This indicates reserve. If you run out of
fuel while riding, move the lever to this
position. Fill the tank at the first oppor-
tunity. Be sure to set the lever back to
"ON" after refueling!
INSTRUMENT AND CONTROL FUNCTIONS
Starter (choke) knob "
1
(a) (b)
1. Starter (choke) knob " "
Starting a cold engine requires a richer
air-fuel mixture, which is supplied by
the starter (choke).
Move the knob in direction (a) to turn on
the starter (choke).
Move the knob in direction (b) to turn off
the starter (choke).
3-9
EAU13600
"

Seat

To remove the seat
Remove the bolts, and then pull the
seat off.
1
1. Bolt
To install the seat
1. Insert the projection on the front of
the seat into the seat holder as
shown.
EAU13970
