Table 1-1: ProLiant BL20p G3 Server Blade Front Panel LEDs
Item
3
4
5
6
7
*Actual NIC numeration depends on factors such as which operating system
is installed on the server.

Hot-Plug SCSI Hard Drive

Each hot-plug SCSI hard drive has three LEDs located on the front of the drive. The
LEDs provide activity, online, and fault status for each corresponding drive when
configured as a part of an array and attached to a powered-on Smart Array controller.
Their behavior may vary depending on the status of other drives in the array. Use
Figure 1-2 and Table 1-2 to identify LED locations and functions.
HP ProLiant BL20p Generation 3 Server Blade User Guide
LED Description
NIC 1*
NIC 2*
NIC 3*
NIC 4*
Power
Server Blade Component Identification
Status
Green = Linked to network
Green flashing = Network activity
Off = No activity
Green = On
Amber = Standby (power available)
Off = Unit off
continued
1-3
