Hans Grohe Metro E 06572000 Features & Dimensions

Metro E Showerpanel I
The measurements shown are for reference only.
Products and specifications shown are subject to
change without notice.
Specification sheet revised 2/2008

Product Features

• Anodized aluminum body, satin chrome finish
• Pre-plumbed with thermostatic temperature control with
integrated diverter and volume control
• Max. flow rate of valve -- 8 gpm @ 44 psi
• Raindance E 100 AIR 3-Jet handshower with 63" handshower
hose, 2.5 gpm
• Protection against backflow provided by check valve
• Integrated wallbar with angle adjustable handshower holder
• 5 angle adjustable bodyjets
• Frosted accessory shelf
• 1/2" connections

Code Compliance

This unit meets or exceeds the following:
• ASME A112.18.1
• CSA B125.1
• ASSE 1016
• Listed by IAPMO
• Approved for use in Massachusetts

Available Finishes

Satin chrome panel with chrome trim
Satin chrome panel with brushed nickel trim
06572XX0
06572000
06572820
