Specifications

Standards
Band, Frequency
Packet Data
Circuit Switched Data
Power Requirements
Mechanical Dimensions & Weight
Connectors & Fasteners
Operating Temperatures
Storage Temperatures
Humidity
Features
Certifications
Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide
General Specifications
CDMA2000 1xRTT operation
Dual-band 800/1900 MHz CDMA;
800 MHz or 800/1900 MHZ with R-UIM support
Up to 153K bps forward and reverse
CDMA IS-95-A, IS-95B up to 14.4K bps
5 V to 32VDC
4.3" L x 2.4" W x 0.94" H; 4.2 oz.
(11 cm x 6.1 cm x 2.4 cm; 119 g)
Antenna Connection type: SMA jack
Serial Connector: 15-pin RS232 SUB D female (DE15S)
Pins: RS232 link, audio link, RESET
Power Connector: 2.5mm miniature power jack
-30° to +70°C
-40° to +85°C
Relative humidity 20% to 90% noncondensing
Desktop or panel mounting
Short Message Service features including SMS mobile originated, SMS
mobile terminated, cell broadcast, Over the Air Activation (OTA),
OTASP, OTAPA
Voice features include DTMF, telephony, OCELP 13K, echo cancellation
AT command compatible
Phone book management and Personal Information Management (PIM)
Fixed dialing number
Supplementary services including call forwarding, call barring, multiparty,
call waiting and call hold, calling line identification, closed user group,
call transfer
Numerous LEDs present operational status
Real time clock
Alarm management
EMC: FCC Part 2, 15, 22, 24, EN 55022, EN 55024
Safety: cUL, UL 60950, EN 60950
Network: CDG 1 & 2
Chapter 1 – Product Description and Specifications
