- Page 1 Digital Blood Pressure Monitor Model UA-767NFC Instruction Manual 1WMPD4002380...
-
Page 2: Table Of Contents
Contents Dear Customers..............2 Preliminary Remarks ............. 2 Precautions................2 Parts Identification..............3 Symbols................4 Operation Mode..............6 Using the Monitor ..............7 Installing / Changing the Batteries ........7 Connecting the Air Hose ..........7 Connecting the AC Adapter..........7 Notes on the Built-in Clock .......... -
Page 3: Dear Customers
Dear Customers Congratulations on purchasing a state-of-the-art A&D blood pressure monitor, one of the most advanced monitors available today. Designed for ease of use and accuracy, this monitor will facilitate your daily blood pressure regimen. We recommend that you read through this manual carefully before using the device for the first time. -
Page 4: Parts Identification
Parts Identification Air Hose DC Jack Proper Fit Range Communication Area Index Mark Artery Position Mark Arm Cuff START Button Air Connector Plug Display Air Socket Clock Button Battery Compartment Button Battery Cover 1.5V Batteries (R6P, LR6 or AA) Display Systolic Pressure MEMORY Diastolic Pressure... -
Page 5: Symbols
Symbols Symbols that are printed on the device case Symbols Function / Meaning Recommended Action Standby and Turn the device on. SYS. Systolic blood pressure in mmHg DIA. Diastolic blood pressure in mmHg PUL./min. Pulse per minute Battery installation guide Direct current Serial number Date of manufacture... - Page 6 Symbols Symbols Function / Meaning Recommended Action The battery power indicator during measurement. Full Battery Replace all batteries with new The battery is low when it blinks. ones when the mark blinks. Low Battery Take another measurement. Unstable blood pressure due to Remain very still during movement during measurement.
-
Page 7: Operation Mode
Operation Mode 1. Normal Measurement Press the START button. Blood pressure is measured and the data is stored in memory. 2. Memory Function This monitor can store the last 100 measurements in memory. When the measurement exceeds 100, the oldest data will be deleted automatically and the most recent data will be stored. -
Page 8: Using The Monitor
Using the Monitor Installing / Changing the Batteries Step 1 1. Slide the battery cover up to open it. Step 3 2. Remove the used batteries and insert batteries into battery compartment as shown, taking care that the polarities (+ and -) are correct. Use only R6P, LR6 or AA batteries. -
Page 9: Notes On The Built-In Clock
Using the Monitor Notes on the Built-in Clock The monitor displays the clock as long as power is connected. Adjust the clock prior to use. The current clock setting will be cleared if the batteries are removed, or power is not connected for approximately 30 seconds while the AC adapter is used. -
Page 10: Adjusting The Clock
Using the Monitor Adjusting the Clock Press and 1. Press and hold the button until hold the year starts blinking. Year 2. Select the year using the button. Press the button to set the current year and move to month/day selection. The date can be set anywhere between the years 2011 and 2055. -
Page 11: Selecting The Correct Cuff Size
Using the Monitor Selecting the Correct Cuff Size Using the correct cuff size is important for an accurate reading. If the cuff is not the proper size, the reading may yield an incorrect blood pressure value. The arm size is printed on each cuff. The index and proper fit range, on the cuff, tell you if you are applying the correct cuff. -
Page 12: How To Take Proper Measurements
Using the Monitor Symbols that are printed on the cuff Symbols Function/Meaning Recommended Action Set the mark on the artery of the upper arm or in line with Artery Position Mark the ring finger on the inside of the arm. ▲... -
Page 13: Measurements
Measurements Before measurement, read “Notes for Proper Measurement” on the next page. Normal Measurement Place the cuff on the arm (preferably the left arm). At heart level Sit quietly during measurement. Press the button. START The number of data stored in memory is Press START displayed. -
Page 14: Measurement With The Desired Systolic Pressure
Measurements Measurement with the Desired Systolic Pressure Model UA-767NFC is designed to detect the pulse and to inflate the cuff to a systolic pressure level automatically. Use this method when re-inflation occurs repeatedly or when the results are not displayed even if the pressure decreases to 20 mmHg or less. -
Page 15: Near Field Communication (Nfc) Function
Near Field Communication (NFC) Function To transmit data to or from the blood pressure monitor, communication devices that comply with the communication specifications of the blood pressure monitor are required. Examples of communication devices that comply NFC-enabled cellular phone Personal computer with NFC reader/writer Access Point Memory Data Transmission While the blood pressure monitor displays the clock, hold the... -
Page 16: Caution On Using The Nfc Function
Caution on Using the NFC Function The UA-767NFC blood pressure monitor has an NFC Forum Type 3 Tag wireless interface module built in. When the monitor is used near wireless communication devices which use the same frequency as that of the monitor (13.56 MHz) or use its harmonic frequencies, electromagnetic interference may occur. -
Page 17: What Is Hypertension And How Is It Controlled
About Blood Pressure What is Hypertension and How is it Controlled? Hypertension, an abnormally high arterial blood pressure, if left unattended, can cause many health problems including stroke and heart attack. Hypertension can be controlled by altering lifestyle, avoiding stress, and with medication under a doctor’s supervision. -
Page 18: Troubleshooting
Troubleshooting Problem Possible Reason Recommended Action Replace all batteries with new Nothing Batteries are drained. ones. appears on the Reinstall the batteries with display, even Battery terminals are not negative and positive terminals when the power in the correct position. matching those indicated on the is turned on. -
Page 19: Maintenance
However it is generally recommended to have the device inspected every 2 years, to ensure proper functioning and accuracy. Please contact the authorized dealer in your area or A&D for maintenance. Technical Data Type UA-767NFC Measurement method Oscillometric measurement Measurement range Pressure: 0 - 280 mmHg... - Page 20 A&D Company, Limited 1-243 Asahi, Kitamoto-shi, Saitama 364-8585 JAPAN Telephone: [81] (48) 593-1111 Fax: [81] (48) 593-1119 A&D INSTRUMENTS LTD. Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485 A&D Australasia Pty Ltd.
