Digital Blood Pressure Monitor Model UA-767 BT-Ci Instruction Manual Original ’ Manuel d instructions Traduction Manual de Instrucciones Traducción Manuale di Istruzioni Traduzione Bedienungsanleitung Übersetzung 1WMPD4003087...
Contents Dear Customers ...............2 Preliminary Remarks..............2 Precautions ................2 Parts Identification ..............4 Symbols ...................5 Using the Monitor..............7 Installing / Changing the Batteries ........7 Connecting the Air Hose ............7 Connecting the AC Adapter..........7 Wireless Function..............8 Bluetooth ® Transmission .............8 Pairing / Unpairing ..............9 Selecting the Correct Cuff Size ...........11 Applying the Arm Cuff ............12 How to Take Accurate Measurements ........12...
Dear Customers Congratulations on purchasing a state-of-the-art A&D blood pressure monitor, one of the most advanced monitors available today. Designed for ease of use and accuracy, this monitor will facilitate your daily blood pressure regimen. We recommend that you read through this manual carefully before using the device for the first time.
Page 4
Measurements may be distorted if the device is used close to televisions, microwave ovens, cellular telephones, X-ray or other devices with strong electrical fields. Used equipment, parts and batteries are not treated as ordinary household waste, and must be disposed of according to the applicable local regulations. When the AC adapter is used, make sure that the AC adapter can be readily removed from the electrical outlet when necessary.
Parts Identification DC Jack Button Display START Air Connector Plug Air Socket Air Hose Proper Fit Range Artery Position Mark Index Mark Arm Cuff Battery Cover Battery Compartment 1.5V Batteries (LR6, R6P or AA) Systolic Pressure MEMORY Part of Display Diastolic Pressure Pressure Bar Indicator Pulse Rate...
Symbols Symbols Function / Meaning Recommended Action Standby and power on. Battery installation guide Direct current Type BF: Device, cuff and tubing are designed to provide special protection against electrical shocks. Appears while measurement is in Measurement is in progress. It blinks when the pulse is progress.
Page 7
Symbols Function / Meaning Recommended Action EC directive medical device label R&TTE directive transmitter module label Manufacturer EU-representative Date of manufacture WEEE label Refer to instruction manual/booklet Serial number Polarity of DC jack International protection symbol English 6...
Using the Monitor Step 1 Installing / Changing the Batteries Step 3 Slide the battery cover up to open it. Remove the used batteries and insert new batteries into the battery compartment as shown, taking care that the polarities (+) and (-) are correct. Step 2 Slide the battery cover down to close.
Using the Monitor Wireless Function CAUTION In the unlikely event that this monitor causes radio wave interference in a different wireless station, change the location where this monitor is used or stop use immediately. Be sure to use in a location where visibility between the two devices that you want to connect is good.
Using the Monitor Pairing / Unpairing A Bluetooth® device needs to be paired with a different specific device in order to communicate with that device. If this monitor is paired with a receiver device from the start, measurement data is transmitted automatically to the receiver device each time a measurement is made.
Page 11
Using the Monitor Unpairing procedure Press and hold the button until “upr” is START displayed. Press the button again. Unpairing will be START performed. The monitor displays “end” to indicate that unpairing is complete. When two receiver devices are paired, both devices are unpaired.
Using the Monitor Selecting the Correct Cuff Size Using the correct cuff size is important for an accurate reading. If the cuff is not the proper size, the reading may yield an incorrect blood pressure value. The arm size is printed on each cuff. The index and proper fit range, on the cuff, tell you if you are applying the correct cuff.
Using the Monitor Applying the Arm Cuff Do not roll up shirtsleeve tightly Wrap the cuff around the upper arm, Cuff about 1-2 cm above the inside of the 1 to 2 cm elbow, as shown. Place the cuff directly against the skin, as clothing may cause a faint pulse, and result in a measurement error.
Measurements Model UA-767 BT-Ci is designed to detect the pulse and to inflate the cuff to a systolic pressure level automatically. If your systolic pressure is expected to exceed 230 mmHg, read "Measurement with the Desired Systolic Pressure" on the next page. Normal Measurement Place the cuff on the arm (preferably the left arm).
Measurements Measurement with the Desired Systolic Pressure If your systolic pressure is expected to exceed 230 mmHg, use this procedure. Place the cuff on the arm At heart level (preferably the left arm). Press Press the button. START The last data While the zero blinks, press and hold at initial display button until a number...
What is an Irregular Heartbeat Model UA-767 BT-Ci blood pressure monitor provides a blood pressure and pulse rate measurement even when an irregular heartbeat occurs. An irregular heartbeat is defined as a heartbeat that varies by 25% from the average of all heartbeats during the blood pressure measurement.
About Blood Pressure What is Blood Pressure? Blood pressure is the force exerted by blood against the walls of the arteries. Systolic pressure occurs when the heart contracts. Diastolic pressure occurs when the heart expands. Blood pressure is measured in millimeters of mercury (mmHg).
Take measurements at the same time every Typical fluctuation within a day (Measured every five minutes) day using the procedure described in this Systolic manual to get to know your normal blood pressure. Regular readings give a more comprehensive blood pressure history. Be sure to note date and time when recording your blood pressure.
2 years, to ensure proper functioning and accuracy. Please contact the authorized dealer in your area or A&D for maintenance. Technical Data Type UA-767PBT-Ci Measurement method Oscillometric measurement Measurement range Pressure: 20 - 280 mmHg...
Page 20
Useful life Device: 5 years (when used six times a day) Cuff: 2 years (when used six times a day) Accessory AC adapter The adapter is to connect the blood pressure monitor to a power source at home. TB-233 Please contact your local A&D dealer for purchasing.
Page 21
1-243 Asahi, Kitamoto-shi, Saitama 364-8585 JAPAN Telephone: [81] (48) 593-1111 Fax: [81] (48) 593-1119 A&D INSTRUMENTS LIMITED Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485 A&D ENGINEERING, INC. 1756 Automation Parkway, San Jose, California 95131 U.S.A.
