Cardinal 854F Series Owner's Manual
  1. Manuals
  2. Brands
  3. Cardinal Manuals
  4. Scales
  5. Detecto 854F Series
  6. Owner's manual

Cardinal 854F Series Owner's Manual

Cardinal detecto portable platform scales beam type
Hide thumbs Also See for 854F Series:

Advertisement

Quick Links

Download this manual
This Document is Hosted by: www.oldwillknottscales.com
PORTABLE PLATFORM
SCALES
BEAM TYPE
SERIES 854F/954F
Owner's Manual
CARDINAL SCALE MFG. CO.
0066-M110-O1 Rev H
PO Box 151 Webb City, MO 64870
09/11
Ph: 417-673-4631 Fax: 417-673-5001
Printed in USA
www.detectoscale.com
Technical Support: Ph: 866-254-8261 techsupport@cardet.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 854F Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cardinal 854F Series

Summary of Contents for Cardinal 854F Series

  • Page 1 This Document is Hosted by: www.oldwillknottscales.com PORTABLE PLATFORM SCALES BEAM TYPE SERIES 854F/954F Owner’s Manual CARDINAL SCALE MFG. CO. 0066-M110-O1 Rev H PO Box 151 Webb City, MO 64870 09/11 Ph: 417-673-4631 Fax: 417-673-5001 Printed in USA www.detectoscale.com Technical Support: Ph: 866-254-8261 techsupport@cardet.com...
  • Page 3 854DB DOUBLE BEAM PARTS LIST ..........9 Thank you for purchasing our Detecto 854F/954F Series Scale. Manufactured with Detecto quality and reliability at our factory in Webb City, Missouri U.S.A., this scale has been calibrated and tested before leaving our factory to insure accuracy and dependability for years to come.
  • Page 4 2. Insert column (B) into scale base assembly (A) and secure with two 3/8 split lock washers and two 3/8 -16 hex nuts. NOTE: Detecto decal should be facing toward the platform. 3. Lower steelyard rod assembly (C) into column (B).

  • Page 5: Base Assembly

    BASE ASSEMBLY Figure Number 2 BASE ASSEMBLY PARTS DIAGRAM Item No. 854F Part No. 954F Part No. Part Name Quantity 0066-C017-08 0066-D057-0A Deck Plate 0066-D012-0A 0066-D107-0A Weighbridge Assembly 0066-D006-0A 0066-D060-0A Long Lever Assembly 0066-D007-0A 0066-D061-0A Short Lever Assembly 0066-B004-0A 0066-B004-0A...
  • Page 6 Figure Number 3 COLUMN ASSEMBLY PARTS DIAGRAM...

  • Page 7: Column Assembly

    854F/954F 6P23 3/8 - 16 Hex Nut 854F/954F 593M729 Serial No. Plate 854F/954F 6680-0073 Pop Rivet 854F/954F 6PSS1002 Detecto Logo Decal 854F/954F 6PP3000X Weight Pack Assembly 1000lb 854F100P 6PP3050X Weight Pack Assembly 500lb 854F50P 6PK2500X Weight Pack Assembly 500kg 854F50K...
  • Page 8 Figure Number 4 BEAM ASSEMBLY PARTS DIAGRAM...

  • Page 9: Beam Assembly

    BEAM ASSEMBLY Item No. 854F Part No. 954F Part No. Part Name Quantity Model No. 6P10037 6P10037 Beam 52 & 53 6P11037 6P11037 Insert 100lb (Rear) 854F100P/954F100P 6P11137 6P11137 Insert 100lb (Front) 854F100P/954F100P 6P11042 Insert 50lb (Rear) 854F50P 6P11142 Insert 50lb (Front)
  • Page 10 854DB DOUBLE BEAM SCALE Figure Number 5 DOUBLE BEAM ASSEMBLY PARTS DIAGRAM...
  • Page 11 854DB DOUBLE BEAM SCALE (Assembly for avoirdupois, unit available in metric) Only 1700 Demountable Heads can be used with these scales. ITEM PART PART NAME QUANTITY NUMBER NUMBER 6P7037X Beam W/Pivots 6P6042 Tare Beam 6P11138 Insert 50K Front 6P11038 Insert 50K Rear 6P11137 Insert 100P Front 6P11037...

  • Page 12: Statement Of Limited Warranty

    (1) year from date of shipment. Detecto shall be the sole judge of what constitutes a defect.
  • Page 13 This warranty sets forth the extent of our liability for breach of any warranty or deficiency in connection with the sale or use of the product. Detecto will not be liable for consequential damages of any nature, including but not limited to, loss of profit, delays or expenses, whether based on tort or contract.

This manual is also suitable for:

954f series
