Series User Manual...
-
Page 45: Driver Installation And Configuration
Appendix Driver Installation and Configuration... -
Page 46: Intel Chipset Software Installation Utility Installation
Intel Chipset Software Installation Utility Installation Follow the steps below to install the Intel Chipset Software Installation Utility: Launch <Driver Root Path>\Intel Chipset Software Installation Util- ity\SetupChipset_XX.X.XX_PV Install SetupChipset.exe Click Next TPC-XX51T/H-E Series User Manual... - Page 47 Click Accept Click Install Click Finish TPC-XX51T/H-E Series User Manual...
-
Page 48: Intel Graphics Driver Installation
Intel Graphics Driver Installation Follow the steps below to install the Intel Graphics driver: Launch folder <Driver Root Path>\Graphics Driver\Intel EMGD win7 XX bit\ Install Setp.exe Click Next TPC-XX51T/H-E Series User Manual... - Page 49 Click Yes Click Next Click Install TPC-XX51T/H-E Series User Manual...
- Page 50 Click Next Choose Yes, then click Finish to restart TPC-XX51T/H-E Series User Manual...
-
Page 51: Lan Driver Installation
LAN Driver Installation Follow the steps below to install the LAN driver: Launch folder <Driver Root Path>\LAN\Win7 \Install_Win7_7077_XXX_XXXXXXXX Install setup.exe TPC-XX51T/H-E Series User Manual... - Page 52 Click Next Click Install TPC-XX51T/H-E Series User Manual...
- Page 53 Click Finish TPC-XX51T/H-E Series User Manual...
-
Page 54: Intel® Trusted Execution Engine Driver Installation
Intel® Trusted Execution Engine Driver Installation Follow the steps below to install the Intel Trusted Execution Engine driver: Launch folder <Driver Root Path>\TXE\Intel TXE Firmware\Win7 Install kmdf-1.11-Win-6.1-x86.msu Click Yes TPC-XX51T/H-E Series User Manual... - Page 55 Click Restart Now, then the system will restart Launch folder <Driver Root Path>\TXE\TXE_Win7_X_X.X_X.X.X.XXXX Install SetupTXE.exe TPC-XX51T/H-E Series User Manual...
- Page 56 Click Next Click Next Click Next TPC-XX51T/H-E Series User Manual...
- Page 57 Choose Yes, then click Finish to restart. TPC-XX51T/H-E Series User Manual...
-
Page 58: Windows 7 Usb 3.0 Driver Installation
Windows 7 USB 3.0 Driver Installation Follow the steps below to install the Windows 7 USB 3.0 driver: Launch folder <Driver Root Path>\USB3\Win7\SetupUSB3_X.X.X.XX Install Setup.exe Click Next TPC-XX51T/H-E Series User Manual... - Page 59 Click Yes Click Next Click Next TPC-XX51T/H-E Series User Manual...
- Page 60 Choose Yes, then click Finish to restart TPC-XX51T/H-E Series User Manual...
-
Page 61: Advantech Ec Driver Installation
Advantech EC Driver Installation Follow the steps below to install the EC drivers: Launch folder <Driver Root Path>\EC\Vx.xx.xxxx Install AdvEC_Vx.xx.xxxx.exe Click Next TPC-XX51T/H-E Series User Manual... - Page 62 Click Install Click Finish Choose Yes, then click OK to restart TPC-XX51T/H-E Series User Manual...
-
Page 63: Advantech Ec Brightness Control Tool Installation
Advantech EC Brightness Control Tool Installation Note! The Advantech EC driver must be installed first Follow the steps below to install the EC brightness control tool: Launch folder <Driver Root Path>\EC Brightness\Vx.xx.xxxx Install AdvECBrightness_Vx.xx.xxxx.exe Click Next TPC-XX51T/H-E Series User Manual... - Page 64 Click Install Click Finish Choose Yes, then click OK to restart TPC-XX51T/H-E Series User Manual...
-
Page 65: Advantech Ec Watchdog Timer Driver Installation
Advantech EC Watchdog Timer Driver Installation Note! The EC driver must be installed first Follow the steps below to install the EC Watchdog Timer driver: Launch folder <Driver Root Path>\WDT\Vx.xx.xxxx Install AdvWDT_Vx.xx.xxxx.exe TPC-XX51T/H-E Series User Manual... - Page 66 Click Next Choose Advantech [EC]WDT, then click Next TPC-XX51T/H-E Series User Manual...
- Page 67 Click Install Click Finish TPC-XX51T/H-E Series User Manual...
- Page 68 Choose Yes, then click OK to restart TPC-XX51T/H-E Series User Manual...
