- Page 1 Digital Blood Pressure Monitor Model UA-767S Instruction Manual Original Manuel d’instructions Traduction Manual de Instrucciones Traducción Manuale di Istruzioni Traduzione 使用手冊 翻譯 1WMPD4002781C...
-
Page 2: Table Of Contents
Contents Dear Customers..............2 Preliminary Remarks ............. 2 Precautions................2 Parts Identification..............4 Symbols................5 Operation Mode..............7 Using the Monitor ..............8 Installing / Changing the Batteries ........8 Connecting the Air Hose ..........8 Connecting the AC Adapter..........8 Selecting the Correct Cuff Size ......... -
Page 3: Dear Customers
Dear Customers Congratulations on purchasing a state-of-the-art A&D blood pressure monitor, one of the most advanced monitors available today. Designed for ease of use and accuracy, this monitor will facilitate your daily blood pressure regimen. We recommend that you read through this manual carefully before using the device for the first time. - Page 4 Used equipment, parts and batteries are not treated as ordinary household waste, and must be disposed of according to the applicable local regulations. When the AC adapter is used, make sure that the AC adapter can be readily removed from the electrical outlet when necessary. Do not modify the device.
-
Page 5: Parts Identification
Parts Identification Display Air Connector Plug AC adapter Plug DC Jack Button START Air Socket Air Hose Proper Fit Range Artery Position Mark Index Mark Arm Cuff Battery Compartment Battery Cover 1.5V Batteries ｃ (R6P, LR6 or AA) Display Average MEMORY I.H.B. -
Page 6: Symbols
Symbols Symbols that are printed on the device case Symbols Function / Meaning Standby and Turn the device on. SYS. Systolic blood pressure in mmHg DIA. Diastolic blood pressure in mmHg PUL. Pulse per minute Battery installation guide Direct current Type BF: Device, cuff and tubing are designed to provide special protection against electrical shocks. - Page 7 Symbols Symbols Function / Meaning Recommended Action The reading may yield an Appears during measurement incorrect value. Apply the when the cuff is attached loosely cuff correctly, and take another measurement. Detected rate of IHB in memory Number of detected IHBs in memory x 100 [%] %IHB =...
-
Page 8: Operation Mode
Operation Mode 1. Normal Measurement Press the button. Blood pressure is measured and the data is stored START in memory. This device can store the last 60 measurements in memory. 2. Recalling the Data In standby, When nothing is displayed, press and hold press and hold the button. -
Page 9: Using The Monitor
Using the Monitor Installing / Changing the Batteries Step 1 1. Remove the battery cover. Step 3 Step 1 2. Remove the used batteries and insert new batteries into the battery compartment as shown, taking Step 2 care that the polarities (+ and -) are correct. -
Page 10: Selecting The Correct Cuff Size
Adult Cuff CUF-F-A Arm size: The circumference at the biceps. Note: Model UA-767S is not designed for using a small cuff. Applying the Arm Cuff 1. Wrap the cuff around the upper arm, Do not roll up shirtsleeve tightly. about 1-2 cm above the inside of the Cuff elbow, as shown. - Page 11 Using the Monitor Symbols that are printed on the cuff Symbols Function / Meaning Recommended Action Set the mark on the artery of the upper arm or Artery Position Mark in line with the ring finger on the inside of the arm. Index ▲...
-
Page 12: How To Take Proper Measurements
Using the Monitor How to Take Proper Measurements For the most accurate blood pressure measurement: Sit comfortably on a chair. Rest your arm on the table. Do not cross your legs. Keep your feet on the floor and straighten your back. Relax for about five to ten minutes before measurement. -
Page 13: Measurements
Measurements Before measurement, read “Notes for Proper Measurement” on the next page. Normal Measurement Place the cuff on the arm (preferably the left arm). At heart level Sit quietly during measurement. Press the button. START All of the display segments are displayed. Press START Zero (0) is displayed blinking briefly. -
Page 14: Measurement With The Desired Systolic Pressure
Measurements Measurement with the Desired Systolic Pressure Model UA-767S is designed to detect the pulse and to inflate the cuff to a systolic pressure level automatically. Use this method when re-inflation occurs repeatedly or when the results are not displayed even if the pressure decreases to 20 mmHg or less. -
Page 15: Recalling The Memory Data
Should the device detect a condition that is abnormal, it will stop the measurement and display an error symbol. Refer to page 6 for the description of symbols. This blood pressure monitor is intended for use by adults only. Consult with your physician before using this device on a child. -
Page 16: What Is An Irregular Heartbeat
What is an Irregular Heartbeat The UA-767S blood pressure monitor provides a blood pressure and pulse rate measurement even when an irregular heartbeat occurs. An irregular heartbeat is defined as a heartbeat that varies by 25% from the average of all heartbeats during the blood pressure measurement. It is important that you are relaxed, remain still and do not talk during measurements. -
Page 17: Pressure Bar Indicator
Pressure Bar Indicator The indicator monitors the progress of pressure during measurement. Pressurizing Releasing air Inflation in progress Measurement in progress Inflation complete WHO Classification Indicator Each segment indicator Example: corresponds to the WHO blood pressure classification described on the next page. WHO Classification Indicator Severe hypertension Moderate hypertension... -
Page 18: What Is Hypertension And How Is It Controlled
What is Hypertension and How is it Controlled? Hypertension, an abnormally high arterial blood pressure, if left unattended, can cause many health problems including stroke and heart attack. Hypertension can be controlled by altering lifestyle, avoiding stress, and with medication under a doctor’s supervision. To prevent hypertension or keep it under control: Do not smoke Exercise regularly... -
Page 19: Troubleshooting
Troubleshooting Problem Possible Reason Recommended Action Replace all batteries with new Nothing Batteries are drained. ones. appears on the Reinstall the batteries with display, even Battery terminals are not negative and positive terminals when the power in the correct position. matching those indicated on the is turned on. -
Page 20: Maintenance
However it is generally recommended to have the device inspected every 2 years, to ensure proper functioning and accuracy. Please contact the authorized dealer in your area or A&D for maintenance. Technical Data Type UA-767S Measurement method Oscillometric measurement Measurement range Pressure: 0 - 299 mmHg... - Page 21 Applied part Cuff Type BF Useful life Device: 5 years (when used six times a day) Cuff: 2 years (when used six times a day) Accessory AC adapter The adapter is to connect the device to a power source at home. Please contact your local A&D dealer for purchasing.
- Page 22 1-243 Asahi , Kitamoto-shi, Saitama 364-8585, JAPAN Telephone: [81] (48) 593-1111 Fax: [81] (48) 593-1119 A&D INSTRUMENTS LIMITED Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485 A&D ENGINEERING, INC. 1756 Automation Parkway, San Jose, California 95131, U.S.A.
