  • Page 1 Digital Blood Pressure Monitor Model UA-767S-W English Instruction Manual Original Français Manuel d’instructions Traduction Español Manual de Instrucciones Traducción Italiano Manuale di Istruzioni Traduzione Português Manual de instruções Tradução Nederlands Instructiehandleiding Vertaling Dansk Betjeningsvejledning Oversættelse Svenska Bruksanvisning Översättning Norsk Bruksanvisning...

  • Page 2: Table Of Contents

    Contents Dear Customers ..............2 Preliminary Remarks ............. 2 Precautions ................2 Parts Identification ..............5 Symbols ................6 Operation Mode ..............8 Using the Monitor ..............9 Installing / Changing the Batteries ........9 Connecting the Air Hose ..........10 Connecting the AC Adapter ..........

  • Page 3: Dear Customers

    Dear Customers Congratulations on purchasing a state-of-the-art A&D blood pressure monitor, one of the most advanced monitors available today. Designed for ease of use and accuracy, this device will facilitate your daily blood pressure regimen. We recommend that you read through this manual carefully before using the device for the first time.
  • Page 4 Used equipment, parts and batteries are not treated as ordinary household waste, and must be disposed of according to the applicable local regulations. When the AC adapter is used, make sure that the AC adapter can be readily removed from the electrical outlet when necessary. Do not modify the device.
  • Page 5 Do not use the device where flammable gases such as anesthetic gases are present. It may cause an explosion. Do not use the device in highly concentrated oxygen environments, such as a high-pressure oxygen chamber or an oxygen tent. It may cause a fire or explosion.

  • Page 6: Parts Identification

    Parts Identification Display Air Connector Plug AC adapter Plug DC Jack Button START Air Socket Air Hose Proper Fit Range Artery Index Mark Arm Cuff Battery Compartment Battery Cover 1.5V Batteries (R6P, LR6 or AA) Display Average MEMORY IHB/AFib symbol Systolic %IHB/AFib Pressure...

  • Page 7: Symbols

    Symbols Symbols that are printed on the device case Symbols Function / Meaning Standby and Turn the device on. Systolic blood pressure in mmHg Diastolic blood pressure in mmHg Pulse per minute Battery installation guide Direct current Type BF: Device, cuff and tubing are designed to provide special protection against electrical shocks.
  • Page 8 Symbols Symbols Function / Meaning Recommended Action The reading may yield an Appears during measurement when incorrect value. Apply the the cuff is attached loosely cuff correctly, and try the measurement again. Detected rate of IHB/AFib in memory Number of detected IHB/AFibs in memory %IHB/AFib = x100 [%]...

  • Page 9: Operation Mode

    Operation Mode 1. Normal Measurement Press the button. Blood pressure is measured and the data is stored START in memory. This device can store the last 60 measurements in memory. 2. Recalling the Data In standby, When nothing is displayed, press and hold press and hold the button.

  • Page 10: Using The Monitor

    Using the Monitor Installing / Changing the Batteries Step 1 1. Remove the battery cover. Step 3 Step 1 2. Remove the used batteries and insert new batteries into the battery compartment as shown, taking care Step 2 that the polarities (+ and -) are correct.

  • Page 11: Connecting The Air Hose

    Using the Monitor Connecting the Air Hose Air socket Insert the air connector plug into the air socket firmly. Air connector plug Connecting the AC Adapter Insert the AC adapter plug into the DC jack. Next, connect the AC adapter to an electrical outlet.

  • Page 12: Selecting The Correct Cuff Size

    Adult Cuff CUF-F-A Arm size: The circumference at the biceps. Note: The UA-767S-W is not designed for using a small cuff. Applying the Arm Cuff 1. Wrap the cuff around the upper arm, Do not roll up shirtsleeve tightly. about 1 - 2 cm above the inside of Cuff the elbow, as shown.
  • Page 13 Using the Monitor Symbols that are printed on the cuff Symbols Function / Meaning Recommended Action Set the mark on the artery of the upper arm or Artery Position Mark in line with the ring finger on the inside of the arm. Index ▲...