-
Page 69: Advantech Lmsensor Driver Installation
Advantech LMsensor Driver Installation Follow the steps below to install the LMsensor driver: Launch folder <Driver Root Path>\Lmsensor\Vx.xx.xxxx Install AdvLmsensor_EC_Vx.xx.xxxx.exe Next Restart Note! Go to Advantech’s product support page for the detailed driver user manual. TPC-XX51T/H-E Series User Manual... - Page 70 Note! The drivers and utilities used for the panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest information regarding drivers and utilities. TPC-XX51T/H-E Series User Manual...
-
Page 71: Appendix Cbios Setup
Appendix BIOS Setup AMI BIOS has been integrated into many motherboards for... -
Page 72: Entering Setup
BIOS supports your CPU. If there is no number assigned to the patch code, please contact an Advantech application engineer to obtain an up-to-date patch code file. This will ensure that your CPU's system status is valid. -
Page 73: Main Setup
C.1.1 Main Setup When you first enter the BIOS Setup Utility, users will enter the Main setup screen. Users can always return to the Main setup screen by selecting the Main tab. There are two Main Setup options. They are described in this section. The Main BIOS Setup screen is shown below. -
Page 74: Advanced Bios Features Setup
C.1.2 Advanced BIOS Features Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. Users can select any item in the left frame of the screen, such as CPU Con- figuration, to go to the sub menu for that item. Users can display an Advanced BIOS Setup option by highlighting it using the <Arrow>... - Page 75 C.1.2.1 ACPI Settings Configuration Enable ACPI Auto Configuration This item allows users to enable or disable BIOS ACPI auto configuration. Enable Hibernation This item allows users to enable or disable System ability to hibernate (OS/S4 sleep State). This option may be not effective with some OS. ...
- Page 76 C.1.2.2 Super I/O Configuration Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA) Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB) C.1.2.3 Embedded Controller Configuration EC Hardware Monitor This page display all information about system Temperature/Voltage/Current. ...
- Page 77 C.1.2.4 S5 RTC Wake Settings Wake system with Fixed Time Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr::min::sec specified. C.1.2.5 Serial Port Console Redirection Console Redirection This item allows users to enable or disable console redirection for Microsoft Windows Emergency Management Services (EMS).
- Page 78 C.1.2.6 CPU Configuration Execute Disable Bit This item allows users to enable or disable Execute Disable Bit. XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows server 2003 SP1, Windows XP SP2, RedHat Enter- prise 3 update 3.) ...
- Page 79 C.1.2.7 Thermal Configuration Critical Trip Point This value controls the temperature of the ACPI critical Trip Point in which the OS will shut the system off. Passive Trip Point This value controls the temperature of the ACPI critical Trip Point - the point in which OS will begin throttling the processor.
- Page 80 C.1.2.8 IDE Configuration Serial-ATA (SATA) This item allows users to enable or disable SATA devices. SATA Test Mode Test Mode enable / disable.. SATA Speed Support Indicates the maximum speed the SATA controller can support. SATA ODD Port SATA ODD is Port0 or Port1.
- Page 81 C.1.2.9 Miscellaneous Configuration OS Selection OS Selection to choose Windows 8.X / Windows 7 C.1.2.10LAN Controller LAN A Controller Enable or disable onboard NIC. LAN B Controller Enable or disable onboard NIC. Wake on LAN Enable Enable/Disable integrated LAN to wake the system TPC-XX51T/H-E Series User Manual...
- Page 82 C.1.2.11 CSM Configuration CSM Support Enable/Disable CSM Support. GateA20 Active UPON REQUEST - GA20 can be disabled using BIOS services. ALWAYS - do not allow disabling GA20; this option is useful when any RT code is executed above 1 ...
- Page 83 C.1.2.12USB Configuration Legacy USB Support Enables support for legacy USB. Auto option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only XHCI Hand-Off This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should claim by XHCI driver.
-
Page 84: Chipset Configuration
C.1.3 Chipset Configuration Intel IGD Configuration Configure Intel IGD Settings C.1.3.1 Intel IGD Configuration GOP Driver Enable GOP Driver will unload VBIOS; Disable it will load VBIOS. TPC-XX51T/H-E Series User Manual... -
Page 85: Security
C.1.4 Security Select Security Setup from the Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>: ... -
Page 86: Boot
C.1.5 Boot Setup Prompt Timeout Number of seconds that the firmware will wait before initiating the original default boot selection. A value of 0 indicates that the default boot selection is to be initiated immediately on boot. A value of 65535(0xFFFF) indicates that firmware will wait for user input before booting. -
Page 87: Save & Exit
C.1.6 Save & Exit Save Changes and Exit This item allows you to exit system setup after saving the changes. Discard Changes and Exit This item allows you to exit system setup without saving any changes. Save Changes and Reset This item allows you to reset the system after saving the changes. - Page 88 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2015...
