Axis Video Server User Manual page 13

The trigger buttons trigger an event directly from the Live View page. These
buttons are configured under Setup > Live View Config > Layout. Click these
buttons to manually start and stop events.
Use the Snapshot button to capture a snapshot of the image currently being
displayed in the window. Right-click on the image to save it in on your
computer.
The AMC viewer toolbar (AXIS Media Control) is available in Microsoft Internet
Explorer only and displays the following buttons:
The Play/Stop buttons start and stop the media stream.
The Snapshot button saves a snapshot of the video image currently being
displayed. The Snapshot function and the target directory for saving snapshots
can be configured from the AMC Control Applet, which can be opened from the
Windows Control Panel or by right-clicking the image in Internet Explorer.
Click the View Full Screen button and the video image will fill the entire screen
area. No other windows will be visible. Press Esc (Escape) on your keyboard to
cancel full screen view.
AMC Audio controls (AXIS 241SA and AXIS 241QA)
There are audio controls for controlling the client computer's speaker output. These
controls are only available in the MPEG-4 video format and when audio is enabled, see
Audio Settings, on page 25.
Click the Speaker and Microphone buttons to switch the sound off and on, for the
speaker and microphone, respectively.
Use the slider to control the volume on the speaker and microphone.
The volume can be set between 0 and 100.
When using Half-duplex mode, this button toggles between allowing you to speak
and listen. The first icon indicates that you can talk and the speaker attached to the
video server plays your voice. The second icon indicates that you will hear audio
from the video server, but no audio is sent to web clients. When in simplex talk
mode, the icon toggles between allowing you to speak, and is dimmed when you do not
want other clients to receive any audio.
Note that these AMC toolbar functions can also be accessed by right-clicking in the image.
For information on using Pan/Tilt/Zoom controls, please see Pan Tilt Zoom, on page 41.
Axis video server - Using the video server
13
