HP Z230 SFF Workstation Quickspecs page 4

QuickSpecs
Overview
Available Processor
Disclaimers
Color
Convertibility
Expansion Slots (see
system board section for
more details)
Expansion Bays (see
storage section for more
details)
Front I/O
Internal I/O
Rear I/O
Interfaces Supported
Chassis Dimensions
(H x W x D)
Integrated Intel® HD graphics is not supported on the Intel® Xeon Processor E3-1230v3, E3-1240v3, E3-
1270v3 or E3-1280v3.
Intel® Xeon E3, Intel Core i3 and Intel Pentium processors can support either ECC or non-ECC memory;
Intel® Core i5/i7 processors only support non-ECC memory.
Intel's numbering is not a measurement of higher performance. Processor numbers differentiate features
within each processor family, not across different processor families. See:
http://www.intel.com/products/processor_number/
64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS,
operating system, device drivers and applications enabled for Intel 64 architecture. Processor will not
operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary
depending on your hardware and software configurations. See:
information.
Dual-Core and Quad-Core technologies are designed to improve performance of multithreaded software
products and hardware-aware multitasking operating systems and may require appropriate operating
system software for full benefits; check with software provider to determine suitability; Not all customers
or software applications will necessarily benefit from use of these technologies.
Jack Black
The Z230 SFF can either be placed flat on the desktop or made to stand on the desk with the optional
tower stand.
1 PCIe Gen3 x16 slot
1 PCIe Gen2 x4 slot /x16 connector
1 PCIe Gen2 x1 slot/x4 connector
1 PCIe Gen2 x1 slot
(all slots are Low Profile)
Note: In the PCIe Gen3 x16 slot, if it is not being used for a graphics card, only cards certified as After
Market Options for this platform are supported.
1 external Half Height 5.25" bay
1 shared internal/external 3.5" bay
1 internal 3.5" bay
1 internal 2.5" bay (for SSD only)
2 USB 3.0, 2 USB 2.0, 1 Headphone, and 1 Microphone
1 USB 3.0 and 3 USB 2.0 ports available as 2 separate 2x10(3.0 x1, 2.0 x1) and 2x5(2.0 x2) header:
supports one HP Internal USB 2.0 Port Kit and one USB 3.0 Media Card Reader.
3 DisplayPort (DP 1.2) outputs from Intel HD graphics (available on specific processors only); 2 USB 3.0
ports, 4 USB 2.0 ports, 2 serial ports (1 standard, 1 optional), 1 parallel port (optional), 2 PS/2, RJ-45 (LoM),
1 Audio Line-in, and 1 Audio Line-out; 2 IEEE 1394b ports (optional).
14-in-1 Media Card Reader (optional)
Standard desktop orientation: 100 x 337 x 384 mm (3.95 x 13.3 x 15.1 in); Optional SFF Tower orientation
(excluding stand dimension): 337 x 100 x 384 mm (13.3 x 3.95 x 15.1 in)
DA - 14630 Worldwide — Version 14 — April 1, 2014
HP Z230 SFF Workstation
for details.
http://www.intel.com/info/em64t for more
Page 4
