6. Finger tighten three Handrail Bolts (64) with
three Star Washers (90) into the Right Upright
(74). Next, finger tighten three Handrail Bolts
with three Upright Star Washers (not shown) into
the Left Upright (73). Then, firmly tighten the six
Handrail Bolts.
7. Slide the Right Upright Sleeve (96) up against
the console assembly. Attach the Right Upright
Sleeve with two 3/4" Screws (4).
Attach the Left Upright Sleeve (not shown) to
the Left Upright (73) as described above.
6
73
64
7
73
9
64
90
74
90
4
96
4
74
