Carrier edge Owner's Manual

Performance programmable
Hide thumbs Also See for edge:
Table of Contents

Advertisement

Quick Links

Performance
Programmable Owner's Manual
t
R
®

Advertisement

Table of Contents
loading

Related Manuals for Carrier edge

Summary of Contents for Carrier edge

  • Page 1 Performance Programmable Owner’s Manual ®...
  • Page 3 Designed to be as smart – and smart−looking – as any of the other electronics in your home, your new Edge thermostat offers programming options to fit your lifestyle – not anybody else’s. Let this manual show you how easy it is to enjoy the newest experience in home comfort.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS BUTTON IDENTIFICATION ......... ON−SCREEN INDICATORS .
  • Page 5 TABLE OF CONTENTS Using the fan ............Changing the humidity level .
  • Page 6 TABLE OF CONTENTS SPECIAL FEATURES Hybrid Heat (heat pump systems only) ......Service reminders .
  • Page 7 ......ExP – Edge Expansion Port ........

  • Page 8: Button Identification

    BUTTON IDENTIFICATION...

  • Page 9: Button Identification

    BUTTON IDENTIFICATION Enters the programming schedule, adjusts the clock, changes calendar, etc. Choose follow schedule, hold, or vacation SCHEDULE Selects whether the fan operates continuously (on) or only when needed for heating or cooling (auto) Selects whether thermostat is set for heating, cooling, MODE emergency heat, or auto (heat and cool as needed), or off Saves settings when completing a set−up or programming...

  • Page 10: On−Screen Indicators

    ON−SCREEN INDICATORS...
  • Page 11 ON−SCREEN INDICATORS 1. Day of the week 2. Programming option; indicates which settings are being adjusted 3. Filter, UV lamp, humidifier pad reminders 4. Current temperature 5. Current program routine – follow scheduled programming, hold current settings, run vacation program 6.

  • Page 12: Quick Start

    QUICK START Setting the time and day You must set the time and date before you can use any of the thermostat’s programming features. 1. Open the door. 2. Press the set button on the left. The screen will show the word clock on the left and the time on the bottom.
  • Page 13 QUICK START 6. To set the month, press the button underneath the letter M (month), then press the up or down button on the right. Stop at the desired month. 7. To set the day of the month, press the button underneath the letter D (day), then press the up or down button on the right.

  • Page 14: Setting The Temperatures For Heating And Cooling

    QUICK START Setting or changing the temperatures for heating and cooling Your thermostat is installed with pre−set heating and cooling temperature settings. You can use these or change them so your home is as warm or as cool as you would like it to be. You can also temporarily change the temperature after you’ve programmed your thermostat according to your specific schedule needs.
  • Page 15 QUICK START 4. Press the up or down button, located to the right of the display, to change the displayed setting. Stop on the desired setting. 5. When there are arrow indicators next to both the words heat and cool at the top right of the screen, the heating and cooling temperatures are also displayed at the bottom of the screen.

  • Page 16: Holding The Temperature

    QUICK START Holding the temperature Here’s how to override your programmed temperature settings and hold the temperature at a specific setting without the temperature changing during the next programmed period. 1. Open the door. 2. Press the schedule button at the top. The arrow will move to the word hold under the button.

  • Page 17: Using The Exp - Edger Expansion Port - To Program The Thermostat

    QUICK START Using the ExP – Edge Expansion Port – to program the thermostat Your Edge thermostat has an unique ExP – Edge Expansion Port – that allows you to use a digital memory card to program the thermostat on your computer. The ExP is sold separately as an accessory.

  • Page 18: Programming The Thermostat

    PROGRAMMING THE THERMOSTAT Determining your programming schedule Unlike many thermostats, this one gives you the option of programming every day of the week differently. It is pre−programmed at the factory with the same settings for all seven days: Monday Time Heat Cool through...
  • Page 19 PROGRAMMING THE THERMOSTAT You can change those settings easily. Each day in your schedule must have four time periods. The thermostat thinks of these time blocks in terms of when people wake up, when they leave for the day, when they return home, and when they go to sleep.
  • Page 20 PROGRAMMING THE THERMOSTAT Tuesday Wake Tuesday Day Tuesday Evening Tuesday Sleep Wednesday Wake Wednesday Day Wednesday Evening Wednesday Sleep...
  • Page 21 PROGRAMMING THE THERMOSTAT Thursday Wake Thursday Day Thursday Evening Thursday Sleep Friday Wake Friday Day Friday Evening Friday Sleep...
  • Page 22 PROGRAMMING THE THERMOSTAT Saturday Wake Saturday Day Saturday Evening Saturday Sleep Sunday Wake Sunday Day Sunday Evening Sunday Sleep...

