- Page 1 User Manual TPC-307W 7" Touch Panel Computer 製造商: 研華股份有限公司 地址: 台北市內湖區陽光街365巷33號 電話: 02-27927818...
- Page 2 The documentation and the software included with this product are copyrighted 2023 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
- Page 3 Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.
- Page 4 This product has passed the CE test for environmental specifications when shielded ca- bles are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Please contact your local supplier for ordering infor- mation.
- Page 5 Replace the bat- tery only with the same or equivalent type recommended by the manufac- turer. Discard used batteries according to the manufacturer's instructions. Notes provide optional additional information. Note! TPC-307W User Manual...
- Page 6 19. This product is not intended for use by children (this product is not a toy). 20. This equipment is not suitable for use in locations where children are likely to be present. 21. Caution: The wire of the protective bonding conductor shall be green-and-yellow, 22AWG/0.3mm2 minimum. TPC-307W User Manual...
- Page 7 16. 注意：如果電池放置不正確，將有爆炸的危險。因此，只可以使用製造商推薦的同一 種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。 17. 根據 IEC 704-1:1982 的規定，操作員所在位置的音量不可高於 70dB(A)。 18. 限制區域：請勿將設備安裝於限制區域使用。 19. 免責聲明：該安全指示符合 IEC 704-1 的要求。研華公司對其內容的準確性不承擔 任何法律責任。 20. 使用過度恐傷害視力。 21. 使用 30 分鐘請休息 10 分鐘。 22. 未滿 2 歲幼兒不看螢幕，2 歲以上每天看螢幕不要超過 1 小時。 23. 本產品為國內裝置使用時，其電源僅限使用架構電源模組所提供電源直流輸入， 不 得使用交流電源及附加其他電源轉換裝置提供電源這者，其電源輸入電壓及電流請依 說明書規定使用。 TPC-307W User Manual...
- Page 8 Don't touch any components on the CPU card or other cards while the PC is on. Disconnect power before making any configuration changes. The sudden rush of ◼ power as you connect a jumper or install a card may damage sensitive electronic components. viii TPC-307W User Manual...
-
Page 9: Table Of Contents
2.4.2 System Wiring ................ 10 System configuration ................11 2.5.1 Rear Bracket Removal ............11 2.5.2 AT/ATX Jumper Setting (PSON1) .......... 12 Table 2.1: AT/ATX Function Appendix A Connectors ........13 Jumper and Connector Location ............14 TPC-307W User Manual... - Page 10 NCT61260 HW Monitor ............29 B.3.8 USB Configuration ..............30 B.3.9 Network Stack Configuration ..........31 B.3.10 NVMe Configuration ............... 32 Chipset Configuration ................33 B.4.1 System Agent (SA) Configuration .......... 33 B.4.2 PCH-IO Configuration ............34 TPC-307W User Manual...
- Page 11 Security ....................35 Boot ....................... 36 Save & Exit .................... 37 TPC-307W User Manual...
-
Page 13: General Information
Chapter General Information TPC-307W User Manual... -
Page 14: Introduction
Introduction The TPC-307W Elkhart Lake series touch panel computer is a human machine interface (HMI) equipped with an Intel® Atom™ X6211E dual core processor. ◼ Industrial-grade 7" WSVGA TFT LCD with 50K lifetime and LED backlight Fanless design ◼ Intel® Elkhart Lake (EHL) Atom™ X6211E 1.30 GHz, dual core processor ◼... -
Page 15: Lcd Panel
Power Consumption: 19.2 W (typical) 1.2.9 External I/O The arrangement of I/O ports is shown below. A. Power receptor E. RS-232/422/485 (COM 2) B. USB 3.0 F. LAN (10/100/1000) C. USB 2.0 G. Line Out D. RS-232 (COM 1) TPC-307W User Manual... -
Page 16: Dimensions And Cutout
Dimensions and Cutout ◼ Dimensions (W x H x D): 205 x 146.92 x 55.7mm (8.07 x 5.78 x 2.20 inch) Unit: mm ◼ Cutout Dimensions: 192 x 138.5 mm (7.56 x 5.45 inch) TPC-307W User Manual... -
Page 17: Installation
Chapter Installation TPC-307W User Manual... -
Page 18: Transport And Unpacking
2.1.2 Unpacking Unpack the TPC-307W device. Configure the power mode if necessary (default: AT mode). See Section 2.5. Connect the power connector to the 24 VDC power lines of a power adapter or in-house power source. - Page 19 16-26 B, C 2(105), 4* Figure 2.2 Power Connector Power on the system. The power LED turns to blue. LED Indicator: Off - “dark” ON - “blue” Standby - “orange” Figure 2.3 Power LED Calibrate the touchscreen. TPC-307W User Manual...
