Summary of Contents for Nilfisk-ALTO FLOORTEC 560 P

  • Page 1  www.nilfisk-alto.com FLOORTEC 560 P DEUTSCH BETRIEBSANLEITUNG FRANÇAIS MANUEL D’UTILISATION ENGLISH USER MANUAL NEDERLANDS GEBRUIKSAANWIJZING...
  • Page 2 S310027 S310028 S310072 S310029 S310030 S310074 S310032 S310088 S310075 S310034...
  • Page 3: Table Of Contents

    DUST FILTER CLEANING AND INTEGRITY CHECK ................... 11 SKIRT HEIGHT AND OPERATION CHECK ....................12 HOOD SAFETY SWITCH OPERATION CHECK ................... 12 TROUBLESHOOTING ........................13 SCRAPPING ............................13 EC CERTIFICATE OF CONFORMITY ....................14 146 2592 000(1)2005-03 A FLOORTEC 560 P...
  • Page 4: Introduction

    Nilfisk-Alto Service Center in case of doubts procedures must be carried out by qualified personnel or regarding the interpretation of the instructions and for any by Nilfisk-Alto Service Centers (listed at the end of this further information. manual). Only original spare parts and accessories must be used.
  • Page 5: Symbols

    – Do not let fuel come into contact with your skin; do not breathe fuel vapours. Keep out of reach of children. 146 2592 000(1)2005-03 A FLOORTEC 560 P...
  • Page 6: Unpacking

    25. Pedal brake on front wheel (optional) 26. Fuel tank cap 27. Engine pull-starter cord handle 28. Engine exhaust pipe 29. Petrol tap and engine starter compartment 30. Petrol engine ventilating grid 31. Front skirt lifting lever FLOORTEC 560 P 146 2592 000(1)2005-03 A...
  • Page 7: Technical Data

    Paper dust filter 5-10 µm Air lever (starter) Main broom compartment vacuum 12 mm H Diagrams Wiring diagram (see Fig. X) engine frame engine on/off switch engine ignition coil SW1: hood safety switch Color code Black 146 2592 000(1)2005-03 A FLOORTEC 560 P...
  • Page 8: Accessories/Options

    (5, Fig. C) is lifted. A safety system prevents the engine from starting. NOTE The engine running, the main broom always rotates, while the side broom doesn't move if it is lifted. FLOORTEC 560 P 146 2592 000(1)2005-03 A...
  • Page 9: Machine Operation

    – While working, repeat the operation every 10 minutes on average (depending on the dustiness of the area to be cleaned). 146 2592 000(1)2005-03 A FLOORTEC 560 P...
  • Page 10: After Using The Machine

    Check that the visible parts are whole and that there are no leaks. After the first 20 hours of work, or after the first month, replace the petrol engine oil (see instructions in the related User Manual). FLOORTEC 560 P 146 2592 000(1)2005-03 A...
  • Page 11: Scheduled Maintenance Table

    (6): maintenance operations to be performed by an authorized Honda Dealer, unless the Operator has the service equipment and data and feels qualified for such operations (7): For the related procedure, see the Petrol Engine User Manual (8): If considered necessary by the person in charge for the maintenance 146 2592 000(1)2005-03 A FLOORTEC 560 P...
  • Page 12: Main Broom Height Check

    Take care when performing the above-mentioned checks and use the machine only according to the indicated conditions. FLOORTEC 560 P 146 2592 000(1)2005-03 A...
  • Page 13: Side Broom Height Adjustment

    Install the new broom on the machine engaging it on the fan (24, Fig. U)). the pins (3) and on the tabs (1). Carry out the side broom height adjustment as described in the previous paragraph. 146 2592 000(1)2005-03 A FLOORTEC 560 P...
  • Page 14: Skirt Height And Operation Check

    (23) together with the belt (17, Fig. U). – On the machine, adjust the skirt (1, Fig. S) height by using its slots (2). – Reassemble in the reverse order of disassembly. FLOORTEC 560 P 146 2592 000(1)2005-03 A...
  • Page 15: Troubleshooting

    Adjust the belt tensioner Check the drive belt efficiency (1): For the related procedure, see the Petrol Engine User Manual. For further information, refer to the Service Manual, available at any Nilfisk-Alto Service Center. 146 2592 000(1)2005-03 A FLOORTEC 560 P...
  • Page 16: Ec Certificate Of Conformity

    USER MANUAL ENGLISH EC CERTIFICATE OF CONFORMITY FLOORTEC 560 P 146 2592 000(1)2005-03 A...
  • Page 17 S310035 S310036 S310037 S310083 S310084 S310085 S310040 S310041 S310062 S310089...