  • Page 23: Setting Up Your Schedule When All Days Of The Week Will Follow The Same Schedule

    PROGRAMMING THE THERMOSTAT Setting up your schedule when all days of the week will follow the same schedule Here’s how to program your thermostat when all seven days of the week will follow the same schedule. 1. Open the door. 2.
  • Page 24 PROGRAMMING THE THERMOSTAT 5. Set the cooling temperature for that time period by pressing the button under the cool set at: temperature on the right and then pressing the up or down button until you reach the desired cooling temperature. 6.

  • Page 25: Setting Up Your Schedule When All Days Of The Week Won't Follow The Same Schedule

    PROGRAMMING THE THERMOSTAT Setting up your schedule when all days of the week won’t follow the same schedule Here’s how to program your thermostat when one or more days will follow a different schedule from the rest. 1. Open the door. 2.
  • Page 26 PROGRAMMING THE THERMOSTAT 6. Set the cooling temperature for that time period by pressing the button under the cool set at: temperature on the right and then pressing the up or down button until you reach the desired cooling temperature. 7.

  • Page 27: Using The Programmable Fan

    PROGRAMMING THE THERMOSTAT 10. Continue to repeat step 8, then steps 4 through 7 to program remaining days. 11. Press the done button on the right when you’ve completed the process. 12. Close the door. Using the programmable fan When you use the instructions on page 45 in the Advanced Programming Options section to turn on the programmable fan feature, you can program the fan selection to “auto”...

  • Page 28: Programming A Vacation Schedule

    PROGRAMMING THE THERMOSTAT Programming a vacation schedule You can program a special heating and cooling schedule to follow when you will be gone for a vacation or an extended period of time. 1. Open the door. 2. Press the set button on the left side repeatedly until the screen shows vacation settings on the right side, your vacation heating and cooling temperatures in the lower right, and humidify* on the bottom.

  • Page 29: Activating Your Vacation Program

    PROGRAMMING THE THERMOSTAT 7. Press the up or down button on the side and stop at the desired setting. 8. To change the fan from auto to on, press the fan button at the top. 9. To change the thermostat mode to heat, cool, Em heat or heat/cool (auto), press the mode button at the top until the arrow is next to the option you want.
  • Page 30 PROGRAMMING THE THERMOSTAT 1. Press the schedule button at the top until the arrow is next to vacation. 2. You will see the next day’s date at the bottom of the screen under the words return on. There is a box around the date.

  • Page 31: Operating The Thermostat

    OPERATING THE THERMOSTAT Using the thermostat to turn the heating and cooling system off Here’s how to use the thermostat to turn the heating and cooling system off. 1. Open the door. 2. Press the mode button on the top left repeatedly until the display shows off in the upper left.

  • Page 32: Changing The Humidity Level

    OPERATING THE THERMOSTAT Changing the humidity level Your thermostat offers three humidity* options: normal, auto and off. It is set at the factory for “normal humidify,” which is a fixed setting based on how much humidity you want in the home. This humidity level remains constant, regardless of the outdoor temperature.

  • Page 33: Using Auto Humidify

    OPERATING THE THERMOSTAT 3. Press the up or down button to change the setting. It is factory−set at 26% for humidify and 60% for dehumidify. It there’s too much condensation on the windows, try a lower number. If the air is too dry, try a higher number.

  • Page 34: How To Turn Off The Humidify Or Dehumidify Feature

    OPERATING THE THERMOSTAT 3. Press the up or down button to change this auto humidify set at number (1 through 9). If there is too much condensation on the windows, select a number lower than 5. If there seems to be a lot of static electricity, which often means the air is too dry, select a number higher than 5.