-
Page 20: Panel Mount
Panel Mount There is an adhesive waterproof gasket on the front bezel. Make sure the water- proof gasket is in position before installing the TPC-307W panel computer into the panel opening. Install the TPC into the panel opening. For adequate air circulation, the TPC requires a certain clearance on all sides. -
Page 21: Vesa Mount
Figure 2.6 Panel Mounting – Clamp Fixing VESA Mount The TPC-307W’s rear cover features four VESA mounting (75 x 75 mm) holes. The VESA mounting kit needs to be installed by 4pcs M4x10L screws. Please use suitable mounting apparatus to avoid risk of injury. -
Page 22: Cabinet Installation And Earth Grounding Setup
Cabinet Installation and Earth Grounding Setup Follow the following steps to setup TPC-307W system, and please pay attention that Ground pin of TPC-307W system should be connected to earth ground. Un- der this circumstance, TPC-307W system could have the best performance such as EMI immunity, ESD immunity, surge immunity and also system isolation. -
Page 23: System Configuration
System configuration TPC-307W is a compact touch panel with IIoT functions for industrial applications. The system setup will be completed by the dealer or system integrator prior to delivery. However, users may still need to access the system to adjust configura- tion, such as the interfaces or boot modes. -
Page 24: At/Atx Jumper Setting (Pson1)
2.5.2 AT/ATX Jumper Setting (PSON1) Power mode can be set via this jumper on the TPC-307W motherboard as shown below. Table 2.1: AT/ATX Function Description This jumper is used to select Power ON mode Default (1-2) (2-3) (1-2) (1-2) AT power... -
Page 25: Appendix A Connectors
Appendix Connectors TPC-307W User Manual... -
Page 26: Jumper And Connector Location
Internal USB connector 2 LED2 LED indicator connector BAT1 RTC battery connector COM1 COM1 RS-232 connector COM2 COM2 RS-232/422/485 connector USB3C1 USB 3.0 connector USB2C1 USB 2.0 connector DCIN1 Power input connector LAN12 LAN RJ45 connectors AUDIO1 Audio connector TPC-307W User Manual... -
Page 27: Jumper Settings And Descriptions
Clear CMOS (1-2) CLR RTC Register (2-3) Normal, default (3-4) Clear CMOS A.2.2 LCD Resolution Select (SW1) Table A.3: LCD Resolution Select Description This switch is used to select LCD resolution Default 1024*600 (24-bit) PWM 1KHz (1-2-3-4) OFF-ON-ON-ON TPC-307W User Manual... -
Page 28: Connector Pin Definition
Table A.4:Power Button Connector (BTN1) Signal ATX_PWRBTN# A.3.2 Internal USB Connector (USB2H1 & USB2H2) Table A.5: Internal USB Connector (USB2H1 & USB2H2) Signal A.3.3 LED Indicator Connector (LED2) Table A.6: LED Indicator Connector (LED2) Signal Orange light Blue light TPC-307W User Manual... -
Page 29: Rtc Battery Connector (Bat1)
A.3.4 RTC Battery Connector (BAT1) Table A.7: RTC Battery Connector (BAT1) Signal +VBAT A.3.5 COM1 RS-232 Connector (COM1) Table A.8: Internal COM Port Connector (COM1) Signal DCD# DTR# RTS# CTS# TPC-307W User Manual... -
Page 30: Com2 Rs-232/422/485 Connector (Com2)
A.3.6 COM2 RS-232/422/485 Connector (COM2) Table A.9: COM2 RS-232/422/485 Connector (COM2) RS232 RS422 RS485 Data- Data+ A.3.7 Power Input Connector (DCIN1) Table A.10: Power Input Connector (DCIN1) Signal Power In V+ Power In V- (GND) GND_EARTH TPC-307W User Manual... -
Page 31: Appendix Bbios Setup
Appendix BIOS Setup TPC-307W User Manual... -
Page 32: Entering Setup
BIOS supports your CPU. If there is no num- ber assigned to the patch code, contact an Advantech application engineer to obtain an up-to-date patch code file. This will ensure that the CPU status is valid. -
Page 33: Main Setup
System Date using the <Arrow> keys. Enter new values via the key- board. Press the <Enter> key to move between fields. The date must be entered in MM/DD/YY format. The time must be entered in HH:MM:SS for- mat. TPC-307W User Manual... -
Page 34: Advanced Bios Features Setup
Users can display an Advanced BIOS Setup option by highlighting it using the <Arrow> keys. All Advanced BIOS Setup options are described in this section. The Advanced BIOS setup screen is shown below. The submenus are described on the following pages. TPC-307W User Manual... -
