Axis video server - Live View Config
32
Viewer Settings
Checking the Show viewer toolbar box displays the AMC toolbar under the video stream
in Microsoft Internet Explorer.
By checking the Enable MPEG-4 decoder installation box, it is also possible for the
Administrator to enable or disable the installation of the MPEG-4 decoder. This is used to
prevent the installation of unlicensed copies. Further decoder licenses can be purchased
from your Axis dealer.
Show crosshair in PTZ joystick mode - This will enable the display of a crosshair in the
video image when the the PTZ mode is set to joystick.
Show IV SVG data in image stream (AXIS 242S IV only) - The currently running IV
module is capable of showing SVG data superimposed over the video image.

HTML Examples

Live video from the Axis video server can be added to your own web page.
Select the preferred Video Format from the drop down list. The available options are
Motion JPEG, MPEG-4 using AMC and MPEG-4 using QuickTime. If MPEG-4 using AMC is
set as the video format, note that a separate MPEG-4 license is required for each viewer.
The Motion JPEG selection has additional settings for Image Type, Image size and other
optional settings for configuring the video stream to suit your web page. Click Update
when satisfied.
The video server then generates the required source code for your configuration. Copy this
code and paste it into your own web page code.

External Video

You can add links to other Axis network devices available over the network. These sources
can be displayed on the Live View page, just as if they were video sources connected
directly to the Axis video server.
Click the Add button to open the External Video Source Setup dialog, which is used to
make all the necessary settings.
Example of a path to an external video source:
http://192.168.0.125/axis-cgi/mjpeg/video.cgi