  • Page 35: Using Emergency Heat (Heat Pump Systems Only)

    OPERATING THE THERMOSTAT Using emergency heat (heat pump systems only) Emergency heat is useful when the automatic auxiliary heat system can’t keep up with demand. (Systems with heat pumps use “auxiliary heat” when it’s too cold outside for the heat pump to heat the house without help. The display indicator for this is auxiliary heat on.) If the heat pump compressor that works with auxiliary heat fails, or if the heat pump isn’t working at all, you can turn on the emergency heat for that extra...

  • Page 36: Advanced Programming Options

    ADVANCED PROGRAMMING OPTIONS Advanced programming display codes chart You can customize several features of your thermostat. This chart shows which features you can change and the codes associated with them. The codes will be shown on the display when you follow the instructions. Feature Configuration Code Change Indication...

  • Page 37: Clearing The Reset Reminders

    ADVANCED PROGRAMMING OPTIONS Clearing the reset reminders The thermostat tells you when it’s time to change the UV light in the evaporator coil box connected to the furnace (if equipped), humidifier pad (if equipped), and furnace filter. (See page 47 for more information.) When the reminder icons are displayed on the screen, pressing and holding the done button for about three seconds clears all reminders on the screen.
  • Page 38 ADVANCED PROGRAMMING OPTIONS 5. Press the done button. 6. Close the door.

  • Page 39: Changing From Fahrenheit To Celsius

    ADVANCED PROGRAMMING OPTIONS Changing from Fahrenheit to Celsius Your thermostat is preset to display the temperature in degrees Fahrenheit. You can change this to Celsius. 1. Open the door. 2. Press and hold the buttons underneath the heat and cool setpoints simultaneously (the two bottom buttons on the right) until the screen displays the reset reminders and 01 in the lower right corner.

  • Page 40: Adjusting Or Turning Off The Continuous Backlighting

    ADVANCED PROGRAMMING OPTIONS Adjusting or turning off the continuous backlighting Your thermostat may feature a low level amount of backlighting until you press any button, which increases the lighting temporarily. You can adjust the intensity of the backlighting or turn if off completely. The range is off (OF) 1 to 5 brightness.
  • Page 41 ADVANCED PROGRAMMING OPTIONS 5. Press the done button. 6. Close the door.

  • Page 42: Keypad Lockout

    ADVANCED PROGRAMMING OPTIONS Keypad lockout The keypad lockout feature lets you “lock” the thermostat at one of three levels that increasingly limit anyone’s ability to make changes by pressing buttons. The levels are: 1 – You can change the temperature settings, the time of day, and the day of the week only 2 –...

  • Page 43: Unlocking The Keypad

    ADVANCED PROGRAMMING OPTIONS 5. Press the done button. 6. Close the door. Unlocking the Keypad Here’s how to temporarily unlock the keypad after you have locked it. 1. Open the door. 2. Press and hold the up and down buttons on the right simultaneously for about five seconds.

  • Page 44: Changing From Programmable To Nonprogrammable

    ADVANCED PROGRAMMING OPTIONS Changing from programmable to nonprogrammable It is possible to convert your thermostat’s operation from programmable to nonprogrammable. This eliminates its advanced features. When switching to the nonprogrammable format, you lose the programming, hold, vacation and Smart Recovery features. Switching to nonprogrammable also means you’ll give up some of the thermostat’s energy saving features.
  • Page 45 ADVANCED PROGRAMMING OPTIONS 4. Press the rightmost lower button then press the up arrow button until screen displays (nonprogrammable). 5. Press the done button. 6. Close the door.

  • Page 46: Changing The Number Of Programming Periods

    ADVANCED PROGRAMMING OPTIONS Changing the number of programming periods Your thermostat is preset with four time periods. You can change this to two. Here’s how to change the number of periods in the day. 1. Open the door. 2. Press and hold the buttons underneath the heat and cool setpoints simultaneously (the two bottom buttons on the right) until the screen displays the reset reminders and 01 in the lower right corner.

  • Page 47: Turning On The Programmable Fan Feature

    ADVANCED PROGRAMMING OPTIONS Turning on the programmable fan feature When you turn on the programmable fan feature using these instructions, you can program the fan selection to “auto” or “on” for each of the program schedule periods. (Learn more about this on page 25.) 1.

