DIGITAL PHYSICIAN
Waist-High Scale
Model 8430 Series
Operating Instructions
CARDINAL SCALE MFG. CO.
8525-M041-O1 Rev K
Printed in USA
PO BOX 151 WEBB CITY, MO 64870
10/12
PH (417) 673-4631 FAX (417) 673-5001
www.detectoscale.com
Technical Support: Ph: 866-254-8261 techsupport@cardet.com
Advertisement
Table of Contents
Related Manuals for Cardinal Detecto 8430 Series
Summary of Contents for Cardinal Detecto 8430 Series
-
Page 1: Operating Instructions
This Document is Hosted by: www.oldwillknottscales.com DIGITAL PHYSICIAN Waist-High Scale Model 8430 Series Operating Instructions CARDINAL SCALE MFG. CO. 8525-M041-O1 Rev K Printed in USA PO BOX 151 WEBB CITY, MO 64870 10/12 PH (417) 673-4631 FAX (417) 673-5001 www.detectoscale.com... -
Page 3: Specifications
Power ………………..6 “C” cell Alkaline, Ni-Cad or NiMH batteries (not included) OR an optional 115 VAC 50/60Hz 12 VDC 300 mA wall plug-in UL/CSA listed AC power adapter, Cardinal part number 728R121. Also available, for 230 VAC operation, Cardinal part number 728R901. -
Page 4: Unpacking Instructions
UNPACKING INSTRUCTIONS Remove scale from carton by lifting up with equal force from column and platform base. Check for any damage incurred in shipping. If scale has been damaged, place a claim with the carrier. Use the original carton and shipping material to return the scale. Remove all plastic wrapping, foam fillers and cardboard material from the scale. - Page 5 ASSEMBLY INSTRUCTIONS, CONT. Grommet Load Cell Cable Figure No. 1 Figure No. 3 Column Raise Draft Push Draft Column Lever Bracket Opening Figure No. 4 Indicator Bracket #10-32 Screw Lock Washer Figure No. 2 8525-M041-O1 Rev K 8430 Series...
-
Page 6: Basic Operation
OPERATION 758C Keypad Basic Operation To Weigh 1. Press ON/OFF key to turn indicator on. 2. Press ZERO key to zero weight display. ZERO, GROSS and lb, oz, kg or ST annunciator will turn on to show that the scale is ready for use. 3. -
Page 7: Basic Operation With Id
OPERATION, CONT. Basic Operation with ID – (No BMI) To Weigh 1. Press ON/OFF key to turn indicator on. 2. Press ZERO key to zero weight display. ZERO, GROSS and lb, oz, kg or ST annunciator will turn on to show scale is ready for use. 3. - Page 8 OPERATION, CONT. Body Mass Index (BMI) Operation with ID To Weigh and Calculate BMI 1. Press ON/OFF key to turn indicator on. 2. Press ZERO key to zero weight display. ZERO, GROSS and lb, oz, kg or ST annunciator will turn on to show scale is ready for use. 3.
-
Page 9: Height Rod Instructions
HEIGHT ROD INSTRUCTIONS Height Rod Hole Location 2” Please check Height Rod hole locations before installing Height Rod. Some models may require holes to be drilled. Please follow the measurements for drilling holes if necessary. 9/64” diameter After holes have been drilled, please holes, 1”... - Page 10 HEIGHT ROD INSTRUCTIONS, CONT. 3. Place the large end of the slotted holes in the height rod brackets over the four hex head screws on the back of the column. Height Rod Bracket 4. Pull down to set the screws in the small end of the slotted hole and secure the bracket to the column.
- Page 11 HEIGHT ROD INSTRUCTIONS, CONT. Height Rod Operating Guide 1. Before the person steps onto the scale Spoon platform, the spoon should be rotated to the horizontal position, and raised well above the person’s apparent height. 2. The person may now step onto the scale platform.
- Page 12 OPTIONAL WHEELS INSTALLATION How to Setup the Scale with Roller Wheels. 1. Remove the two lower screws in the back Screws and of the column. wheel bracket 2. Place the wheel bracket against the back of the column and align the holes in the bracket with the holes in the column.
-
Page 13: Error And Status Displays
ERROR AND STATUS DISPLAYS Display Meaning General error, invalid keypad entry was attempted. -Err- Attempting to display a negative number greater than –9,999 or a -OF- positive number greater than 99,999 Indicates an attempt to zero a weight outside scale zero range. Refer to -trL- the Setup and Calibration trL= (Four Percent Zero Tracking Range Limit) parameter. -
Page 14: Parts Identification
PARTS IDENTIFICATION FINAL ASSEMBLY ITEM PART NUMBER DESCRIPTION 3P1201X-1 BASE ASSEMBLY 0033-X306-0A BASE ASSY S.S. FOR 8430S, 8431S, 8437S 430XG3R800 COLUMN ASSEMBLY FOR 6127(KG), 6129(KG) 0033-B315-0A COLUMN ASSEMBLY FOR 8430S, 8431S, 8437S 709GR1206 LOAD CELL ASSY 0033-B254-08 DRAFT ROD FOR 8430 SERIES 3P8068 PLATFORM COVER 63K1038... - Page 15 PARTS IDENTIFICATION, CONT. FINAL ASSEMBLY, CONT. 8525-M041-O1 Rev K 8430 Series...
-
Page 16: Base Assembly
PARTS IDENTIFICATION BASE ASSEMBLY ITEM PART NUMBER DESCRIPTION 3P2011X PLATFORM WELDMENT 3P2087 PLATFORM LOAD BEARING 3P1001X BASE WELDMENT 0033-D307-0A BASE ASSY S.S. FOR 8430S, 8431S, 8437S 3P60 CHECK PLATE 6021-0985 HEX WASHER HD SCW #10 X 1/2 63K1038 BASE LEG 2U58 UNION CENTER HANGER 3P8003X... - Page 17 PARTS IDENTIFICATION, CONT. BASE ASSEMBLY, CONT. 8525-M041-O1 Rev K 8430 Series...
-
Page 18: Statement Of Limited Warranty
STATEMENT OF LIMITED WARRANTY Detecto Scale warrants its equipment to be free from defects in material and workmanship as follows: Detecto warrants to the original purchaser only that it will repair or replace any part of equipment which is defective in material or workmanship for a period of one (1) year from date of shipment. - Page 19 STATEMENT OF LIMITED WARRANTY Conditions Which Void Limited Warranty This warranty shall not apply to equipment which: A.) Has been tampered with, defaced, mishandled or have had repairs and modifications not authorized by Detecto. B.) Has had serial number altered, defaced, or removed. C.) Has not been grounded according to Detecto’s recommended procedure.
- Page 20 8525-M041-O1 Rev K 8430 Series 8525-M041-O1 Rev K 8430 Series...
