INSTALL INSTRUCTIONS C-VS-700-EXPL
TOOLS REQUIRED:
Phillips Screw Driver
Power Drill
HARDWARE:
QTY: DESCRIPTION:
6
#10 x ¾" Sheet metal screws
INSTALLATION:
1. Mount Explorer C-VS Console:
• Place C-VS Console over top O.E.M console tight to dashboard.
• Mark (6) mounting holes.
• Drill 1/8" pilot hole through plastic trim.
• Mount VS-Console with #10 X ¾" Sheet metal screws.
2002-2005 FORD EXPLORER
Mounting Holes
1/8" Drill Bit
PART #:
GSM33195
C-VS-700-EXPL-INST-6-06