Page 35: Cpu Configuration
To turn on/off prefetching of adjacent cache lines ◼ Intel (VMX) Virtualization Technology When enabled, a VMX can utilize the additional hardware capabilities pro- vided by Vanderpool Technology ◼ Active Processor Cores Number of cores to enable in each processor package TPC-307W User Manual... -
Page 36: Power & Performance
This item allows more than two frequency ranges to be supported. ◼ Intel(R) Speed Shift Technology This item allows users to enable/disable Intel® Speed Shift Technology sup- port. Enable it will expose the CPPC v2 interface to allow for hardware con- trolled P-states. TPC-307W User Manual... -
Page 37: Pch-Fw Configuration
CPU to go to C states when not 100% utilized. B.3.3 PCH-FW Configuration ◼ ME State When this item is disabled, ME will be put into ME Temporarily Disabled Mode. ◼ Firmware Update Configuration This item allows users to configure the management engine technology pa- rameters. TPC-307W User Manual... -
Page 38: Trusted Computing
This item allows users to enable/disable endorsement hierarchy. ◼ TPM2.0 UEFI Spec Version This item allows users to select the TCG2 spec version supported. TCG_1_2: The compatible mode for Win8/10. TCG_2: Supports new TCG2 protocol and event formats for Win10 or later. TPC-307W User Manual... -
Page 39: Acpi Settings
This item allows users to enable/disable the system hibernation function (OS/S4 Sleep State). This option may not be available with some operating systems. ◼ ACPI Sleep State This item allows users to select the highest ACPI sleep state when the Sus- pend button is pressed. TPC-307W User Manual... -
Page 40: Nct61260 Super Io Configuration
B.3.6 NCT61260 Super IO Configuration ◼ Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). ◼ Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB). TPC-307W User Manual... -
Page 41: Nct61260 Hw Monitor
B.3.7 NCT61260 HW Monitor TPC-307W User Manual... -
Page 42: Usb Configuration
This item allows users to Set the maximum time the device will take before reporting itself to the Host Controller. The Auto option uses the default value, which is 100 ms for a Root port. For a Hub port, the delay time is ob- tained from the Hub descriptor. TPC-307W User Manual... -
Page 43: Network Stack Configuration
B.3.9 Network Stack Configuration ◼ Network Stack This item allows users to enable or disable UEFI network stack. TPC-307W User Manual... -
Page 44: Nvme Configuration
B.3.10 NVMe Configuration TPC-307W User Manual... -
Page 45: Chipset Configuration
System Agent (SA) Configuration ◼ Memory Configuration This item allows users to view the memory parameters. ◼ Graphics Configuration This item allows users to set graphics configuration parameters ◼ VT-d This item allows users to enable or disable VT-d capability TPC-307W User Manual... -
Page 46: Pch-Io Configuration
This item allows users to enable or disable the PCIe device to wake up the system from S3/S4/S5 state. ErP Function ◼ When this option is disabled, the wake on function can be selected. ◼ PinCntrl Driver GPIO Scheme This item allows users to enable or disable PinCntrl Driver GPIO Scheme. TPC-307W User Manual... - Page 47 Security ◼ Administrator Password Set administrator password ◼ Secure Boot This item allows users to access a submenu to configure secure boot set- tings. TPC-307W User Manual...
- Page 48 This item allows users to set the number of seconds to wait for setup activa- tion key. 65535 (oxFFFF) means indefinite waiting. ◼ Bootup NumLock State This item allows users to select the keyboard NumLock state. ◼ Quiet Boot This item allows users to enable/disable quiet boot option. TPC-307W User Manual...
- Page 49 This item allows users to restore/load default values for all setup options. ◼ Save as User Defaults This item allows users to save all current settings as user defaults. ◼ Restore User Defaults This item allows users to restore all setup options to the user default values. TPC-307W User Manual...
- Page 50 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2023 TPC-307W User Manual...
