- Page 1 Digital Blood Pressure Monitor Model UA-767NFC Instruction Manual Original ’ Manuel d instructions Traduction Manual de Instrucciones Traducción Manuale di Istruzioni Traduzione Bedienungsanleitung Übersetzung 1WMPD4002380D...
-
Page 2: Table Of Contents
Contents Dear Customers .................... 1 Preliminary Remarks..................2 Precautions....................2 Parts Identification..................3 Symbols......................4 Operation Mode .................... 6 Using the Monitor..................7 Installing / Changing the Batteries............7 Connecting the AC Adapter ..............7 Connecting the Air Hose ..............8 Setting and Adjusting the Clock............ -
Page 3: Preliminary Remarks
Preliminary Remarks This device conforms to the European Directive 93/42 EEC for Medical Products. This is made evident by the mark of conformity. (0123: The reference number to the involved notified body) The device is designed for use on adults only, not newborns or infants. Environment for use. -
Page 4: Parts Identification
Do not use the device where flammable gases such as anesthetic gases are present. It may cause an explosion. Do not use the device in highly concentrated oxygen environments, such as a high-pressure oxygen chamber or an oxygen tent. It may cause a fire or explosion. Parts Identification Air Hose DC Jack... -
Page 5: Symbols
Symbols Symbols that are printed on the device case Symbols Function / Meaning Standby and Turn the device on. Systolic blood pressure in mmHg SYS. Diastolic blood pressure in mmHg DIA. Pulse per minute PUL./min. Battery installation guide Direct current Type BF: Device, cuff and tubing are designed to provide special protection against electrical shocks. - Page 6 Symbols Symbols Function / Meaning Recommended Action The battery power indicator during measurement. Full Battery Replace all batteries with new The battery is low when it blinks. ones when the mark blinks. Low Battery Take another measurement. Unstable blood pressure due to Remain very still during movement during measurement.
-
Page 7: Operation Mode
Operation Mode 1. Normal Measurement Press the button. Blood pressure is measured. START 2. Memory Function When the memory setting is 100: This device will store the last 100 measurements in memory. When the measurement exceeds 100, the oldest data will be deleted automatically and the most recent data will be stored. -
Page 8: Using The Monitor
Using the Monitor Installing / Changing the Batteries Step 1 1. Slide the battery cover up to open it. Step 3 2. Remove the used batteries and insert batteries into battery compartment as shown, taking care that the polarities (+ and -) are correct. Use only R6P, LR6 or AA batteries. -
Page 9: Connecting The Air Hose
Using the Monitor Connecting the Air Hose Insert the air connector plug into the air socket firmly. Air socket Air connector plug “Year” blinks when Setting and Adjusting the Clock inserting the batteries or Set or adjust the clock prior to use. Press and hold connecting the AC adapter 1. -
Page 10: Notes On The Built-In Clock
Notes on the Built-in Clock The device displays the clock as long as power is connected. Adjust the clock prior to use. During measurement, the clock adjustment is not available. When adjusting the clock, press the button to increase the value by one, or press and hold the button to change the value continuously. -
Page 11: Selecting The Correct Cuff Size
22 cm to 32 cm Adult Cuff CUF-F-A Arm size: The circumference of the biceps. Note: Model UA-767NFC is NOT designed for using a small adult cuff. Symbols that are printed on the cuff. Function / Meaning Recommended Action Symbols... -
Page 12: Applying The Arm Cuff
Using the Monitor Applying the Arm Cuff Do not roll up shirtsleeve tightly 1. Wrap the cuff around the upper arm, about 1 - 2 cm above the Cuff inside of the elbow, as shown. 1 to 2 cm Place the cuff directly against the skin, as clothing may cause a faint pulse, and result in a measurement error. -
Page 13: Measurements
Measurements Before measurement, read “Notes for Proper Measurement” on page 14. Normal Measurement 1. Place the cuff on the arm (preferably the left arm). At heart level Sit quietly during measurement. 2. Press the button. START Press START All of the display segments are displayed. Zero (0) is displayed blinking briefly. -
Page 14: Measurement With The Desired Systolic Pressure
Measurements Measurement with the Desired Systolic Pressure Model UA-767NFC is designed to detect the pulse and to inflate the cuff to a systolic pressure level automatically. Use this method when re-inflation occurs repeatedly or when the results are not displayed even if the At heart level pressure decreases to 20 mmHg or less. -
Page 15: Notes For Proper Measurement
Notes for Proper Measurement Sit down in a comfortable position. Place your arm on a table with your palm facing upward and the cuff at the same level as your heart. Relax for about five to ten minutes before taking a measurement. If you are excited or depressed by emotional stress, the measurement will reflect this stress as a higher (or lower) than normal blood pressure reading and the pulse reading will usually be faster than normal. -
Page 16: Near Field Communication (Nfc) Function
Near Field Communication (NFC) Function To transmit data to or from the device, communication devices that comply with the communication specifications of the device are required. Examples of communication devices that comply NFC-enabled cellular phone Personal computer with NFC reader/writer Access Point Displaying the Memory Data When the memory setting is 100, the memory data can be displayed. -
Page 17: Switching The Memory Setting
Switching the Memory Setting While the device displays the clock, hold the communication symbol of the NFC-enabled communication device close to the communication area ( ) of the device until “ ” appears. The memory setting is switched. Initiate Data communication transmission 100 blinks. -
Page 18: Transmitting The Memory Data
Caution on Using the NFC Function The UA-767NFC has an NFC Forum Type 3 Tag wireless interface module built in. When the device is used near wireless communication devices which use the same frequency as that of the device (13.56 MHz) or use its harmonic frequencies, electromagnetic interference may occur. -
Page 19: What Is An Irregular Heartbeat
What is an Irregular Heartbeat The UA-767NFC provides a blood pressure and pulse rate measurement even when an irregular heartbeat occurs. An irregular heartbeat is defined as a heartbeat that varies by 25% from the average of all heartbeats during the blood pressure measurement. -
Page 20: What Is Hypertension And How Is It Controlled
About Blood Pressure What is Hypertension and How is it Controlled? Hypertension, an abnormally high arterial blood pressure, if left unattended, can cause many health problems including stroke and heart attack. Hypertension can be controlled by altering lifestyle, avoiding stress, and with medication under a doctor’s supervision. -
Page 21: Troubleshooting
Troubleshooting Problem Possible Reason Recommended Action Batteries are drained. Replace all batteries with new ones. Nothing appears on the display, Reinstall the batteries with negative even when the Battery terminals are not in and positive terminals matching power is turned the correct position. -
Page 22: Maintenance
2 years, to ensure proper functioning and accuracy. Please contact the authorized dealer in your area or A&D for maintenance. Technical Data Type UA-767NFC Measurement method Oscillometric measurement Measurement range Pressure: 0 - 280 mmHg... - Page 23 Useful life Device: 5 years (when used six times a day) Cuff: 2 years (when used six times a day) Wireless communication NFC wireless interface module Accessory AC adapter The adapter is to connect the device to a power source at home. TB-233 Please contact your local A&D dealer for purchasing.
- Page 24 1-243 Asahi , Kitamoto-shi, Saitama 364-8585, JAPAN Telephone: [81] (48) 593-1111 Fax: [81] (48) 593-1119 A&D INSTRUMENTS LIMITED Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485 A&D ENGINEERING, INC. 1756 Automation Parkway, San Jose, California 95131, U.S.A.