  • Page 48: Turning Off The Daylight Savings Time Feature

    ADVANCED PROGRAMMING OPTIONS Turning off the daylight savings time feature The thermostat will automatically change the clock according to daylight savings time procedures twice a year. Here’s how to turn off the daylight savings time feature so the clock doesn’t automatically change. 1.

  • Page 49: Special Features

    SPECIAL FEATURES Hybrid Heat (heat pump with a furnace system only) This thermostat works with the Carrier Hybrid Heat systems offering maximum comfort and economy by automatically controlling whether your system delivers heating with the heat pump, with the furnace, or with both options working together.

  • Page 50: Auto Changeover

    SPECIAL FEATURES Auto changeover The thermostat displays one of five modes: heat, cool, Em heat (heat pump version only), heat cool (auto mode) and off. When the mode selection is for both heating and cooling – auto mode – the thermostat is in auto changeover mode.

  • Page 51: What If

    WHAT IF . . . “Auxiliary heat on” is displayed (heat pump and Hybrid Heat systems only) Auxiliary heat on applies only to the heat pump version. If it is on, you will see auxiliary heat on. When it is displayed, it means the system has determined that it’s too cold outside for your heat pump to heat the house without help, so it’s getting help from the electric heaters.

  • Page 52: You Get A Service Reminder Message

    WHAT IF . . . You get a service reminder message Service reminder messages – check UV light, check hum pad, check filter – tell you that it’s time to change the UVC lamp in the evaporator coil box connected to the furnace (when installed), humidifier pad (when installed), and furnace filter.

  • Page 53: Common Terms And Where To Find Them

    COMMON TERMS AND WHERE TO FIND THEM Auto changeover page 48 ......... . This feature automatically switches your system from heating to cooling –...

  • Page 54: Dehumidify

    ....... The unique EXP – Edge Expansion Port – allows you to use a digital memory card to program the thermostat on your computer.

  • Page 55: Humidify

    COMMON TERMS AND WHERE TO FIND THEM Humidify page 30 ..........When your heating and cooling system includes a humidifier, the thermostat will instruct it to add moisture to the air as necessary when the heat is on.

  • Page 56: Smart Recovery

    COMMON TERMS AND WHERE TO FIND THEM Service reminders page 47 ......... The thermostat tells you when it’s time to change the UVC lamp (if equipped), humidifier pad (if equipped) and furnace filter.
  • Page 57 NOTES PAGE...

  • Page 58: Warranty

    Limited Warranty for Thermostats FOR WARRANTY SERVICE OR REPAIR: Contact the installer or a Carrier dealer. You may find the installer’s name on the equipment or in your Owner’s Packet. You can also find a Carrier dealer online at www.carrier.com For help, contact: Carrier Corporation, Consumer Relations, P.O.
  • Page 59 THERMOSTAT LIMITED WARRANTY OWNER−OCCUPIED, RESIDENTIAL APPLICATIONS This warranty is to the original purchasing owner and is transferable only to the extent and as stated in the Warranty Conditions and below. The warranty period in years, depending on the part and the claimant, is as shown in the chart below.

  • Page 60: Warranty Conditions

    LEGAL REMEDIES: The owner must notify the Company in writing, by certified or registered letter to Carrier Corporation, Warranty Claims, P.O. Box 4808, Syracuse, New York 13221, of any defect or complaint with the product, stating the defect or complaint and a specific request for repair, replacement, or other correction of the product under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.
  • Page 61 THERMOSTAT LIMITED WARRANTY LIMITATIONS OF WARRANTIES: ALL IMPLIED WARRANTIES AND/OR CONDITIONS (INCLUDING IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE OR PURPOSE) ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY. SOME STATES OR PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THE ABOVE MAY NOT APPLY TO YOU.
  • Page 62 – such as infants and the elderly – and those sensitive to the effects of molds, pollen, pets and more. And, it is an integral component to Carrier Healthy Home Solutions.
  • Page 64 OM−TPPRH−04CA Manufacturer reserves the right to discontinue, or change at any time, E Carrier Corporation 2010 specifications or designs without notice or without incurring obligations.

This manual is also suitable for:

Performance edge tp seriesPerformance edge tc seriesPerformance edge tb series
