INSTALL INSTRUCTIONS C-VS-1200-DUR

TOOLS REQUIRED:

Cordless Screwdriver
Power drill with 1/8" drill bit

HARDWARE:

QTY DESCRIPTION
8 #10 x ¾" Sheet metal screws

SUB ASSEMBLY:

1. Run wiring for control heads to OEM console area.

INSTALLATION:

1. Mount Vehicle Specific Console :
• Place console between dashboard and OEM armrest. Works best if console is
carefully slid in from side.
• Vehicle Specific console will rest on top of OEM console.
• Mark and pre-drill console.
• Screw Vehicle specific console directly to OEM console.
Note: Console can be centered off the Dash, or centered off the OEM Armrest.
switch and 12 volt socket can be relocated to the mounting plate provided (Installer must lengthen wires)
Shown with console model options: C-SP-3B, C-CH-2, C-ML-LP2 and Equipment Bracket.
2004-2008 DODGE DURANGO
PART #
GSM33195
The OEM. Traction control
C-VS-1200-DUR_INST_9-07