  • Page 14: How To Take Accurate Measurements

    Using the Monitor How to Take Accurate Measurements For the most accurate blood pressure measurement: Sit comfortably on a chair. Rest your arm on the table. Do not cross your legs. Keep your feet flat on the floor and straighten your back. Relax for about five to ten minutes before measurement.

  • Page 15: Measurements

    Measurements Before measurement, refer to “Notes for Accurate Measurement” on the next page. Normal Measurement Place the cuff on the arm (preferably the left arm). Sit quietly during measurement. At heart level Press the button. START All of the display segments are displayed. Press START Zero (0) is displayed blinking briefly.

  • Page 16: Measurement With The Desired Systolic Pressure

    Measurements Measurement with the Desired Systolic Pressure The UA-767S-W is designed to detect the pulse and to inflate the cuff to a systolic pressure level automatically. Use this method when re-inflation occurs repeatedly or when the results are not displayed even if the pressure decreases to 20 mmHg or less.

  • Page 17: Recalling The Memory Data

    This device is intended for use by adults. Consult with your physician before using this device on a child. A child should not use this device unattended. The automatic blood pressure monitor’s performance may be affected by excessive temperature or humidity, or altitude. Recalling the Memory Data Note: This device stores the last 60 measurements in memory.

  • Page 18: What Is The Ihb/Afib Indicator

    What Is The IHB/AFib Indicator? When the monitor detects an irregular rhythm during the measurements, the IHB/AFib indicator will appear on the display with the measurement values. Note: We recommend contacting your physician if you see this IHB/AFib indicator frequently. What Is The AFib? The heart contracts due to electrical signals occurring in heart and sends blood through the body.

  • Page 19: Pressure Bar Indicator

    Pressure Bar Indicator The indicator monitors the progress of pressure during measurement. Pressurizing Releasing air Inflation in progress Measurement in progress Inflation complete WHO Classification Indicator Each segment of the bar indicator Example: corresponds to the WHO blood pressure classification described on the next page. WHO Classification Indicator Severe hypertension Moderate hypertension...

  • Page 20: What Is Hypertension And How Is It Controlled

    What is Hypertension and How is it Controlled? Hypertension, an abnormally high arterial blood pressure, if left unattended, can cause many health problems including stroke and heart attack. Hypertension can be controlled by altering lifestyle, avoiding stress, and with medication under a doctor’s supervision. To prevent hypertension or keep it under control: Do not smoke Exercise regularly...

  • Page 21: Troubleshooting

    Troubleshooting Problem Possible Reason Recommended Action Replace all batteries with new Batteries are drained. Nothing ones. appears on the Reinstall the batteries with display, even Battery terminals are not negative and positive terminals when the device in the correct position. matching those indicated on the is turned on.

  • Page 22: Maintenance

    However it is generally recommended to have the device inspected every 2 years, to ensure proper functioning and accuracy. Please contact the authorized dealer in your area or A&D for maintenance. Technical Data Type UA-767S-W Measurement method Oscillometric measurement Measurement range Pressure: 0 - 299 mmHg...
  • Page 23 Useful life Device: 5 years (when used six times a day) Cuff: 2 years (when used six times a day) AC adapter: 5 years (when used six times a day) Accessory AC adapter The adapter is to connect the device to a power source at home. Please contact your local A&D dealer for purchasing.
  • Page 24 1-243 Asahi , Kitamoto-shi, Saitama 364-8585, JAPAN Telephone: [81] (48) 593-1111 Fax: [81] (48) 593-1119 Emergo Europe B.V. Prinsessegracht 20, 2514 AP The Hague, The Netherlands Tel: [31] (70) 345-8570 Fax: [31] (70) 346-7299 A&D INSTRUMENTS LIMITED Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485 A&D ENGINEERING, INC.
