Gefen 2X2 VGA SWITCHER User Manual

2x2 vga switcher
Hide thumbs

Advertisement

Quick Links

Download this manual
Optional
2x2 VGA Switcher
Accessories
Switches extended desktop dual VGA displays, USB 1.1 & audio between
any two computers
Our 2x2 VGA Switcher enables you to connect and access two computers using one workstation
equipped with dual VGA monitors and one USB keyboard/mouse. Analog video, keyboard/mouse
control and audio are "switched" for each computer, providing you with an easy and effective way
to alternate access to greater amounts of data at the touch of a button.
RMT-4 (2 Button)
Dual monitors, in this case, refers to the use of two monitors that are running an extended desktop
setup so that the entire digital image is extended over two monitors providing a greater digital
Related Products
desktop on which to work. The 2x2 switcher will not mirror the same desktop but will provide
support for dual displays.
The 2x2 switcher will NOT switch between four computers and two displays or four computers and
one display.
How It Works
You simply connect both computer's VGA video, USB and audio ports to the 2x2 VGA Switcher's
inputs using the supplied cables. Then you connect both VGA displays, the USB keyboard/mouse
and an optional audio device to the Switcher's outputs. Once powered and connected, you switch
between computers by key switch or remotely using contact closure remote control.
Note:
Features:
Switches easily between any two dual VGA computers with USB 1.1 and audio
Output to two extended desktop VGA displays
Maintains highest 1920 x 1200 resolution video
Use either PC or Mac USB 1.1 keyboard/mouse
Front panel switching
Parallel remote port (RMT-4 not included)
Supports resolutions up to 1080p, 2K, 1920 x 1200
Includes rack ears

Specifications:

Video Amplifier Bandwidth: 350 MHz
Input Video Signal: 1.2 volts p-p
Input Sync Signal: 5 volts p-p (TTL)
Horizontal Frequency Range: 15 - 70 KHz
Vertical Frequency Range: 30 - 170 Hz
Video Connector: DVI-I 29 pin female (analog only)
USB Input Connection: type "B"
USB Output Connection: type "A"
Power Supply: 12V AC
Power Consumption: 18 watts (max)
Dimensions: 17"W x 1.75"H x 4.375"D
Rackmountable: 1U Rack space
Shipping Weight: 10 lbs.

Package Includes:

2x2 VGA Switcher
12V power supply
Four 6ft DVI-A to VGA cables Male to Male
Two DVI-A to VGA Adapter Male to Female
Two 6ft USB cables
Two audio cable
Rack Ears

Product Options:

ext-vga-422
Dystrybucja i sprzedaż: Meditronik Sp. z o.o.
02-952 Warszawa, ul. Wiertnicza 129, tel. (+48 22) 651-72-42, fax (+48 22) 651-72-46
http://www.meditronik.com.pl
e-mail: office@meditronik.com.pl
EXT-VGA-422

Advertisement

loading

Related Manuals for Gefen 2X2 VGA SWITCHER

Summary of Contents for Gefen 2X2 VGA SWITCHER

  • Page 1: Specifications

    How It Works You simply connect both computer's VGA video, USB and audio ports to the 2x2 VGA Switcher's inputs using the supplied cables. Then you connect both VGA displays, the USB keyboard/mouse and an optional audio device to the Switcher's outputs. Once powered and connected, you switch between computers by key switch or remotely using contact closure remote control.
  • Page 2 2x2 VGA Switcher U S E R M A N U A L www.gefen.com...
  • Page 3 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. The 2x2 VGA Switcher is a trademark of Gefen Inc. © 2007 Gefen Inc., All Rights Reserved...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Introduction Front Panel Descriptions Back Panel Descriptions How To Connect The 2x2 VGA Switcher System Specifi cations Warranty...
  • Page 5 OPERATION NOTES READ THESE NOTES BEFORE IN STALL ING OR OPERATING THE 2X2 VGA SWITCHER • The 2x2 VGA Switcher is housed in a metal box for better RF shielding.

  • Page 6: Introduction

    Now you can switch easily and reliably between any combination of two computers using two VGA displays, USB keyboard and mouse. The 2x2 VGA Switcher saves space – there’s no need to work on a desk crowded with four monitors, keyboards and mouse devices. It saves time – there’s no need to move from one monitor to another to access different computers.

  • Page 7: Front Panel Descriptions

    FRONT PANEL DESCRIPTIONS...

  • Page 8: Back Panel Descriptions

    BACK PANEL DESCRIPTIONS...

  • Page 9: How To Connect The 2X2 Vga Switcher

    Audio connection in the back of the 2x2 VGA Switcher. 3- Connect the monitors to the VGA Out (1 and 2) connections. 4- Plug the 12v power supply into the 2x2 VGA Switcher. 5- Plug the 12v wallmount power supply into the wall outlet.
  • Page 10 2x2 VGA WIRING DIAGRAM...
  • Page 11 SPECIFICATIONS Video Amplifi er Bandwidth ................. 350 MHz Single Link Range ..................1920 x 1200 Vertical Frequency Range ..................60 Hz DVI Input/Output Connector Type ................DVI-I USB Input Connector ..................Type “B” USB Output Connector ..................Type “A” Power Consumption ................18 Watts (max.) Power Supply .......................

  • Page 12: Warranty

    Gefen Inc. warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
