Summary of Contents for A&D UA-767

  • Page 1 One Step Auto-Inflation Blood Pressure Monitor Trilingual Instruction Guide – MODEL UA-767...
  • Page 2 Congratulations. You have purchased a LifeSource state-of-the-art blood pressure monitor, one of the most technologically advanced yet easy to use products available in the marketplace today. This LifeSource monitor is designed to make your daily regimen useful, and convenient. Physicians agree that daily self-monitoring of blood pressure is an important way individuals can contribute to maintaining their cardiovascular health and preventing the serious consequences of hypertension left...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS WHAT DISPLAY SYMBOLS MEAN ....3 MONITOR COMPONENTS ......4 HOW 767 WORKS .
  • Page 4: What Display Symbols Mean

    WHAT DISPLAY SYMBOLS MEAN Display Condition/ Recommended Symbol Cause Action Appears during measure- Remain still and refrain ment; blinks and beeps from talking; measure- when pulse is detected. ment in progress. Battery voltage is Replace all batteries too low for monitor with new ones.
  • Page 5: Monitor Components

    MONITOR COMPONENTS SYSTOLIC mmHg UA-767 DIGITAL DIASTOLIC BLOOD mmHg PRESSURE MONITOR PUL / min LifeSource Health Line (Toll-Free): 1-888-726-9966...
  • Page 6: How 767 Works

    HOW 767 WORKS LifeSource Blood Pressure Monitors are easy to use, accurate and digitally display full measurement readouts. Our technology is based on the “oscillometric method” — a noninvasive blood pressure determination. The term “oscillation” refers to any measure of vibrations caused by the arterial pulse. The cuff is first inflated until the artery is fully blocked.
  • Page 7: Selecting The Correct Cuff

    SELECTING THE CORRECT CUFF Using the correct cuff size is important for an accurate reading. A cuff that is too large will produce a reading that is lower than the correct blood pressure; a cuff that is too small yields a measurement that is higher.
  • Page 8: Taking Your Blood Pressure

    TAKING YOUR BLOOD PRESSURE Tips for Blood Pressure Monitoring: Relax for about 5 to 10 minutes before measurement. Remove constricting clothing and place cuff on bare arm. Unless your physician recommends otherwise, use left arm to measure pressure. Now you are ready. Follow these simple steps: Sit comfortably with your left arm resting on a flat surface so that the center of your upper arm is at the same height as your heart.
  • Page 9 TAKING YOUR BLOOD PRESSURE Before taking your blood pressure, you will need to set the pressure switch to a number that is at least 30 mmHg higher than your expected systolic pressure. Use the chart below as a guide. For example, if you believe your blood pressure to be 140 (systolic) over 90 (diastolic), set the switch to 180.
  • Page 10 TAKING YOUR BLOOD PRESSURE Press the START button, remain still and do not talk as the cuff automatically inflates to the correct level. It is normal for the cuff to feel very tight. You will see all the display symbols appear briefly. As the cuff pressurizes, blinking numerals—starting at zero—are displayed.
  • Page 11: Taking Your Blood Pressure

    TAKING YOUR BLOOD PRESSURE We advise that you record the date and time after each measure- ment because an accurate blood pressure history relies not on single or sporadic readings but on a pattern over time. NOTE: If you wish to take your blood pressure again, relax and wait 5–10 minutes to enable the flow of blood in the arm to return to normal.
  • Page 12: Check/Adjust Exhaust Velocity

    CHECK/ADJUST EXHAUST VELOCITY Exhaust velocity is the rate at which the air pressure in the cuff deflates during the course of measurement. It is preset at the factory and generally does not need any further adjustment. NOTE: The exhaust rate of your monitor was preset and tested at the factory to ensure proper measurement.
  • Page 13: Check/Adjust Exhaust Velocity

    CHECK/ADJUST EXHAUST VELOCITY If the exhaust velocity range is not within 2 to 5 mmHg, make the following adjustment with the unit turned off: With the edge of your fingernail, peel off the thin black plastic disk covering the adjustment screw. If there is no thin plastic disk, proceed to step 2.
  • Page 14: About Blood Pressure

    ABOUT BLOOD PRESSURE What Is Blood Pressure? Blood pressure is the force exerted by blood against the walls of the arteries. Systolic pressure occurs when the heart contracts; diastolic pressure occurs when the heart expands. Blood pressure is measured in millimeters of mercury (mmHg). What Affects Blood Pressure? Blood pressure is affected by many factors: age, weight, time of day, activity level, climate, altitude and season.
  • Page 15: About Blood Pressure

    ABOUT BLOOD PRESSURE Assessing High Blood Pressure The following standards for assessing high blood pressure (without regard to age) have been established by the National Institutes of Health JNCVI. Category Systolic (mmHg) Diastolic (mmHg) Optimal <120 <80 Normal <130 <85 High Normal 130 - 139 85 –...
  • Page 16: About Blood Pressure

    ABOUT BLOOD PRESSURE Why Measure Blood Pressure at Home? It is now well known that, for many individuals, blood pressure readings taken in a doctor’ s office or hospital setting might be elevated as a result of apprehension and anxiety. This response is commonly called “white coat hypertension.”...
  • Page 17: Blood Pressure Record

    B L O O D P R E S S U R E R E C O R D Name: Age: Weight: DATE SYS/DIA PULSE SYS/DIA PULSE 1/14 9:30 132/98 P 69 6:30 128/87 P 63 E X A M P L E LifeSource Health Line (Toll-Free): 1-888-726-9966...
  • Page 18: Important Information

    Remove and replace batteries if monitor is not used for more than six months. PRECAUTIONS UA-767 is designed to be used at home, by those who are eighteen (18) years and older, to monitor blood pressure (systolic and diastolic) and pulse rate. This monitor is not designed to measure the blood pressure of people with common arrhythmias, such as atrial or ventricular premature beats or atrial fibrillation.
  • Page 19: Specifications

    SPECIFICATIONS Model ....UA-767 Type .....Oscillometric Display .
  • Page 20: Contact Information

    CONTACT INFORMATION Our products are designed and manufactured using the latest scientific and technological methods, and offer accurate, easy to use, home monitoring and treatment options. The product line includes: Aneroid Blood Pressure Kits Blood Pressure Cuffs Digital Blood Pressure Monitors Digital Thermometers Stethoscopes This LifeSource product is covered by a Lifetime...
  • Page 21 Need Help? Call Toll-Free LifeSource Health Line: 1-888-726-9966 A division of A&D Engineering, Inc. 1555 McCandless Drive Milpitas, CA 95035 www.LifeSourceOnline.com UA-767 Printed in China 12/99...
