- Page 1 2x2 HDMI Switcher U S E R M A N U A L www.gefen.com...
- Page 2 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. 2x2 Switcher for HDMI is a trademark of Gefen Inc. HDMI is a trademark of hdmi.org...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Introduction 2 Features 3 Panel Descriptions 4 Connecting and Operating the 2x2 Switcher for HDMI 5 RMT-2IR Installation 6 IR Code Confl icts 7 EDID Management Feature 8 EDID management Modes 9 RS-232 Serial Communication 10 RS-232 Serial Communication Commands 11 Specifi... -
Page 4: Introduction
Our Commitment Gefen will always offer the fi nest quality product at the best possible price. Included in that price is a lifetime support from a team of outstanding engineers. The Gefen 2x2 Switcher for HDMI allows two HDTV HDMI devices to be switched easily in to two HDTV HDMI compatible monitors or projectors. -
Page 5: Features
FEATURES Features • Switches easily between any two HDMI sources • Maintains 480p, 720p, 720i, and 1080i, 1080p resolutions • Maintains highest HDMI single link video resolution • Maintains highest HDMI digital audio signal • Includes TOSlink output for easy hookup to digital audio systems •... -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS Power LED Extender Indicator port Indicates if input 1 IR eye or 2 is selected Connects to RS232 HDMI In 1 HDMI In 2 HDMI Out 1 HDMI Out 2 5VDC power Controller supply Port TOSLINK Optical Out... -
Page 7: Connecting And Operating The 2X2 Switcher For Hdmi
CONNECTING AND OPERATING THE 2X2 SWITCHER FOR HDMI How to Connect the 2x2 Switcher for HDMI to your devices 1 Connect the supplied cables from the HDTV sources into the 2x2 Switcher for HDMI inputs. 2 Connect the cable from your display (monitor or projector) into the HDMI outs of the 2x2 Switcher for HDMI. -
Page 8: Rmt-2Ir Installation
RMT-2IR INSTALLATION 1. Remove battery cover from the back of the RMT-2IR remote. 2. Verify that dip switches 1 & 2 are in the down (OFF) position. 3. Insert the battery, hold the battery so that you can see the positive side facing up. The side that is not marked must be facing down. -
Page 9: Ir Code Confl Icts
IR CODE CONFLICTS Why would I need to change the remote channel? In some instances, the 2x2 Switcher for HDMI may use IR codes that confl ict with other IR remote control devices. The unit may switch inputs when another brand IR remote control is used or the RMT-2IR may cause other brand IR controlled devices to behave unexpectedly. -
Page 10: Edid Management Feature
EDID MANAGEMENT FEATURE EDID. What is it and what is it used for? Under normal circumstances, an source device (digital and analog) will require information about a connected device/display to assess what resolutions and features are available. The source can then cater its output to send only resolutions and features that are compatible with the attached device/display. -
Page 11: Edid Management Modes
EDID MANAGEMENT MODES v. 2015 EDID Modes The diagram below illustrates the 8 DIP switch bank. DIP SWITCH Function EDID Mode EDID Mode IR Channel IR Channel EDID Mode EDID Mode Use DIP switches 1, 2, 5, and 7 to select the desired EDID management mode. EDID Mode 0 (Switch 1=OFF Switch2=OFF Switch5=ON) •... -
Page 12: Rs-232 Serial Communication
RS-232 SERIAL COMMUNICATION What features are available via the RS-232 serial communications port? The 2x2 Switcher for HDMI can accept commands through the RS-232 serial communications port located on the rear panel. The current RS-232 control features are: • Switching/routing of inputs to outputs without the RMT-2IR remote control. •... -
Page 13: Rs-232 Serial Communication Commands
RS-232 SERIAL COMMUNICATION COMMANDS Switching/Routing Binary Table ASCII RMT-2IR Binary Button 0011 0001 0011 0010 EDID Management Modes All DIP switches inside the unit must be in their default OFF position. Use the ASCII commands below to change the EDID modes. For a description of each mode please see page 8. - Page 14 SPECIFICATIONS Video Amplifi er Bandwidth ................. 1.65 GHz Input Video Signal ..................1.2 volts p-p Input DDC Signal ..................5 volts p-p (TTL) Single Link Range ................1080p / 1920 x 1200 Input Connector Type ....................HDMI Output Connector Type ....................HDMI Output Audio Connector Type.................
