QuickSpecs
Configuration
Non-HP Cabinets
I/O Architecture
HP Integrity rx2800 i2 Supported I/O Cards
I/O Card
HP1-port 8Gb PCIe FC SR QLogic HBA
HP 2-port 8Gb PCIe FC SR QLogic HBA
HP PCIe 1-port 8Gb FC SR Emulex HBA
HP PCIe 2-port 8Gb FC SR Emulex HBA
HP Integrity SN1000Q 1p 16GB FC HBA
HP Integrity SN1000Q 2p 16GB FC HBA
HP Integrity PCIe 2p P411/256MB SAS
Controller
For customers who choose to use non HP cabinets, the HP Integrity rx2800 i2 provides simple options for
installation and HP field support. The HP Integrity rx2800 i2 field rack kit (AM227A) contains adjustable
slide rails, allowing the server to be mounted in cabinets that use the four post EIA mounting system.
Once the server is mounted in a non HP cabinet, it must meet some simple criteria to ensure that HP field
personnel can fully support the rack environment.
Anti Tip-The rack/cabinet must be solidly anchored to the floor both front and rear. This is usually
accomplished by anti tip feet or by direct bolting to the floor.
Air Flow-The HP Integrity rx2800 i2 uses front to back airflow to cool the unit. Thus a cabinet
cannot have a solid front or rear door. Solid doors may have to be removed or changed to an open
perforation pattern.
Cable Strain Relief-A proper method of strain relief must be used. This may force the elimination of
the rear door in some cases.
Front and Rear Access-For proper cooling and ease of service access, HP recommends 32 inches of
unobstructed floor space in the front and rear of rack installations. This recommendation applies to
both HP and third party racks and cabinets.
Product
Number
AH400A
AH401A
AH402A
AH403A
B9F23A
B9F24A
AM311A
DA - 13770 Worldwide — Version 14 — December 10, 2013
Length/ Boot Support
Height
Half-Length/ Yes
Low-Profile
or Full-Height
Half-Length/ Yes
Low-Profile
or Full-Height
Half-Length/ Yes
Low-Profile
or Full-Height
Half-Length/ Yes
Low-Profile
or Full-Height
Half-Length/ Yes
Low-Profile
or Full-Height
Half-Length/ Yes
Low-Profile
or Full-Height
Half-Length/ Yes
Low-Profile
or Full-Height
HP Integrity rx2800 i2 Server
Maximum Special Notes
Cards
6 6 with 2 AM228A IO Riser
Cards
6 6 with 2 AM228A IO Riser
Cards
6 6 with 2 AM228A IO Riser
Cards
6 6 with 2 AM228A IO Riser
Cards
6 6 with 2 AM228A IO Riser
Cards
6 6 with 2 AM228A IO Riser
Cards
3 Only supported in Primary
PCIe IO Riser card.
3 with 1 AM228A IO Riser
Card
