Explanation of LED Displays
+
I
Table 1
Symbol
Meaning
Lights when the battery is charging or ready for use.
+
I
Lights when the computer is switched on. Flashes in power saving mode.
Lights when the hard disk is being accessed.
Lights when optical disk is accessed.
Lights when the wireless LAN is activated.
Lights when Caps Lock is on.
Lights when Num Lock is on.
Lights when Scroll Lock is on.
MAXDATA Notebook PRO 6000 I
Fig. 11
(1)
Battery
(2)
Power
(3)
Hard disk access
(4)
ODD access
(5)
Wireless LAN
(6)
Caps Lock
Num Lock
(7)
(8)
Scroll Lock
UK
73
