BLADEZ KZ1 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

KZ1
BIKE
OWNER'S MANUAL
CAUTION:
Exercise of a strenuous nature, as is customarily done on this equipment, should not be
undertaken without first consulting a physician. No specific health claims are made or implied as they
relate to the equipment.
IMPORTANT:
Read all instructions carefully before using this product. Retain this owner's
manual for future reference.
BH North America
Foothill Ranch, California 92610

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KZ1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BLADEZ KZ1

Summary of Contents for BLADEZ KZ1

  • Page 1 BIKE OWNER’S MANUAL CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment, should not be undertaken without first consulting a physician. No specific health claims are made or implied as they relate to the equipment. IMPORTANT: Read all instructions carefully before using this product.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety……......………….…..1 Pre-Assembly Instructions…….....3 Assembly Instructions…………………..5 Maintenance…………………………....9 Troubleshooting……..………………………10 Exploded View ………........11 Parts List …………………......12 Warranty……..………………………....13...

  • Page 3: Safety

    IMPORTANT SAFETY ADVICE PRECAUTIONS This bike has been designed and constructed to provide maximum safety. Nevertheless, certain precautions should be taken when using exercise equipment. Read the whole manual before assembling and using the bike. The following safety precautions should also be observed: 1.
  • Page 4 KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE FOR WARRANTY REPAIR PLEASE DO NOT TAKE YOUR BIKE BACK TO THE RETAIL STORES! CONTACT BLADEZ FITNESS FIRST BH North America Corporation 20155 Ellipse Foothill Ranch, CA 92610 Toll Free: (866) 325-2339...

  • Page 5: Pre-Assembly Instructions

    6. Use suitable clothing and footwear. Make sure all laces/cords are tied correctly. FOR WARRANTY REPAIR PLEASE DO NOT TAKE YOUR BIKE BACK TO THE RETAIL STORES! CONTACT BLADEZ FITNESS FIRST BH North America Corporation 20155 Ellipse Foothill Ranch, CA 92610...
  • Page 6 ASSEMBLY...

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS STEP 1 Attach the front stabilizer (2) to the main frame (1) and secure with carriage bolts (43), washers (44), and dome nuts (45). STEP 2 Attach the rear stabilizer (3) to the main frame (1) and secure with carriage bolts (43), washers (44), and dome nuts (45).
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 3. Slide the handlebar post (6) into the main frame (1) and tighten the adjustable plastic knob (54) to secure STEP 4 Attach the handlebar (7) to the main frame (1) and secure it with bolts (57), washers (29).
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 5. Slide the seat post (4) into the main frame (1) and secure it with the adjustable plastic knob (54). STEP 6 Attach the seat (36) to the seat bar (5). Slide the seat bar (5) into the seat post (4) and tighten the adjustable plastic knob (54) to secure...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 7. Left or right, manually thread the pedal (40) onto the crank arm toward the front of the bike at first until tight. Then, tighten further with wrench. Failure to follow the directions can result in damage to either the crank or the pedal threads. The right-hand pedal, marked with the letter (R),screws onto the right-hand crank, also marked with an (R), should be tightened in a clockwise direction (toward the front).

  • Page 11: Maintenance

    MAINTENANCE INSTRUCTIONS CLEANING Care has been taken to assure that your bike has been properly adjusted and lubricated at the factory. It is not recommended that the user attempt service on the internal components instead seek service from an authorized service center. However, from time-to-time the outer surfaces may appear dull or dirty.

  • Page 12: Troubleshooting

    TROUBLE SHOOTING RESISTANCE ADJUSTMENT: Pedaling resistance is controlled by the tension (adjustable) plastic knob. Properly adjusting the seat will help reducing the risk of injury and ensure maximum exercise efficiency and comfort. The most appropriate position while using this bike is while one pedal in the downward position, the other leg is slightly bent at the knee.

  • Page 13: Exploded View

    EXPLODED VIEW...

  • Page 14: Parts List

    PARTS LIST No. Description Size Description Size Main frame Crank Shaft Front stabilizer Spacer for crank Rear stabilizer Crank Seat post Pedal Seat post Adjustable foot Front post Adjustable nut Handlebar Carriage bolt M8x40 M12x1 Washer Φ8 Chain adjust screw Nylon nut Nylon nut Hex nut...

  • Page 15: Warranty

    Owner’s Manual. FOR WARRANTY REPAIRS, PLEASE DO NOT TAKE YOUR MACHINE BACK TO THE RETAIL STORES. CONTACT BLADEZ FITNESS FIRST! BH North America Corporation 20155 Ellipse Foothill Ranch, CA 92610...
